Transition Networks SGFEB1013-100 User Manual

Stand-alone media converter
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Enlarged version
User's Guide
SGFEB10xx-1xx
Stand-Alone Media Converter
• Copper to Fiber
• 10/100/1000Base-TX to 1000Base-SX/LX
• Optional Tap Port
Transition Networks SGFEB10xx-1xx series
media converters connect 10Base-TX,
100Base-TX, or 1000Base-TX twisted-pair
copper cable to 1000Base-SX or 1000Base-LX
fiber cable.
Part Number
Port 1 - Copper
10/100/1000-Base-TX
SGFEB1013-100
RJ-45
100 m (328 ft)
SGFEB1014-100
RJ-45
100 m (328 ft)
SGFEB1015-100
RJ-45
100 m (328 ft)
SGFEB1017-100
RJ-45
100 m (328 ft)
SGFEB1024-100
RJ-45
100 m (328 ft)
SGFEB1035-100
RJ-45
100 m (328 ft)
The distances listed are the typical maximum cable distance. Actual distance is
dependent upon the physical characteristics of the network installation.
** The CGFEB1024 extends 1000Base beyond 220 m. Transition Networks
cannot guarantee a full 2 km distance on every installation since the distance is
largely dependent on the quality of the fiber, cable installation and splicing.
Port 2 - Duplex Fiber-Optic
SC, 1000Base-SX, 850 nm multimode
220 m (720 ft)
SC, 1000Base-LX, 1310 nm
single mode, 10 km (6.2 miles)
SC, 1000Base-LX, 1310 nm
single mode, 25 km (15.5 miles)
SC, 1000Base-LX, 1550 nm
single mode, 65 km (40.4 miles)
SC, 1000Base-LX, 1300 nm
multimode, 2 km (1.2 miles)**
SC, 1000Base-LX, 1550 nm
single mode, 125 km (77.5 miles)
Installation . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . .6
Cable Specifications . . . . . . . . .9
Troubleshooting . . . . . . . . . . .12
Contact Us . . . . . . . . . . . . . . .15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGFEB1013-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Transition Networks SGFEB1013-100

Summary of Contents for Transition Networks SGFEB1013-100

  • Page 1: Table Of Contents

    100Base-TX, or 1000Base-TX twisted-pair copper cable to 1000Base-SX or 1000Base-LX fiber cable. Part Number Port 1 - Copper Port 2 - Duplex Fiber-Optic 10/100/1000-Base-TX SGFEB1013-100 RJ-45 SC, 1000Base-SX, 850 nm multimode 100 m (328 ft) 220 m (720 ft) SGFEB1014-100 RJ-45...
  • Page 2 SGFEB10xx-1xx The SGFEB10xx-1xx single fiber-optic models are listed below: Part Number Port 1 - Copper Port 2 - Single Fiber-Optic 10/100/1000-Base-TX 1000Base-SX, single mode SGFEB1029-100 RJ-45 SC, 1310 nm (TX) / 1550 nm (RX) 100 m (328 ft) 20 km (12.4 miles) SGFEB1029-101 RJ-45, SC, 1550 nm (TX) / 1310 nm (RX)

  • Page 3: Installation

    SGFEB10xx-1xx Installation CAUTION: Wear a grounding device and observe electrostatic discharge precautions when setting the jumpers and the six-position switch. Failure to observe this caution could result in damage to, and subsequent failure of, the media converter. Six-Position Switch The six-position switch is located on the side of the media converter. Use a small, flat-blade screwdriver (or a similar device) to set the switch according to the site the requirements (see the drawing below).

  • Page 4: Operation

    SGFEB10xx-1xx Installation -- Continued Install the Cable Port 1: 10/100/1000Base-TX Copper Port Locate or build 10, 100, or 1000Base-TX compliant copper cables with male, RJ-45 connectors installed at both ends. Connect the RJ-45 connector at one end of the cable to the media converter’s 10/100/1000Base-TX RJ-45port (port 1).
  • Page 5 SGFEB10xx-1xx Operation -- Continued Product Features Auto-Negotiation The Auto-Negotiation feature allows the SGFEB10xx-1xx media converter to automatically configure itself to achieve the best possible mode of operation over a link. The media converter broadcasts its speed (10 Mb/s, 100 Mb/s, or 1000 Mb/s) and duplex capabilities (full or half) to the other devices and negotiates the best mode of operation.

  • Page 6: Cable Specifications

    <10-9 Single mode fiber (recommended): 9 µm Multimode fiber (recommended): 62.5/125 µm Multimode fiber (optional): 100/140, 85/140, 50/125 µm SGFEB1013-100, SGFEB1013-110 850 nm multimode Fiber Optic Transmitter Power: min: -10.0 dBm Fiber Optic Receiver Sensitivity: min: -17.0 dBm Link Budget: 7.5 dB...

  • Page 7: Technical Specifications

    SGFEB10xx-1xx Technical Specifications For use with Transition Networks Model SGFEB10xx-1xx. Standards: IEEE 802.3™ Dimensions: 4.8" x 3.25" x 1.0" (122 x 82 x 25 mm) Weight: 10 oz (283 g) Power Consumption: 7.28 watts Power Supply: 12VDC, 1.25 A Data Rate (copper): 10, 100, 1000 Mb/s Data Rate (fiber): 1000 Mb/s (operates in full-duplex only)

  • Page 8: Contact Us

    Name of Mfg: Transition Networks 6475 City West Parkway, Minneapolis MN 55344 U.S.A. Model: SGFEB10xx-1xx Series Media Converters Part Number(s): SGFEB1013-100, SGFEB1014-100, SGFEB1015-100, SGFEB1017-100, SGFEB1024-100, SGFEB1035-100, SGFEB1029-100, SGFEB1040-100 SGFEB1029-101, SGFEB1029-102, SGFEB1029-103, SGFEB1013-110, SGFEB1014-110, SGFEB1015-110, SGFEB1017-110, SGFEB1024-110, SGFEB1029-110, SGFEB1029-111, SGFEB1029-112, SGFEB1029-113, SGFEB1035-110...

  • Page 9: Compliance Information

    Compliance Information CISPR22/EN55022 Class A + EN55024 CE Mark FCC Regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
