ISU 512e
ISDN Service Unit
Part Number 1203086L1
Document Number 61203086L1-1A
September 1999

Advertisement

Table of Contents
loading

Related Manuals for ADTRAN ISU 512e

Summary of Contents for ADTRAN ISU 512e

  • Page 1 ISU 512e ISDN Service Unit Part Number 1203086L1 Document Number 61203086L1-1A September 1999...
  • Page 2 Trademarks: DMS-100 is a trademark of Northern Telecom, Inc. 5ESS is a registered trademark of LUCENT. ISU is a trademark of ADTRAN, Inc. ExpertISDN is a trademark of ADTRAN, Inc. SunNet Manager is a registered trademark of Sun Microsystems, Inc.
  • Page 3 ADTRAN YEAR 2000 (Y2K) READINESS DISCLOSURE ADTRAN has established a Year 2000 program to ensure that our products and operations will correctly function in the new millen- nium. ADTRAN warrants that all products meet Year 2000 specifica- tions regardless of model or revision. Information about ADTRAN’s...
  • Page 4 FCC regulations require that the following information be pro- vided in this manual: 1. This equipment complies with Part 68 of the FCC rules. On the bot- tom of the equipment housing is a label that shows the FCC regis- tration number and Ringer Equivalent Number (REN) for this equipment.
  • Page 5 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Change or modifications to this unit not expressly ap- proved by ADTRAN will void the user’s authority to operate the equipment.
  • Page 6 CANADIAN EMISSIONS REQUIREMENTS This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference- causing equipment standard entitled "Digital Apparatus," ICES-003 of the Department of Communications. Cet appareil nuerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Class B prescrites dans la norme sur le materiel brouilleur: "Appareils Numeriques,"...
  • Page 7 CANADIAN EQUIPMENT LIMITATIONS Notice: The Canadian Industry and Science Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, ensure that it is permissible to be connected to the facilities of the local telecommunications company.
  • Page 8 AFFIDAVIT REQUIREMENTS FOR CONNECTION TO DIGITAL SERVICES • An affidavit is required to be given to the telephone company whenever digital terminal equipment without encoded analog content and billing protection is used to transmit digital signals containing encoded analog content which are intended for even- tual conversion into voiceband analog signals and transmitted on the network.
  • Page 9 AFFIDAVIT FOR CONNECTION OF CUSTOMER PREMISES EQUIPMENT TO 1.544 MBPS AND/OR SUBRATE DIGITAL SERVICES For the work to be performed in the certified territory of _________________________ (telco name) State of ___________________ County of __________________ I, _______________________________ (name), _________________________________ (business address), _________________________________ (telephone number) being duly sworn, state: I have responsibility for the operation and maintenance of the termi-...
  • Page 10 ( ) A. A training course provided by the manufacturer/grantee of the equipment used to encode analog signals; or ( ) B. A training course provided by the customer or authorized repre- sentative, using training materials and instructions provided by the manufacturer/grantee of the equipment used to encode analog sig- nals;...

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 Understanding ISDN and the ISU 512e ..1-1 ISDN Overview ......... .1-1 Product Overview .
  • Page 12 ISDN Menu/SPID ........6-3 ISU 512e User Manual...
  • Page 13 IP/Static Routes ........6-18 61203086L1-1 ISU 512e User Manual xiii...
  • Page 14 MPPP Authentication/Receive Username ... . . 6-27 MPPP Authentication/Receive Password ... . . 6-27 MPPP Authentication/Transmit Auth Type ... 6-27 ISU 512e User Manual 61203086L1-1...
  • Page 15 Ldm SlvMstr ......... .6-37 61203086L1-1 ISU 512e User Manual...
  • Page 16 ........Index-1 ISU 512e User Manual...
  • Page 17 Figure 1-1. ISU 512e Applications ......1-3 Figure 2-1. ISU 512e Rear Panel ......2-1 Figure 3-1.
  • Page 18 List of Figures xviii ISU 512e User Manual 61203086L1-1...
  • Page 19 Table A-2. EIA-232 Pinouts....... A-3 Table A-3. RS-366 Dialing Port Pinouts ....A-4 61203086L1-1 ISU 512e User Manual...
  • Page 20 List of Tables ISU 512e User Manual 61203086L1-1...
  • Page 21 20455512130100 LDN1 5551212 LDN2 5551213 To configure the ISU 512e from the front panel, press from the initial Enter status screen and continue entering the appropriate numbers (as shown below) until the switch protocol, SPIDs, and LDNs have been entered.
  • Page 22 Line 4 512 kbps SPID8/LDN8 To configure the ISU 512e using the VT 100 terminal interface, use the following procedure: Connect a VT 100 async terminal, or personal computer with a terminal emulator running 9600 8-N-1, to the EIA232 MAINT PORT.
  • Page 23 Expert ISDN feature. First enter the area code and local directory numbers; then select the specific line number or A , and press over the highlighted E Enter XPERT ISDN S field. TART 61203086L1-1 ISU 512e User Manual Quick Start-3...
  • Page 24 Quick Start Guide Quick Start-4 ISU 512e User Manual 61203086L1-1...

  • Page 25: Chapter 1 Understanding Isdn And The Isu 512E

    The ADTRAN ISDN Service Unit (ISU™) 512e is a standalone device that connects data terminal equipment (DTE) to the ISDN network. The ISU 512e is specifically designed as a low-cost solution for appli- cations such as video-conferencing, T1 backup, LAN/WAN connec- tivity, and high-speed file transfer.
  • Page 26 T1 circuit. Since ISDN is a switched digital service, bandwidth can be established and utilized on an as needed basis. Therefore, the ISU 512e is well suit- ed for applications where a high bandwidth connection is needed to support bursty or infrequent traffic like medical image or large file transfer.

  • Page 27: Ordering Isdn

    These IOCs are supported by all major local exchange carriers as well as several independent carriers. Capability S (previously Generic Data M) ordering code is recom- mended for ISU 512e applications. It is the most feature-rich and sup- ports most voice and data applications. The voice capability is not 61203086L1-1...
  • Page 28 Chapter 1. Understanding ISDN and the ISU 512e necessary for operation of the ISU 512e; however, it is useful in trou- bleshooting a misconfigured ISDN line. In some areas, ISDN tariffs may warrant the use of ordering codes with less features. For example, in a particular region, there may be additional monthly expense asso- ciated with having voice service on each B channel.

  • Page 29: Chapter 2 Installation

    NETWORK CONNECTION The ISU 512e supports either dial or leased operation. Four 8-pin RJ-45 modular jacks on the rear panel of the ISU 512e allow connection to the network service. (See Figure 2-1.) Figure 2-1. ISU 512e Rear Panel Dial operation uses the ISDN Basic Rate interface and allows the ISU 512e to dial out over the ISDN network.

  • Page 30: Dte Data Connection

    DTE DATA CONNECTION Data terminal equipment (DTE) is connected to the ISU 512e by using the V.35 interface on the rear panel of the ISU 512e. The maximum ca- ble length recommended is 150 feet for the V.35 interface. The pin as- signments for the V.35 interface are shown in Appendix A Pinouts on...

  • Page 31: Dial Interface Connection

    EIA-366 connector, see Appendix A Pinouts on page A-1. Smart Dial String Formats The ISU 512e can accept changes to C and C HANNEL using suffix commands appended to the end of the dial string. The fol- lowing string format is used.

  • Page 32: Software Update

    HANNELS If no suffix is used, the call is placed using the values configured for the ISU 512e. For example, if the ISU 512e is configured for 384K, the dial string 7082906055 is the same as 7082906055#4#6. If the C suffix is used, the C suffix is required.
  • Page 33 512e once the C’s appear on the screen. 1K XMODEM can be used at the 57600 rate only. Power ON the ISU 512e while holding the up arrow for a down- load speed of 57600, or the down arrow for 9600. Holding the up or down arrow during self test initiates the software update.
  • Page 34 Chapter 2. Installation ISU 512e User Manual 61203086L1-1...

  • Page 35: Chapter 3 Operation

    Operation Chapter 3 MENU STRUCTURE The ISU 512e uses a multilevel menu structure to access its configura- tion options and activate its feature set. The menu structure can be ac- cessed in several ways: • Through the front panel (see Front Panel and Front Panel Menu on page 3-8).

  • Page 36: Terminal Menu Description

    Status The S menu provides options to review and monitor TATUS the status of the ISU 512e system. See Chapter 4 Status Menu on page 4-1 for detailed information on the available options. Test The T menu can be used for performing both local and re- mote diagnostic testing of the ISU 512e.
  • Page 37 Right Pane - Lists available sub- Menu Path - Describes the menus. Additional submenus avail- current position in the ter- able through this pane are indicated minal menu structure. by the [+] symbol. Left Pane - Lists available menus. DSL Status - Displays Navigation Help - Displays list of current status of each characters you can use to navigate the...

  • Page 38: Terminal Menu Navigation

    Escape be used to go back up the menu tree until a SAVE screen is reached. The changes are only saved PARAMETER after this screen is displayed and a response of (yes) is entered. ISU 512e User Manual 61203086L1-1...

  • Page 39: Navigation With The Keyboard

    Also will dismiss the pop-up help screens. moves between the left and right panes. moves to the top of a screen. moves to the bottom of a screen. Backspace ascends one menu level. 61203086L1-1 ISU 512e User Manual...

  • Page 40: Table 3-3. Session Management Keystrokes

    Password prompt will display. Control-R refreshes the screen. To save time, only the portion of the screen that has changed is refreshed. This option should be necessary only if the display picks up incorrect characters. ISU 512e User Manual 61203086L1-1...

  • Page 41: Table 3-4. Configuration Keystrokes

    ONNECTION the cursor is over the index number. deletes a list item. For example, delete an item from the C ONNECTION pressing while the index number is active. 61203086L1-1 ISU 512e User Manual...

  • Page 42: Front Panel And Front Panel Menu

    Figure 3-2. ISU 512e Front View Front Panel Description The ISU 512e front panel consists of a 2-line, 16-character LCD display, 7 LED indicators, and a 16-button keypad. This allows for configuring most options, dialing, testing, and monitoring the unit without data terminal or test equipment.

  • Page 43: Self Test

    Data set ready. Self Test The ISU 512e performs an initial self test upon powerup. Once the self test is successfully completed, the current status mode is displayed by the front panel. If the ISU 512e is not connected to the network, the S TATUS menu displays DOWN next to the network connection number.

  • Page 44: Front Panel Menu Navigation

    Figure 3-4. Figure 3-4. Front Panel Top-Level Menu Four function keys on the ISU 512e keypad allow the various menu branches to be entered, exited, and scrolled through. Table 3-6 de- scribes these function keys.
  • Page 45 ONFIG OPTIONS PTIONS It is important to note that some features in the ISU 512e do not imme- diately take effect upon selection. This prevents unintentional recon- figuration of the ISU 512e during an active call. Items such as L...
  • Page 46 Chapter 3. Operation 3-12 ISU 512e User Manual 61203086L1-1...

  • Page 47: Chapter 4 Status Menu

    Status Menu Chapter 4 Figure 4-1 shows the S menu as it appears on the terminal TATUS screen. Figure 4-1. Status Terminal Menu 61203086L1-1 ISU 512e User Manual...

  • Page 48: Status/Status Buffer

    TATUS UFFER by the ISU 512e during operation. Appendix B Status Buffer Messages on page B-1 contains an explanation of the status buffer messages. The Status buffer is the only S menu item displayed...

  • Page 49: System Info/System Name

    System Info/System Location This provides a user configurable text string for the location of the ISU 512e. This helps to keep track of the physical location of the unit. You can enter up to 31 alpha-numeric characters in this field, includ- ing spaces and special characters (such as an under bar).

  • Page 50: System Info/Loop Status

    Chapter 4. Status Menu System Info/Loop Status The ISU 512e displays the current loop status for each ISDN line both here and on the bottom, center line of the terminal screen. Appendix C Loop Status Messages on page C-1 gives an explanation of the loop status messages.

  • Page 51: System Info/Li

    System Info/LI This field displays the link integrity of the 10BaseT Ethernet port and corresponds to the green LED on the Ethernet connector. It indicates that there is a good physical connection between the ISU 512e and the LAN. STATUS/ARP CACHE This S submenu lists the contents of the ISU 512e’s Address Res-...

  • Page 52: Ip Routes/Netmask

    ISU 512e IP stack eth0 ISU 512e’s Ethernet port IP Routes/Use This is the number of times the ISU 512e has referenced the route. IP Routes/Flags These are important tags associated with the route entry: route is a host route...

  • Page 53: Ip Routes/Ttl

    “zombied.” A value of 999 means route is static. STATUS/EXIT Activating this feature will exit the terminal session from the mainte- nance port or Telnet. It is equivalent to the key combination Control L 61203086L1-1 ISU 512e User Manual...
  • Page 54 Chapter 4. Status Menu ISU 512e User Manual 61203086L1-1...

  • Page 55: Chapter 5 Test Menu

    Figure 5-1. Test Front Panel Menu See System Info/NEBE/FEBE on page 4-4 and System Info/ Firmware Revision on page 4-3 for descriptions of the last two menu items in Figure 5-1. Figure 5-2. Test Terminal Menu 61203086L1-1 ISU 512e User Manual...

  • Page 56: Test/Test Status

    Figure 5-3. ISU 512e Loopback Points TEST/2047 CHECKER The ISU 512e has the ability to generate and check a 2047 BERT pat- terns through the BONDING protocol. This allows 2047 BERT pat- terns to be run on multiple ISDN connections (through BONDING).
  • Page 57 In addition, the ISU 512e can loop back a remote unit automatically at the start of a BONDING call and run the 2047 pattern. This is accom- plished through a smart dial string: <number>...
  • Page 58 Chapter 5. Test Menu ISU 512e User Manual 61203086L1-1...

  • Page 59: Chapter 6 Configuration Menu

    Figure 6-1. Configuration Terminal Menu CONFIGURATION/NETWORK OPTIONS The N menu (see Figure 6-2 on page 6-2) is used to set ETWORK PTIONS up the ISDN parameters for the ISU 512e. 61203086L1-1 ISU 512e User Manual...

  • Page 60: Network Options/Line Mode

    ISDN Menu/Switch Protocol Find out what kind of ISDN switch protocol the local CO is using by asking the local telephone administrator or the tele- phone company representative. The ISU 512e can be config- ured for the following: 5ESS ®...

  • Page 61: Isdn Menu/Area Code

    ISDN line is configured. For instance, there are no SPIDs for a point-to-point line. Multipoint lines may have one or two SPIDs. The ISU 512e uses the presence of SPID 1 to determine whether the line is multipoint. If the line has only one SPID, then it must be entered in SPID 1, SPID 3, SPID 5, and SPID 7, depending on the number of lines being installed.

  • Page 62: Isdn Menu/Ldn

    Status buffer. The message E ISDN P appears when Ex- ASSED pertISDN has determined the SPIDs for each line. See Appendix B Status Buffer Messages on page B-1 for additional messages and their explanations ISU 512e User Manual 61203086L1-1...

  • Page 63: Expertisdn/Line

    Mu-law/ PEECH A-law speech circuit as the bearer capability for outgoing calls. The S option is used with an ISDN line configured for PEECH voice service. In some areas voice service costs less than data 61203086L1-1 ISU 512e User Manual...

  • Page 64: Call Type/Audio

    64 kbps data circuit. Dial Line/Dial Options Dial Options/Mode The ISU 512e can be configured to dial using the F RONT ANEL (def), EIA-366 parallel dialing port, or V.25. To establish and...

  • Page 65: Dial Options/V.25 Options

    LAGS DTE interface using standard synchronous HDLC V.25 bis commands with 7E HEX idle. The ISU 512e supports V.25 bis in-band dialing in accordance with Fascicle VIII.I - V.25 bis (Malaga-Torremolinos 1984, Melbourne 1988). Recommendation V.25 uses the following DCE/DTE control signals:...

  • Page 66: Dial Options/Eia-366 Timing

    Dial Options/EIA-366 Timing EIA-366 dialers can end a string of dialed numbers by sending the end of number (EON) to alert the ISU 512e that the entire number has been sent. Another method is to stop sending numbers and allow the ISU to time out, then dial the number.

  • Page 67: Dial Options/Eia-366 Security

    For more information on this option, contact ADTRAN Technical Support (see the last page of this manual). Dial Line/Auto Answer The ISU 512e can be configured to automatically answer or not an- swer. Auto Answer/Disabled When D...

  • Page 68: Dial Line/Connect Timeout

    Chapter 6. Configuration Menu Dial Line/Connect Timeout This option sets the length of time that the ISU 512e waits for a far-end unit to answer an outgoing call. The default is 30 seconds. Dial Line/Call Screening allows the ISU 512e to answer all incoming calls by...

  • Page 69: Dial Line/Line Passwords (Remote Access)

    EMOTE feature. Do not download software from an OWNLOAD ISU 512 to an ISU 512e or vice versa. The unit will not function properly. SPV Password (Remote Supervision) The ISU 512e has the ability to be remotely accessed and con- figured from another ISU 512e.

  • Page 70: Dial Line/Call Number Id

    Chapter 6. Configuration Menu The ISU 512e can be protected from illegal access by using the password protection built into the remote protocol. The smart dial string format for this type of call is as follows: <number>#6#<password> For example, the dial string 9224323#6#4321 places a remote supervisory call to the remote unit and sends the 4321 string as the SPV password.

  • Page 71: Network Options/Leased Line

    ASTER see Figure 6-4 on page 6-14. To easily configure ISU 512e’s for this ap- plication, all three leased mode configurations are available on the menu. For more information, see Quick Setup Configura-...

  • Page 72: Leased Line/Channel Rate

    Once line 1 is connected, the ISU 512e will wait for all lines required to achieve the maximum bit rate to show READY. If this does not occur, the ISU 512e will time out and place a call using all the available lines once line 1 becomes READY.

  • Page 73: Configuration/V.35 Options

    (see Figure 6-5) is used to select the configu- PTIONS ration parameters that control the operation of the DTE interface port of the ISU 512e. Figure 6-5. V.35 Options Menu V.35 Options/Maximum Bit Rate This field sets the maximum bit rate at which the V.35 operates. There are eight multiples of 64K (64K through 512K) and eight multiples of 56K (56K through 448K).

  • Page 74: V.35 Options/Cd Options

    U-interface is not present. V.35 Options/DTR Options Selecting I DTR (def) causes the ISU 512e to disregard the state GNORE of the DTR pin. I forces the unit to end the current call DLE WHEN when DTR is no longer asserted.

  • Page 75: Configuration/Ip Options

    This address must be unique within the network. The factory default is 10.0.0.1. IP/Subnet Mask The IP network mask to be applied to the ISU 512e’s Ethernet port is set here. The factory default is 255.255.255.0. IP/Default Gateway The default gateway is used by the ISU 512e for sending IP packets whose destination address is not found in the route table.

  • Page 76: Ip/Static Routes

    This is the IP address of the router to receive the forwarded IP packet. Static Routes/Hops This is the number of router hops required to get to the network or host. Maximum distance is 15 hops. 6-18 ISU 512e User Manual 61203086L1-1...

  • Page 77: Ip/Rip

    RIP/V2 Secret This is a text string used for authenticating advertised routes. IP/Utilities The ISU 512e has utilities embedded in it to help manage and test the network and to facilitate software upgrades. Utilities/Ping This option is not available from the front panel.

  • Page 78: Utilities/Upgrade

    (read only). Utilities/Upgrade This option is not available from the front panel. The ISU 512e’s firmware can be upgraded using this menu. Upgrade/Transfer Method TFTP (Trivial File Transfer Protocol) requires a TFTP server running somewhere on the network. The ISU 512e starts a TFTP client function which gets the upgrade code from the TFTP server.

  • Page 79: Upgrade/Status

    Use this activator to cancel any TFTP transfer in progress. CONFIGURATION/PROTOCOL OPTIONS The ISU 512e communicates with many different types of telecommu- nication equipment. The ISU 512e supports both the IETF standards for the Multilink Point-to-Point protocol (MPPP) and the BONDING Mode 1 (Bandwidth on Demand Interoperability Group) adaptation protocol.

  • Page 80: Protocol/Bonding

    ISU 512e’s, ISDN TE/ TA’s, and inverse multiplexing equipment supporting the BONDING protocol. When the ISU 512e uses the BONDING Mode 1 protocol, up to eight separate ISDN phone calls are placed to seize control of all re- quired ISDN bearer channels.

  • Page 81: Txdeq

    Call Stagger This option specifies the amount of delay placed between calls. The default setting is 0 (no delay). Values of 0 (def), 100 , 200 , and 2 can be selected. SECOND SECONDS 61203086L1-1 ISU 512e User Manual 6-23...

  • Page 82: Protocol/Mppp

    Point-to-Point protocol (PPP). It provides a method for splitting, recombining, and sequencing datagrams across multiple logical data links. In the case of the ISU 512e, the eight ISDN bearer channels constitute the MPPP logical data links. MPPP options are only available from the terminal menu.

  • Page 83: Fragment

    If this option is set to O , or if BACP is not negotiated with the peer, the ISU 512e will dial the original number to gain the additional band- width. If the ISU 512e is unsuccessful three times in gaining additional bandwidth, the DTE rate will be set to equal the network data rate for the duration of the call.

  • Page 84: Mppp Authentication/Receive Auth Type

    If the peer is not capable of EAP , then the connection is terminated. MPPP Authentication/Receive Auth Timing The ISU 512e can be configured to authenticate the peer (using the above method) for incoming calls using A NSWER (def), or for outgoing and incoming calls using O...

  • Page 85: Mppp Authentication/Receive Username

    This is the password or secret that is used to authenticate the peer. MPPP Authentication/Transmit Auth Type This parameter specifies how the ISU 512e is to be authenticat- ed by the peer. The possible values are: The ISU 512e will not allow the peer to authenticate it.

  • Page 86: Configuration/Management

    Protocol (SNMP), or the maintenance port. SNMP support is limited to MIB definitions. See Appendix E SNMP on page E-1 for a description of the MIBs supported by the ISU 512e. Each of the three methods can be protected using authentication. Figure 6-8 shows the Management Menu.

  • Page 87: Telnet/Server Access

    Turning it O means that access is denied. Telnet/User List Up to four users can be configured for access to the ISU 512e. Each user can be assigned a privilege and time out. User List/Name A text string of the user name for this session.

  • Page 88: Communities/Name

    SNMP manager can access the ISU 512e for this community. SNMP/Traps The ISU 512e can generate SNMP traps. See Appendix E SNMP on page E-1 for trap types supported. This list allows up to four managers to be listed to receive traps.

  • Page 89: Management/Maint Port

    Chapter 6. Configuration Menu Management/Maint Port The ISU 512e has an EIA232 MAINT PORT connector on the back of the unit. The setup for that port is under this menu. Maint Port/Password Protect When set to O , the maintenance port is not password protected.

  • Page 90: Configuration/Terminal Mode

    MPPP negotiation to the terminal screen QUICK SETUP CONFIGURATION To aid in configuring the V.35 options for the ISU 512e, many common configurations are preset for Q . These include various dial UICK ETUP and leased options.

  • Page 91: Factory Default

    S message is displayed on ASSED the front panel. 512K MP When the ISU 512e is configured for 512K MP, the following parameters are automatically preset: Service type ISDN dial line Automatic answering Enabled...

  • Page 92: 512K Bonding

    Chapter 6. Configuration Menu 448K MP When the ISU 512e is configured for 448K MP, the following parameters are automatically preset: Service type ISDN dial line Automatic answering Enabled ISDN call type 64 kbps data Dial options Front panel Maximum bit rate...

  • Page 93: 448K Bonding

    Chapter 6. Configuration Menu 384K BONDING When the ISU 512e is configured for 384K B , the fol- ONDING lowing parameters are automatically preset: Service type ISDN dial line Automatic answering Enabled ISDN call type 64 kbps data Dial Options...

  • Page 94: 336K Bonding

    Chapter 6. Configuration Menu 336K BONDING When the ISU 512e is configured for 336K B the fol- ONDING lowing parameters are automatically preset: Service type ISDN dial line Automatic answering Disabled ISDN call type 56 kbps data Dial options Front panel...

  • Page 95: Leased Master

    Chapter 6. Configuration Menu Leased Master When the ISU 512e is configured for L the fol- EASED ASTER lowing parameters are automatically preset: Service type Leased Line Automatic answering Enabled Maximum bit rate 512 kbps data DTR options Ignore Clock mode...
  • Page 96 Chapter 6. Configuration Menu 6-38 ISU 512e User Manual 61203086L1-1...

  • Page 97: Chapter 7 Dial Menu

    ANG UP LINE IAL NUMBER EDIAL LAST NSWER TORED TORE EVIEW Figure 7-1. Dial Front Panel Menu Figure 7-2. Dial Terminal Menu 61203086L1-1 ISU 512e User Manual...

  • Page 98: Enter Number

    Enter number to dial the number REDIAL LAST NUMBER Allows redial of the last number called or attempted. ANSWER CALL Allows selective answer of incoming calls when A is dis- NSWER abled. ISU 512e User Manual 61203086L1-1...

  • Page 99: Dial Stored Number

    If a mistake is made, Enter press to clear the line and allow another attempt. Cancel Press twice in succession to exit without changing Cancel the selected stored number. 61203086L1-1 ISU 512e User Manual...
  • Page 100 Chapter 7. Dial Menu ISU 512e User Manual 61203086L1-1...

  • Page 101: Chapter 8 Troubleshooting

    Support (see the last page of this manual). IF AN ISDN NETWORK LINE READS DOWN When the ISU 512e has been set up and connected to ISDN lines, and the front panel displays D for any of the network ISDN lines, use...
  • Page 102 G. With a minimum of extra wiring, try connecting to the line pair at the point where service provider's wiring ends. H. With the ISU 512e connected to the ISDN line and pow- ered up, contact and inform the service provider's repair group that your ISDN basic rate line has a Physical Layer 1 problem.

  • Page 103: If The Display Reads Tei1

    Chapter 8. Troubleshooting IF THE DISPLAY READS TEI1 If the ISU 512e reads TEI1, then the ISU 512e is physically connected to the local telephone service provider but is unable to establish Logi- cal Layer 2. The problem is in one or more of the following places: •...

  • Page 104: If The Display Reads Tei2

    ISDN line. IF THE DISPLAY READS TEI2 If the ISU 512e continues to read TEI2, the ISU 512e has completely ini- tialized the first phone number but is unable to establish Logical Layer 2 for the second phone number. The problem is in one or more of the following places: •...

  • Page 105: If The Display Reads Spid<1,3,5, Or 7

    If the ISU 512e reads SPID1, then the ISU 512e is physically connected to the local telephone service provider and has established Logical Layer 2. The ISU 512e is unable to establish Layer 3. The problem is with one or more of the following: •...
  • Page 106 Chapter 8. Troubleshooting Ensure that the ISU 512e is set up with the correct SPIDs and LDNs. Try swapping SPID1 with SPID2 and LDN1 with LDN2, SPID3 with SPID4 and LDN3 with LDN4, SPID5 with SPID6 and LDN5 with LDN6, and SPID7 with SPID8 and LDN7 with LDN8. Deter- mine whether the problem is the second phone number or the quantity of phone numbers.

  • Page 107: Chapter 9 Specifications Summary

    Specifications Summary Chapter 9 SPECIFICATIONS AND FEATURES This section describes the standard specifications and features incor- porated in the ISU 512e. Network Interface Four RJ-45s for ISDN Basic Rate Interface DTE Interface V.35 Dialing Selections • Manual or automatic stored number dialing from the front panel •...

  • Page 108: Protocols Supported

    ° • Storage temperature: 20 to 70 C (- 4 to 158 • Relative humidity: Up to 95%, non-condensing Physical 2.25" H, 8.75" W, 11.00" D Power 90-250 VAC, 50-60 Hz, 8-15, 5W maximum dissipation ISU 512e User Manual 61203086L1-1...

  • Page 109: Appendix A Pinouts

    Pin 5 ISDN Figure A-1. RJ-45 ISDN Line Interface V .35 Figure A-2. V.35 Connector (See Table A-1 on page A-2.) Pin 1 10 BASE T Pin 2 Pin 3 Pin 6 Figure A-3. 10BaseT Connector 61203086L1-1 ISU 512e User Manual...

  • Page 110: Table A-1. V.35 Pinouts

    No Connection No Connection No Connection No Connection No Connection No Connection No Connection No Connection No Connection No Connection No Connection I= Input, O= Output, N/A= Not Applicable See Figure A-2 on page A- 1. ISU 512e User Manual 61203086L1-1...

  • Page 111: Figure A-4. Eia-232 And Rs-366 Connector

    No Connection No Connection Transmit Clock No Connection Receive Clock No Connection No Connection Data Terminal Ready No Connection No Connection No Connection ETC-A External Transmit Clock No Connection I= Input, O= Output, N/A= Not Applicable 61203086L1-1 ISU 512e User Manual...

  • Page 112: Table A-3. Rs-366 Dialing Port Pinouts

    Abandon Call and Retry Call Request Present Next Digit Power Indication Signal Ground Distant Station Connect Digit LSB Digit bit 2 Digit bit 3 Digit MSB Data Line Occupied I= Input, O= Output, N/A= Not Applicable ISU 512e User Manual 61203086L1-1...

  • Page 113: Appendix B Status Buffer Messages

    Area Code Req’d ExpertISDN was activated without entering the area code. Authen failed The PPP peer has rejected the ISU 512e’s username and/or password used for authentication. Make sure the T and T SERNAME are correctly entered.
  • Page 114 ExpertISDN has determined that the switch protocol is National ISDN Bad call type ISU 512e placed a call with an improper call type. Bad DTE mode The DTE bit rate does not match a valid bit rate for the protocol select-...
  • Page 115 BUSY The called number is busy. CallID 1 in use ISU 512e tried to place a call using SPID 1 though SPID 1 was already in use. CallID 2 in use ISU 512e tried to place a call using SPID 2 though SPID 2 was already in use.
  • Page 116 Received an incoming call from a third party during negotiations with a far end BONDING unit on the use of the second Bearer channel. DEST NOT ISDN The number called is not ISDN (warning only). DEST_OUT_OF_ORDER The called number is out of order. ISU 512e User Manual 61203086L1-1...
  • Page 117 The DTE equipment is not optioned for the same bit rate as the ISU 512e for V.25 bis dialing. DTR not up ISU 512e tried to place a call in a dialing mode that requires DTR to be in an active state but it is not. Dump call ISU 512e could not accept an incoming call because it was already in- volved in a call.
  • Page 118 Expert ISDN is attempting another SPID format. ExpertISDN Stop The ExpertISDN process was stopped by the user. FACILITY_NOT_IMP The network does not support the requested supplementary service. FACILITY_REJECTED A facility requested by the user cannot be provided by the network. ISU 512e User Manual 61203086L1-1...
  • Page 119 The called number cannot accept the type of call that has been placed. INTRWORKING _UNS A message was sent by a far-end network that was not understood. INVALID_CALL_REF Call control error. INVALID_ELEM_CON Call control error. 61203086L1-1 ISU 512e User Manual...
  • Page 120 L2 #<1- 8> not up The data link layer interface for the call number shown (BONDING) is not active. L3 #<1- 8> not up The call control layer interface for the call number shown (BONDING) is not active. ISU 512e User Manual 61203086L1-1...
  • Page 121 After three tries to increase network bandwidth to match the DTE bit rate, the protocol set the DTE rate to match the network rate. Negotiation fail The BONDING negotiation has failed. NETWORK BUSY The ISDN switch is busy and unable to process a call. 61203086L1-1 ISU 512e User Manual...
  • Page 122 NO_USER_RESPONDI The dialed number is not responding. NORMAL_CLEARING The network is disconnecting the current call. NOT end2end ISDN The path that the call was routed over is not ISDN from end-to-end (warning only). B-10 ISU 512e User Manual 61203086L1-1...
  • Page 123 The network will not allow the outgoing call to be placed. Peer failed authen The PPP peer’s reported username and/or password does not match the ISU 512e’s authentication parameters. This is most likely caused by the peer sending an incorrect username and/or password. Make sure that the R and R are correctly entered.
  • Page 124 SPID DL Stop <1-4> Lucent SPID download was disabled. SPID DL Unavail Lucent SPID download is not available from this ISDN switch. SPID SL <1-4> Lucent SPID download feature has started on this dsl. B-12 ISU 512e User Manual 61203086L1-1...
  • Page 125 Appendix B. Status Buffer Messages TANULL expired Bonding timer TANULL expired; non BONDING equipment attempt- ed to call into the ISU 512e while optioned for BONDING. TEMPORARY_FAILURE The network has temporarily failed; try the call again. TIMER_EXPIRY Call control error.
  • Page 126 Received a cause message from the network that is not understood. USER_BUSY The dialed number is busy. WRONG_MESSAGE The ISU 512e received a message that does not match the valid mes- sages defined for the switch. WRONG_MSG_FOR_ST The ISU 512e received a message that is not appropriate for the state of the call.

  • Page 127: Appendix C Loop Status Messages

    The ISU 512e has completed protocol negotiation with the network switch and is ready to place/receive calls. <1,2,3,4>:PLBBK The ISU 512e has been set to perform a loopback in the network direc- tion after letting the incoming data pass through the BONDING pro- tocol.
  • Page 128 <1-4>:SPID2 The ISU is registering its second SPID with the network. <1,2,3,4>:Sync The ISU 512e has successfully activated to the network but is still wait- ing for the switch to issue the ACT bit. <1-4>:TEI1 The ISU is receiving the first Terminal Endpoint Identifier (TEI) from the network.
  • Page 129 BONDING Setup BONDING Mode 1 rate adaption protocol is negotiating with the far end unit. CALL <xxxxxxx> The ISU 512e is calling phone number <xxxxxxx>. Call Connect B1 Bearer channel 1 connected and is currently active. Call Connect B2 Bearer channel 2 connected and is currently active.
  • Page 130 Appendix C. Loop Status Messages ISU 512e User Manual 61203086L1-1...

  • Page 131: Appendix D Front Panel Configuration Menu

    5ESS UCENT 2=DMS-100 ISDN1 ATIONAL 4=NI-1 E NBLOC SPID ISDN XPERT 1=DSL 1 2=DSL 2 3=DSL 3 4=DSL 4 TART OWNLOAD NABLED ISABLED ALL TYPE PEECH UDIO Figure D-1. Config/Netw. Options/Dial Line Front Panel Menu 61203086L1-1 ISU 512e User Manual...
  • Page 132 NABLED UMP ALL CALLS ONNECT IMOUT 1=15 2=30 MINUTE MINUTE MINUTE CREENING NSWER ANY SN0...9 ANSR IF ASSWORDS 1=SPV P ASSWORD 2=RDL P ASSWORD NABLED ISABLED Figure D-1. Config/Netw. Options/Dial Line Front Panel Menu (continued) ISU 512e User Manual 61203086L1-1...

  • Page 133: Figure D-2. Config/Netw. Options/Leased Line

    Appendix D. Front Panel Configuration Menu ONFIG OPTIONS EASED LOCK MODE LAVE ASTER LAVE ASTER HANNEL RATE 1=56K B EARER 2=64K B EARER EMOTE NABLED ISABLED Figure D-2. Config/Netw. Options/Leased Line Front Panel Menu 61203086L1-1 ISU 512e User Manual...

  • Page 134: Figure D-3. Config/V.35 Options Front Panel Menu

    PTIONS ORCED OLLOW OLLOW V.25 ANSR 3=CD O PTIONS 1=CD F ORCED ORMAL 4=DTR O PTIONS GNORE DLE WHEN >O NSWER IF 5=DSR O PTIONS 1=DSR F ORCED Figure D-3. Config/V.35 Options Front Panel Menu ISU 512e User Manual 61203086L1-1...

  • Page 135: Figure D-4. Config/Ip Options Front Panel Menu

    3=IP O PTIONS 1=IP A DDRESS UBNET ATEWAY Figure D-4. Config/IP Options Front Panel Menu ONFIG ROTOCOL PTIONS ULTILINK ONDING 1=TXINT 2=TXFA 3=TXADD01 4=TXDEQ 5=TANULL 6=TCID TAGGER RANSPARENT Figure D-5. Config/Protocol Options Front Panel Menu 61203086L1-1 ISU 512e User Manual...

  • Page 136: Figure D-6. Config/Maint Setup Options Front Panel Menu

    Figure D-6. Config/Maint Setup Options Front Panel Menu ONFIG UICK ETUP ACTORY 2=512K MP 3=448K MP 4=512K BONDING 5=384K BONDING 6=448K BONDING 7=336K BONDING EASED LAVE EASED ASTER 0=LDM S Figure D-7. Configuration/Quick Setup Options Front Panel Menu ISU 512e User Manual 61203086L1-1...

  • Page 137: Appendix E Snmp

    The agent in that device interprets the incoming request, performs the requested task, and sends its response to the network manager. The network manag- 61203086L1-1 ISU 512e User Manual...
  • Page 138 These messages are typically encased within informational packets and transported over the LAN or WAN. SNMP EMBEDDED AGENT The ISU 512e supports the following groups from MIB-II (RFC 1213): • System Group • UDP Group •...
  • Page 139 Up to four hosts can be set to receive traps. Each host entry requires an IP address of the manager. In addition to the cold start trap, the ISU 512e sends traps each time a link is brought up or down.
  • Page 140 Appendix E. SNMP ISU 512e User Manual 61203086L1-1...

  • Page 141: Acronyms

    EKTS......Electronic Key Telephone Service ESS ......Electronic Switching System FAX ......Facsimile FEBE......Far End Block Errors FX .......Foreign Exchange ICMP ......Internet Control Message Protocol ID .......Identification IETF ......Internet Engineering Task Force I/O ......Input/Output IOC......ISDN Ordering Codes IP ........Internet Protocol 61203086L1-1 ISU 512e User Manual Acronyms-1...
  • Page 142 POTS ......Plain Old Telephone Service RFC ......Request for Comments RIP ......Routing Information Protocol SNMP ......Simple Network Management Protocol SPID......Service Profile Identifier TA.......Terminal Adapter TE .......Terminal Equipment TEI......Terminal Endpoint Identifier TFTP ......Trivial File Transfer Protocol WAN ......Wide Area Network Acronyms-2 ISU 512e User Manual 61203086L1-1...

  • Page 143: Glossary

    Bearer services defined for ISDN are circuit mode and packet mode. BONDING protocol Industry standard B channel aggregation protocol. Developed by the Bandwidth on Demand Interoperability Group. 61203086L1-1 ISU 512e User Manual Glossary-1...
  • Page 144 CSMA/CD is used by Ethernet and IEEE 802.3. Channel service unit. A component of CPE used to terminate a digital circuit, such as DDS or T1 at the customer site. Performs Glossary-2 ISU 512e User Manual 61203086L1-1...
  • Page 145 DCE and DTE is that pins 2 and 3 are reversed on the RS- 232. EIA-232 An EIA-specified physical interface with associated electrical sig- naling between DCE and DTE. The most commonly employed interface between computer devices and modems. 61203086L1-1 ISU 512e User Manual Glossary-3...
  • Page 146 An IEEE LAN protocol that specifies an implementation of the LLC sublayer of the data link layer. It handles errors, framing, flow control, network layer (Layer 3) service interface, and is used in LANs. Glossary-4 ISU 512e User Manual 61203086L1-1...
  • Page 147 The slight movement of a transmission signal in time or phase that can introduce errors and loss of synchronization for high-speed synchronous communications. See phase jitter. 61203086L1-1 ISU 512e User Manual Glossary-5...
  • Page 148 Typically, user data streams are interleaved on a bit or byte basis (time divi- sion) or separated by different carrier frequencies (frequency divi- sion). Glossary-6 ISU 512e User Manual 61203086L1-1...
  • Page 149 Routing Information Protocol. A protocol used to exchange rout- ing information among a set of computers connected by a LAN. RIP uses hop counts as a routing metric. 61203086L1-1 ISU 512e User Manual Glossary-7...
  • Page 150 T interface T reference point Performs the same function as the S interface but uses an NT1 rather than an NT2. Glossary-8 ISU 512e User Manual 61203086L1-1...
  • Page 151 20 seconds) or full motion. Bandwidth require- ments for two-way videoconferencing range from 6 MHz for analog, full-motion, full-color, commercial grade TV to 56 kbps for digitally-encoded freeze-frame to 1.544 kbps for very good quality, full-color, full-motion TV. 61203086L1-1 ISU 512e User Manual Glossary-9...
  • Page 152 (a NAK - negative acknowledgment) to retransmit that block once again. If the block checks out, the com- puter sends ACK (an acknowledgment). In this way, relatively er- ror-free transmission can be accomplished. Glossary-10 ISU 512e User Manual 61203086L1-1...

  • Page 153: Index

    448K BONDING 6-35 bit error rate test (BERT) 5-2 448K MP 6-34 bit rate 3-11 512K BONDING 6-34 BONDING Mode 1 protocol 6-22 512K MP 6-33 BONDING protocol 5-2 factory default 6-33 bonding setup 3-11 6-21 61203086L1-1 ISU 512e User Manual Index-1...
  • Page 154 56 kbps 6-6 data 64 kbps 6-6 data bits 6-31 EIA-232 data rates 9-1 pinouts A-3 data set ready 3-9 EIA-366 default gateway 6-17 dialing 6-6 dial interface connection 2-3 out of band 2-3 Index-2 ISU 512e User Manual 61203086L1-1...
  • Page 155 2-1 features 9-1 if self test fails 8-1 installation 2-1 if the display reads leased operation 2-1 SPID{1,3,5, or 7} 8-5 menu structure 3-1 SPID{2,4,6, or 8} 8-5 operation 3-1 TEI1 8-3 61203086L1-1 ISU 512e User Manual Index-3...
  • Page 156 6-31 auth type 6-27 maint port/data bits 6-31 MPPP authentication/transmit maint port/parity 6-31 password 6-27 maint port/password 6-31 MPPP authentication/transmit maint port/password protect username 6-27 6-31 MPPP/BACP 6-25 maint port/stop bits 6-31 Index-4 ISU 512e User Manual 61203086L1-1...
  • Page 157 RIP/V2 secret 6-19 pinouts A-1 RJ 2-1 10 Base T A-1 RJ-45 ISDN connectors 2-1 EIA-232 A-3 RS-366 dialing port RS-366 dialing port A-4 pinouts A-4 V.35 A-2 RTS, CTS, CD, DTR, DSR 4-4 power 9-2 61203086L1-1 ISU 512e User Manual Index-5...
  • Page 158 4-3 summary 9-1 system info/system uptime 4-3 speech 6-5 system location 4-3 SPID system name 4-3 obtaining 6-3 system uptime 4-3 SPID1 8-5 SPID2 8-5 SPIDs Quick Start-1 TANULL 6-23 download 6-5 TCID 6-23 Index-6 ISU 512e User Manual 61203086L1-1...
  • Page 159 Index TEI1 8-3 TXINIT 6-22 TEI2 8-4 Telnet 6-28 updating 2-4 Telnet/server access 6-29 updating ISU 512e software Telnet/user list 6-29 from utilities/upgrade menu temperature 6-20 operating 9-2 local method 2-4 storage 9-2 remote method 6-11 terminal interface upgrade 6-20...
  • Page 160 Index VT 100 quick start from Quick Start-2 wait for EON 6-9 terminal menu 3-1 XMODEM protocol 2-4 Index-8 ISU 512e User Manual 61203086L1-1...
  • Page 161 (800) 615-1176 Sales (800) 827-0807 Post-Sale Support Please contact your local distributor first. If your local distributor can- not help, please contact ADTRAN Technical Support and have the unit serial number available. Technical Support (888) 4ADTRAN Repair and Return If ADTRAN Technical Support determines that a repair is needed, Technical Support will coordinate with the Customer and Product Service (CAPS) department to issue an RMA number.

This manual is also suitable for:

1203086l1

Table of Contents
