ABSOLUTE MAXIMUM RATINGS

Table 2.
Parameter
Positive Supply Voltage (V )
CC
Voltage on Any Input or Output Pin
Input Current at Any Pin
Package Input Current
Maximum Junction Temperature (T
Storage Temperature Range
Lead Temperature, Soldering
IR Reflow Peak Temperature
Lead Temperature (Soldering 10 sec)
ESD rating

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
Rating
3.6 V
−0.3 V to +3.6 V
±5 mA
±20 mA
) 150°C
JMAX
−65°C to +150°C
260°C
300°C
1500 V
Rev. 0 | Page 5 of 64
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.

THERMAL CHARACTERISTICS

16-lead QSOP package:
θ = 150°C/W
JA
θ = 39°C/W
JC
ADT7475
