Features

1.5
 Modules can be easily installed and connected without tools.
 Flexible and modular structure allows I/O stations to be easily expanded.
 A comprehensive selection of I/O modules supports a wide range of applications.
 Small removable terminal blocks conserve panel space and save time making system
connections.

Module-based diagnostic functions
 The amount of costly parallel wiring is reduced. Within a station, voltage and data routing
can be carried out without additional wiring, reducing the cabinet space needed.
 Different parts of the system can be operated independent of one another. This means
that pretests can be carried out when the system is set up and that the whole system can
be adapted and expanded.

List of RSTi Network adapters

1.6
RSTi PROFIBUS Network Adapters:













RSTi PROFINET Network Adapter


PACSystems Documentation

1.7
■
GFK-2746B PACSystems* RSTi PROFIBUS and PROFINET Network Adapter–August 2013
STXPBS001 PROFIBUS DP/V1 network adapter
STXPBS032 32 point Positive Logic Input
STXPBS132 32 point Negative Logic Input
STXPBS232 32 point Negative Logic Output
STXPBS332 32 point Positive Logic Output
STXPBS016 16 relay output
STXPBS116 16 relay output isolated
STXPBS432 16 Positive Logic in/16 Negative Logic out
STXPBS532 16 Negative Logic in/16 Negative Logic out
STXPBS824 16 Positive Logic in/8 relay out
STXPBS924 16 Negative Logic in/8 relay out
STXPBS825 16 Positive Logic in/8 relay out isolated
STXPBS925 16 Negative Logic in/8 relay out isolated
STXPNS001 PROFINET network adapter
PACSystems RSTi I/O Manual – GFK 2745
