Troubleshooting

1. Is a media converter installed in the single‐slot chassis?
NO
• Install a slide‐in card, media converter into the single‐slot chassis. See the Installation section.
• Proceed to step 2.
YES
• Proceed to step 2.
2. Is the Power LED on the media converter lit?
NO
• Is the power adapter the proper type and cycle frequency for the AC outlet? (See the Specifications
section)
• Is the power adapter properly installed in the media converter and in the grounded AC outlet?
• Contact Technical Support. See Contact Us below.
YES
• Proceed to step 3.
3. Check the power requirement for the installed slide‐in card:
• Power requirement must be 6 W or less.
• For additional assistance, see Contact Us below.

Related Manuals and Help

A printed documentation card is shipped with each ION001-A chassis.
Application Notes, Brocures, Case Studies, Data Sheets, Specifications, Webinars, White papers, etc. go
to https://www.transition.com/support/library/ (no registration required).
For Transition Networks Drivers, Firmware, Release Notes, Manuals (Install Guides, Quick Start Guides,
User Guides) go to the Product Support webpage at https://www.transition.com/support/product‐
support/ (logon required).
Other ION system and related device manuals include.
1. Product Documentation Postcard, 33504
2. ION Management Module (IONMM) Install Guide, 33420 and User Guide, 33457
3. ION System NID User Guides (33432, 33457, 33472, 33493, 33494, 33495, 33496, 33574)
4. SPS-2460-SA External Power Supply User's Guide, 33455
™
5. Focal Point
6. Release Notes (firmware version specific)
Note: Information in this document is subject to change without notice.
33419 Rev. C
3.0 Management Application User Guide, 33293
