1.2 System Features
The following views of the system display the main features. Refer to
specifications.
Front View
Node A
A0
A1
A2
A3
A4
Item
Description
0 - 5
2.5" hot-swap SATA drive bays (each node)
Drive Carrier Indicators
Each drive carrier has two LED indicators: an activity indicator and a status indicator. For RAID
configurations using a controller, the meaning of the status indicator is described in the table
below. For OS RAID or non-RAID configurations, some LED indications are not supported,
such as hot spare. For VROC configurations, refer to the
Color
Blue
Activity
Blue
LED
Off
Red
Red
Red
Status
Red
LED
Red
Node B
A5
B0
B1
B2
B3
B4
B5
Figure 1-1. Front View
Logical Storage Drive Numbers
Drive Carrier LED Indicators
Blinking Pattern
Behavior for Device
Solid On
Idle drive installed
Blinking
I/O activity
Idle SATA or no drive
Solid On
Failure of drive with RSTe support
Blinking at 1 Hz
Rebuild drive with RSTe support
Blinking at 4 Hz
Identify drive with RSTe support
Blinking with two blinks
Hot spare for drive with RSTe support
and one stop at 1 Hz
On for five seconds,
Power on for drive with RSTe support
then off
11
Node C
C0
C1
C2
C3
C4
C5
D0
VROC section
Chapter 1: Introduction
Appendix B
for additional
Node D
D1
D2
D3
D4
D5
in this manual.
