ADT7473

ABSOLUTE MAXIMUM RATINGS

Table 2.
Parameter
Positive Supply Voltage (V )
CC
Voltage on Any Input or Output Pin
Input Current at Any Pin
Package Input Current
Maximum Junction Temperature (T
Storage Temperature Range
Lead Temperature, Soldering
IR Reflow Peak Temperature
Lead Temperature (Soldering, 10 sec)
ESD Rating
ESD CAU TION
ESD (electrostatic dischar ge) sensitive device. Electrostatic charges as high a
th e human body and te st equipment and can discharge without detection. Although this product features
pr oprietary ESD protec ti on circuitry, permanent damage may occur on devices subjected to high energy
elec trostatic discharge s. Therefore, proper ESD precautions are recommended to avoid perf
de gradatio n or loss of fun ctionality.
Rating
3.6 V
−0.3 V to +3.6 V
±5 mA
±20 mA
max) 150°C
J
−65°C to +150°C
260°C
300°C
1500 V
Rev. A | Page 6 of 76
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.

THERMAL RESISTANCE

θ is sp ecified for the worst-case conditions, that is, a device
JA
soldered in a circuit board for surface-mount packages.
Table 3. Thermal Resistance
Package Type
16-Lead QSOP
s 4000 V readily accumulate on
ormance
θ θ Unit
JA JC
150 39 °C/W
