2. Installation
2.1 Unpacking inspections
XP UPS consists of UPS module, battery module (or extended back-up time charger
module) and machine box. And the accessories are listed below:
Standard 1KVA (XP1K)
Extended back-up time
1KVA (XP1KS)
Standard 2KVA (XP2K)
Extended back-up time
2KVA (XP2KS)
Standard 3KVA (XP3K)
Extended back-up time
3KVA (XP3KS)
The following accessories are needed when operating the UPS in paralleling mode.
Paralleling 1KVA
Paralleling 1KVA with
extended back-up time
Paralleling 2KVA
Paralleling 2KVA with
extended back-up time
Paralleling 3KVA
Paralleling 3KVA with
extended back-up time
Types
battery connection wire, bracket connector 2
RS232 cable for paralleling, bracket connector 2
power wire for paralleling battery connection
wire for paralleling, output wire,bracket
connector 2
RS232 cable for paralleling, output wire, power
wire for paralleling, bracket connector 2
battery connection wire for paralleling, power
wire for paralleling, bracket connector 2
RS232 cable for paralleling, power wire for
paralleling, bracket connector 2
Components
Installation CD, power wire, RS232 cable,
Tower bracket 4.
×
Installation CD, power wire, RS232 cable,
battery connection wire, Tower bracket 4.
Installation CD, power wire,RS232 cable,
Tower bracket 4.
×
Installation CD, power wire,RS232 cable,
battery connection wire, Tower bracket 4.
Installation CD, power wire,RS232 cable,
o u t p u t w i r e , Tower bracket 4.
Installation CD, power wire,RS232 cable,
battery connection wire,
Tower bracket 4.
×
×
37
×
×
×
o u t p u t w i r e ,
×
×
，
×
×
×
