CMEFG10xx-1xx / SMEFG10xx-1xx
Cable Specification -- continued
Fiber cable (DMI models)
CMEFG1013-110, SMEFG1013-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CMEFG1014-110, SMEFG1014-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CMEFG1015-110, SMEFG1015-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CMEFG1029-110, SMEFG1029-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CMEFG1029-111, SMEFG1029-111
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CMEFG1029-112, SMEFG1029-112
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CMEFG1029-113, SMEFG1029-113
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
16
24-hour Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
850 nm multimode
min: -10.0 dBm max: -4.0 dBm
min: -17.0 dBm max: 0.0 dBm
7.0 dB
1310 nm single mode
min: -9.0 dBm max: -3.0 dBm
min: -21.0 dBm max: -3.0 dBm
12.0 dB
1310 nm single mode
min: -5.0 dBm max: -0.0 dBm
min: -24.0 dBm max: -3.0 dBm
19.0 dB
1310(TX)/1490(RX) nm single mode
min: -8.0 dBm max: -3.0 dBm
min: -22.0 dBm max: -3.0 dBm
14.0 dB
1490(TX)/1310(RX) nm single mode
min: -8.0 dBm max: -3.0 dBm
min: -22.0 dBm max: -3.0 dBm
14.0 dB
1310(TX)/1490(RX) nm single mode
min: -3.0 dBm max: +2.0 dBm
min: -23.0 dBm max: -3.0 dBm
20.0 dB
1490(TX)/1310(RX) nm single mode
min: -3.0 dBm max: +2.0 dBm
min: -23.0 dBm max: -3.0 dBm
20.0 dB
Cable Specification -- Continued

Copper cable

Category 5: (minimum requirement)
Gauge:
Attenuation:
Maximum Cable Distance:
• Straight-through (MDI) or crossover (MDI-X) cable may be used.
• Shielded twisted-pair (STP) or unshielded twisted-pair (UTP) may be used.
• All pin pairs (1&2, 3&6, 4&5, 7&8) are active in a gigabit Ethernet network.
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into
beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures
other than those specified herein may result in hazardous radiation exposure.
The fiber optic transmitters on this device meet Class I Laser safety
requirements per IEC-825/CDRH standards and comply with 21 CFR1040.10
and 21CFR1040.11.
Optional Accessories for the SMEFG10xx-1xx media converter (sold separately).
Part # Description
SPS-1872-SA Optional External Power Supply; 18-72VDC Stand-Alone
Output: 12.6VDC, 1.0 A
WMBL Optional Wall Mount Brackets; Length: 4.0 in. (102mm)
WMBV Optional Vertical Mount Bracket; Length: 5.0 in. (127mm)
WMBD Optional DIN Rail Mount Bracket; Length: 5.0 in. (127mm)
WMBD-F Optional DIN Rail Mount Bracket (flat); Length: 3.3in. (84mm)
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
24 to 22 AWG
22.0 dB /100m @ 100 MHz
100 meters
