Supermicro SuperServer SYS-210TP-HPTR User Manual page 152

Power Supply
SYS-210TP-HPTR
Model: PWS-2K04A-1R, 2000W dual redundant modules, 80Plus Titanium level
AC Input
100-127 Vac, 50-60 Hz
200-240 Vac, 50-60 Hz
+12V
2000W, 100A (100 Vac–127 Vac)
2000W, 183.3A (200 Vac–240 Vac)
5V standby: 1A
SYS-210TP-HPTRD
Model: PWS-2K04A-1R, 2000W dual redundant modules, 80Plus Titanium level
DC Input
2000W @ -44.1Vdc to -66Vdc
1600W @ -36Vdc to -44Vdc
+12V
2000W, 166A (-44.1Vdc to -66Vdc)
2000W, 133A (-36Vdc to -44Vdc)
5V standby: 6A
Operating Environment
Operating Temperature: 10º to 35º C (50º to 95º F)
Non-operating Temperature: -40º to 60º C (-40º to 140º F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
Regulatory Compliance
FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB
Certified Safety Models
Compliant with UL or CSA: 217-22 / 217H-R22X12 / 217TWP-X12
Appendix C: System Specifications
152
