Verify that the Communication Type is set for COM Port and the Select Port field is set for the
COM port of your local PC.
In the Dial String field, enter the AT command for dialing (ATDT) plus the phone number of the
remote MultiFRAD.
If your Modem Initialization String, Initialization Response, or Connect Response values are
different from the defaults in the dialog box, refer to your modem user documentation and change
the default values to match your modem.
Click OK when you are satisfied with your selections.
6 Run the MultiFRAD Configuration program. Click Start | Programs | MultiFRAD 200 |
MultiFRAD Configuration, or double-click the MultiFRAD Configuration icon in the MultiFRAD
200 program group.
7 The Dialing dialog box is displayed while software is dialing the remote MultiFRAD.
8 The Reading Setup dialog box is displayed.
9 The MultiFRAD main menu is displayed. This is the main menu for the remote MultiFRAD.
10 After you have changed the configuration of the remote MultiFRAD, click Download Setup to
update the configuration. The remote MultiFRAD will be brought down, the new configuration
written to the unit, and the unit will reboot.
11 Click Exit when the downloading is complete.
12 The Hangup connection? dialog box is displayed
Click Yes to disconnect the phone connection to the remote site.
13 If the same telephone number is not going to be used again in the immediate future, you may
want to remove it from the Port Setup dialog box.
14 At the remote site, reconnect the MultiFRAD to the serial port of the PC and from the MultiFRAD
200 program group double click on the MultiFRAD Configuration icon to verify that the
MultiFRAD is running.
