ABSOLUTE MAXIMUM RATINGS

Table 2.
Parameter
Positive Supply Voltage (V )
CC
Voltage on Any Input or Output Pin
Input Current at Any Pin
Package Input Current
Maximum Junction Temperature (T
Storage Temperature Range
Lead Temperature, Soldering
IR Reflow Peak Temperature
Lead Temperature (Soldering, 10 sec)
ESD Rating
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
Rating
3.6 V
−0.3 V to +3.6 V
±5 mA
±20 mA
max) 150°C
J
−65°C to +150°C
260°C
300°C
1500 V
Rev. C | Page 5 of 72

THERMAL RESISTANCE

θ is specified for the worst-case conditions, that is, a device
JA
soldered in a circuit board for surface-mount packages.
Table 3. Thermal Resistance
Package Type
16-Lead QSOP

ESD CAUTION

ADT7473/ADT7473-1
θ θ Unit
JA JC
150 39 °C/W
