ME Recovery
JPME2 is used for ME Firmware Recovery mode, which will limit system resource for essential
function use only without putting restrictions on power use. In the single operation mode,
online upgrade will be available via Recovery mode.

4.5 LED Indicators

Network LAN LEDs
The Ethernet ports each have two LEDs. One LED indicates activity when flashing green.
The other may be green, amber or off to indicate the speed of the connection. .
Dedicated BMC LAN LEDs
A dedicated BMC LAN port is also included on the motherboard. The amber LED on the right
of the BMC LAN port indicates activity, while the LED color on the left indicates the speed
of the connection.
BMC Link LED
Color
Off
Green
Amber
ME Recovery
Jumper Settings
Jumper Setting
Pins 1-2
Pins 2-3
LAN LED (Speed Indicator)
Color Definition
Green 10Gbps
Amber 1Gbps
Off 100Mbps or less
Definition
Link LED
(speed)
No Connection
100 Mb/s
1 Gb/s
Chapter 2: Server Installation
Definition
Normal (Default)
ME Recovery
Activity LED
IPMI LAN
