3 Unboxing & Installation

3.1 Optional accessories

RS-Ruby Plus package does not include accessories by default and requires additional purchase;
The table below lists the optional accessoriesof RS-Ruby Plus from the factory.
No.
1
2
3
4
5
6
7
Note: If there are special requirements, please refer to the actual negotiation.

3.2 Sensor Mounting

As shown in the figure below, the mounting surface of the LiDAR should be flat and uneven
surfaces should be avoided.The precise locator pins on the mounting base should strictly follow
the dimensions of the locator holes at the bottom of the LiDAR, and the height of the locator pin
should not be higher than 4mm. We recommend using aluminum alloy for the mounting base
material, which facilitates heat dissipating of the LiDAR during operating.
Table 3-1 Optional Accessories of the RS-Ruby Plus
Contents
Interface Box
4 pin Airline
16 pin Airline
Power Adapter
Power Cable
Ethernet Cable
Screw Pack
6
RS-Ruby Plus User Manual
SPEC/QTY
*1
3m /4m/6m/12m
3m /4m/6m/12m
DC12Vx3.34A/40W *1
1.2M *1
1.5M *1
M4x10 *3
