REMKO Smart-Control Touch
ID Description
ID7120 Open contact - suction
gas temp. probe
ID7121 Short circuit - heat gas
temp. probe
ID7122 Open contact - heat
gas temp. probe
ID7151 Room sensor offline
ID7152 Room sensor offline
ID7153 Room sensor offline
ID7154 Room sensor offline
ID7155 Room sensor offline
ID7156 Room thermostat off-
line
ID7157 Room thermostat off-
line
ID7158 Room thermostat off-
line
ID7159 Room thermostat off-
line
ID7160 Room thermostat off-
line
ID7161 Modbus address con-
flict
Communication mal-
ID7170
function
Open contact - storage
ID7200
tank 1 bottom probe
Short circuit - storage
ID7201
tank 1 bottom probe
Open contact - storage
ID7202
tank 1 middle probe
Short circuit - storage
ID7203
tank 1 middle probe
Open contact - storage
ID7204
tank 1 top probe
Short circuit - storage
ID7205
tank 1 top probe
Open contact - external
ID7206
probe
98
Desig. Details
Open contact - suction gas temp. probe
Short circuit - heat gas temp. probe
Open contact - heat gas temp. probe
Room sensor offline - The room sensor for the unmixed circuit
was not detected
Room sensor offline - The room sensor for the 1st mixed cir-
cuit was not detected
Room sensor offline - The room sensor for the 2nd mixed cir-
cuit was not detected
Room sensor offline - The room sensor for the 3rd mixed cir-
cuit was not detected
Room sensor offline - The room sensor for the 4th mixed cir-
cuit was not detected
Room thermostat offline - The room thermostat for the
unmixed circuit was not detected
Room thermostat offline - The room thermostat for the 1st
mixed circuit was not detected
Room thermostat offline - The room thermostat for the 2nd
mixed circuit was not detected
Room thermostat offline - The room thermostat for the 3rd
mixed circuit was not detected
Room thermostat offline - The room thermostat for the 4th
mixed circuit was not detected
Modbus address conflict - Make sure that a room sensor and
room thermostat never have the same Modbus address
HP 2 2nd Heat pump
S02 Open contact - storage tank 1 bottom probe
S02 Short circuit - storage tank 1 bottom probe
S09 Open contact - storage tank 1 middle probe
S09 Short circuit - storage tank 1 middle probe
S08 Open contact - storage tank 1 top probe
S08 Short circuit - storage tank 1 top probe
S10 Open contact - external probe
