ADTRAN ISU 512E Specification Sheet

Product Features

I Low cost inverse
multiplexing
I Applications include
video-conferencing,
LAN/WAN connectivity,
high-speed file transfer,
and T1 backup
Supports up to four ISDN
I
Basic Rate lines
I Operates at synchronous
data rates of up to 512 kbps
Supports industry stan-
I
dard BONDING and
Multilink PPP
Dialing options include
I
front panel, stored number,
V.25 bis, DTR dialing, and
an RS-366 dial interface
I Flash memory for
easy upgrades
Remote configuration
I
over ISDN line
I Embedded SNMP
and Telnet
10BaseT Ethernet
I
SNMP access
I Standard five-year
warranty
ISU 512e
512 kbps ISDN Inverse Multiplexer with SNMP
The ADTRAN ISU 512e is a standalone
® ™
ISDN Service Unit that connects data
terminal equipment (DTE) to the ISDN net-
work. The ISU 512e is specifically designed as
a low-cost solution for applications such as
video-conferencing, T1 backup, LAN/WAN
connectivity, and high-speed file transfer.
Embedded SNMP & Telnet are available
through a 10BaseT Ethernet port. Through
the Management Information Base (MIB)-II
standard and an ADTRAN-supplied enterprise
MIB, the ISU 512e can be configured, moni-
tored and diagnosed using standard SNMP
network management programs such as HP
Openview ® , Netview ® and SunNet
The ISU 512e connects directly to the
ISDN network using up to four Basic Rate
ISDN (BRI) lines. By terminating four BRI
circuits, the ISU 512e can create an aggregate
bandwidth of up to 512 kbps which can be
used to backup a T1 circuit.
Since ISDN is a switched digital service,
bandwidth can be established and utilized on
an as needed basis. Therefore, the ISU 512e is
well suited for applications where a high
bandwidth connection is needed to support
bursty or infrequent traffic like medical image
or large file transfer.
The ISU 512e supports synchronous data
rates from 56 kbps to 512 kbps. At rates over
64 kbps, the ISU 512e supports BONDING
Mode 1 and MLPPP utilizing from one to
eight 64 kbps B channels. By supporting
BONDING the ISU 512e interoperates with
other BONDING-compatible inverse multi-
plexers and ISDN terminal adapters. By
supporting MLPPP the ISU 512e interoperates
with MLPPP compatible routers and bridges.
The ISU 512e can be configured and main-
tained, locally or remotely, using a VT100
terminal interface. For remote configuration,
the unit can be accessed over the ISDN line.
® Manager.
The front panel of the ISU 512e consists
of a two-line by 16 character LCD display,
seven LEDs, and a 16-button keypad. This
allows for configuring, dialing, testing, and
monitoring of the unit without data terminal
or test equipment.
Dialing from the unit is accomplished by
using the front panel, stored numbers, DTR
assertion, or V.25 bis in-band dialing. The
RS-366 parallel dial interface is available
for applications such as video-conferencing.
The ISU 512e also supports dedicated 2B1Q
services. This provides a dedicated point-to-
point service (as in a limited distance modern
or leased line application) with no dialing
necessary.
