Chapter 4. Status Menu

IP Routes/Netmask

This is the network mask applied to the destination address.

IP Routes/Gateway

This is the host or router to receive this packet.

IP Routes/Port

This is the port gateway is located on:
local
eth0

IP Routes/Use

This is the number of times the ISU 512e has referenced the route.

IP Routes/Flags

These are important tags associated with the route entry:
H
G
D
I
P
T

IP Routes/Hops

This is the number of routers that must be traversed to get to destina-
tion. Ranges from 0-15 or 16 for infinite (can't get there from here).
4-6
sent directly to the ISU 512e IP stack
ISU 512e's Ethernet port
route is a host route
route is a gateway route
route learned dynamically from RIP
route learned from an ICMP redirect
route is private and is not advertised with
RIP
route is to a triggered port (updates only
when table changes)
