Transition Networks CRMFE1011-200 User Manual

SRMFE10xx-20x
(remote)
Transition Networks CRMFE10xx-20x and SRMFE10xx-20x
series fast Ethernet media converters connect 100Base-TX
shielded or unshielded twisted-pair copper cable to 100Base-
FX fiber-optic cable.
The media converters are designed to be installed in pairs
where the CRMFE10xx-20x is the local media converter and
the SRMFE10xx-20x is the remote media converter.
Part Number Port One - Copper
100Base-TX
CRMFE1011-200 RJ-45
SRMFE1011-200 100 m (328 ft)*
CRMFE1013-200 RJ-45
SRMFE1013-200 100 m (328 ft)*
CRMFE1014-200 RJ-45
SRMFE1014-200 100 m (328 ft)*
CRMFE1015-200 RJ-45
SRMFE1015-200 100 m (328 ft)*
CRMFE1016-200 RJ-45
SRMFE1016-200 100 m (328 ft)*
CRMFE1017-200 RJ-45
SRMFE1017-200 100 m (328 ft)*
CRMFE1018-200 RJ-45
SRMFE1018-200 100 m (328 ft)*
CRMFE1019-200 RJ-45
SRMFE1019-200 100 m (328 ft)*
CRMFE1025-200 RJ-45
SRMFE1025-200 100 m (328 ft)*
* Typical maximum cable distance.
Actual distance is dependent upon the
physical characteristics of the network.
User's Guide
CRMFE10xx-20x
- Chassis
SRMFE10xx-20x
- Stand-Alone
• Fast Ethernet
• 100Base-TX to 100Base-FX
• Remote Converter Management
CRMFE10xx-20x
Port Two - Duplex Fiber-Optic
100Base-FX
ST, 1300 nm multimode
2 km (1.2 miles)*
SC, 1300 nm multimode
2 km (1.2 miles)*
SC, 1310 nm single mode
20 km (12.4 miles)*
SC, 1310 nm single mode
40 km (24.8 miles)*
SC, 1310 nm single mode
60 km (32.3 miles)*
SC, 1550 nm single mode
80 km (49.7 miles)*
MT-RJ, 1300 nm multimode
2 km (1.2 miles)*
LC, 1310 nm single mode
20 km (12.4 miles)
MT-RJ, 1310 nm single mode
20 km (12.4 miles)*
