Analog Devices dBCool ADT7473 Manual page 72

ADT7473
Table 50. Register 0x75—Interrupt Mask Register 2 (Power-On Default <7:0> = 0x00)
Bit Name R/W
[1] OVT Read only
[2] FAN1 R/W
[3] FAN2 R/W
[4] FAN3 R/W
[5] F4P R/W
[6] D1 R/W
[7] D2 R/W
Table 51. Register 0x76—Extended Resolution 1
Bit Name R/W
[3:2] V Read-only
CCP
[5:4] V Read-only
CC
1 If this register is read, this register and the registers holding the MSB of each reading are frozen until read.
Table 52. Register 0x77—Extended Resolution Register 2
Bit Name R/W
[3:2] TDM1 Read-only
[5:4] LTMP Read-only
[7:6] TDM2 Read-only
1
If this register is read, this register and the registers holding the MSB of each reading are frozen until read.
Table 53. Register 0x78—Configuration Register 3 (Power-On Default = 0x00)
1
Bit Name R/W
[0] ALERT R/W
[1] THERM R/W
[2] BOOST R/W
[3] FAST R/W
[4] DC1 R/W
[5] DC2 R/W
[6] DC3 R/W
[7] DC4 R/W
1
This register becomes read-only when the Configuration Register 1 lock bit is set to 1. Any further attempts to write to this register have no effect.
Description
OVT = 1, masks SMBALERT for overtemperature THERM conditions.
FAN1 = 1, masks SMBALERT for a Fan 1 fault.
FAN2 = 1, masks SMBALERT for a Fan 2 fault.
FAN3 = 1, masks SMBALERT for a Fan 3 fault.
F4P = 1, masks SMBALERT for a Fan 4 fault. If the TACH4 pin is being used as the THERM input, this
bit masks SMBALERT for a THERM timer event.
D1 = 1, masks SMBALERT for a diode open or short on a Remote 1 channel.
D2 = 1, masks SMBALERT for a diode open or short on a Remote 2 channel.
1
Description
V LSBs. Holds the 2 LSBs of the 10-bit V
CCP
V LSBs. Holds the 2 LSBs of the 10-bit V
CC
1
Description
Remote 1 temperature LSBs. Holds the 2 LSBs of the 10-bit Remote 1 temperature measurement.
Local temperature LSBs. Holds the 2 LSBs of the 10-bit local temperature measurement.
Remote 2 temperature LSBs. Holds the 2 LSBs of the 10-bit Remote 2 temperature measurement.
Description
ALERT = 1, Pin 5 (PWM2/SMBALERT) is configured as an SMBALERT interrupt output to indicate out-of-
limit error conditions.
THERM Enable = 1 enables THERM functionality on Pin 9. Also determined by Bit 0 and Bit 1 (PIN9FUNC) of
Configuration Register 4. Direction is controlled by Bit 5, Bit 6, and Bit 7 of Configuration Register 5 (0x7C).
When THERM is asserted, if the fans are running and the boost bit is set, the fans run at full speed. THERM
can also be programmed so that a timer monitors the duration THERM has been asserted.
When THERM is an input and BOOST = 1, assertion of THERM causes all fans to run at the maximum
programmed duty cycle for fail-safe cooling.
FAST = 1, enables fast TACH measurements on all channels. This increases the TACH measurement rate
from once per second to once every 250 ms (4 ×).
DC1 = 1, enables TACH measurements to be continuously made on TACH1. Fans must be driven by dc.
Setting this bit prevents pulse stretching, because it is not required for DC-driven motors.
DC2 = 1, enables TACH measurements to be continuously made on TACH2. Fans must be driven by dc.
Setting this bit prevents pulse stretching, because it is not required for DC-driven motors.
DC3 = 1, enables TACH measurements to be continuously made on TACH3. Fans must be driven by dc.
Setting this bit prevents pulse stretching, because it is not required for DC-driven motors.
DC4 = 1, enables TACH measurements to be continuously made on TACH4. Fans must be driven by dc.
Setting this bit prevents pulse stretching, because it is not required for DC-driven motors.
Rev. A | Page 72 of 76
measurement.
CCP
measurement.
CC
