Troubleshooting; Technical Specifications - Transition Networks SCSCF3011-100 User Manual

SCSCF30xx-10x
Cable Specifications -- Continued
CSCSCF3039-100
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
The fiber optic transmitters on this device meet Class I Laser safety requirements
per IEC-825/CDRH standards and comply with 21 CFR1040.10 and
21CFR1040.11.

Technical Specifications

For use with Transition Networks Model SCSCF30xx-10x or equivalent
Standards FCC Class A; EN 55022 Class A; EN 55024; ANSI
T1.102-1993; ETSI TBR-24; ITU-T G.703 G.823 for
jitter tolerance; G.775 for loss of signal; Telecordia
GR-499CORE & GR-253-CORE
Data Rate DS3 / T3 = 44.7 Mb/s; E3 = 34.4 Mb/s
Dimensions 3.25" x 4.7" x 1.0" (83 mm x 119 mm x 25 mm)
Weight 10 oz. (283 g) (approximately)
Power Consumption 6.0 Watts
Power Supply 12 VDC, 0.8 Amp (minimum)
DC Outlet Minimum output regulation: 5%
MTBF (stand alone) 48,996 (MIL217F2 V5.0) (MIL-HDBD-217F)
119,854 (Bellcore7 V5.0)
Environment Tmra*:
Storage Temp:
Humidity:
Altitude:
Warranty Lifetime
*Manufacturer's rated ambient temperature.
For the most up-to-date information on the SCSCF30xx-10x media converter,
view the user's guide on-line at www.transition.com.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into
beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures
other than those specified herein may result in hazardous radiation exposure.
8
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
1300 nm multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
0 to 50°C (32° to 122°F )
-20° to 85°C (-4° to 185°F)
5 to 95%, non condensing
0 to 10,000 feet

Troubleshooting

If the media converter fails, isolate and correct the failure by determining the
answers to the following questions and then taking the indicated action:
1. Is the PWR (Power) LED on the media converter illuminated?
NO
• Ensure that the power adapter is the proper type of voltage and cycle
frequency for the outlet (See "Power Supply" on page 8.)
• Ensure the power adapter is properly installed in the media converter
and in the grounded outlet.
• Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the SDC (Signal Detect / Coax) LED illuminated green?
NO
• Check the coax cables for the proper connection.
• Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the SDF (Signal Detect / Fiber) LED illuminated green?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the local media converter are
connected to the RX and TX ports, respectively, on the remote media
converter.
• Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
YES
• Proceed to step 4.
4. Is the SDC (Signal Detect / Coax) LED flashing green?
YES
• The coax link is in loop-back mode. For normal operation, set the
loop-back switch to the center (normal) position.
• Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
NO
• Proceed to step 5.
5. Is the SDF (Signal Detect / Fiber) LED flashing green?
YES
• The fiber link is in loop-back mode. For normal operation, set the
loop-back switch to the center (normal) position.
• Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
NO
• Proceed to step 6.
