KEB COMBIVERT CONTROL G6 VARAN Programming Manual page 18

PROCeSS DATA MAPPING
Id-Text
fb17
Type
Meaning
Data length
Access
Coding
Note
Meaning
Data length
Access
Coding
Note
Id-Text
fb18
Type
Meaning
Data length
Access
Coding
Note
Meaning
Data length
Access
Coding
Note
18
Name
PD in offset
Array
Subindex 0
Number of subindices of this object
8 bit
read
8
Standard value: 8
-
Subindex 1...8
Specifies the offset of occupancy in the process data field. Posi-
tion of the
value of the mapped parameter.
8 bit
read / write
0...15
Standard value: 0
-
Name
PD in type
Array
Subindex 0
Number of subindices of this object
8 bit
read
8
Standard value: 8
-
Subindex 1...8
The value specifies the parameter type of the selected PD pa-
rameter.
8 bit
read / write
0: off (no parameter type defined)
1: Long (32bit)
2: Word (16bit)
3: Byte (8 bit)
Standard value: 0
-
Parameter index
0x2191
Parameter index
0x2192
