LIGHT-eMITTING DIODeS

8 Light-emitting Diodes

8.1 Status LeDs of VARAN plugs

Link LED
Active LED

8.2 Network status LeD

The LED located on the top of the device indicates the status of the VARAN client ap-
plication.
LED lights green
LED off
30
Green Lights up when connection consists between two PHYs.
Yellow Lights up when data are received over the VARAN bus.
Device runs synchron to the VARAN bus and process data are
available.
Device does not run synchronous to VARAN bus and/ or no
process data available.
