1.1 Overview

This chapter provides a brief outline of the functions and features of the SuperServer
SYS-210TP-HPTR/HPTRD. The following provides an overview of the specifications and
capabilities.
Motherboard*
One X12SPT-PT
Chassis
CSE-217HQ+-R2K04BP4
Single 3rd Gen Intel Xeon Scalable processor, P+ (LGA4189) sockets; up to 270W TDP
Processor*
(thermal design power)
Eight DIMM slots, DDR4 RDIMM/LRDIMM or Intel Optane PMem 200 Series
Up to 3200MHz; size up to 256GB
Memory*
Note: PMem 200 Series are supported on 3rd gen Intel Xeon Scalable Platinum, Gold
and selected Silver processors.
Six hot-swap 2.5" drive bays (SATA)
Drive Support*
Two M.2 SSDs with carrier card included*
Expansion Slots*
Two PCIe 4.0 x16 (HH/HL)
Two 10G SFP+ ports
One dedicated IPMI port
I/O Ports*
One VGA port
One COM header port (internal header)
Two USB3.2 Gen1 ports
Four 8-cm heavy duty fans with Optimal Fan Speed Control
System Cooling
One air shroud, CPU heatsinks*
Dual 2000W redundant 80Plus Titanium level power supply modules
Power
Note: SYS-210TP-HPTR: AC power input, SYS-210TP-HPTRD: DC power input
Form Factor
2U rackmount; (WxHxD) 17.3" x 3.5" x 28.75" (438 x 88 x 730mm)
*Quantity shown is per node
A link to the Quick Reference Guide can be found on the product pages of the Supermicro
website.
The following safety models associated with the SYS-210TP-HPTR/HPTRD have been
certified as compliant with UL or CSA: 217-22 / 217H-R22X12 / 217TWP-X12.
