REMKO Smart Control Touch Operating Manual page 102

REMKO Smart-Control Touch
ID Description
Low evaporation tem-
ID7287
perature
High evaporation tem-
ID7288
perature
High condensation tem-
ID7289
perature
ID7290 WKF fault code E102
ID7291 WKF fault code E201
ID7292 WKF fault code E231
ID7293 WKF fault code E251
ID7294 WKF fault code E320
ID7295 WKF fault code E416
Open contact -
ID7296 2nd mixed heating cycle
return flow temp.
Short circuit -
ID7297 2nd mixed heating cycle
return flow temp.
Open contact -
ID7298 3rd mixed heating cycle
inlet temp.
Short circuit -
ID7299 3rd mixed heating cycle
inlet temp.
Open contact -
ID7300 3rd mixed heating cycle
return flow temp.
Short circuit -
ID7301 3rd mixed heating cycle
return flow temp.
Open contact -
ID7302 4th mixed heating cycle
inlet temp.
Short circuit -
ID7303 4th mixed heating cycle
inlet temp.
Open contact -
ID7304 4th mixed heating cycle
return flow temp.
Short circuit -
ID7305 4th mixed heating cycle
return flow temp.
102
Desig. Details
The compressor is disabled due to the evaporation tempera-
µPC
ture being too low
The compressor is disabled due to the evaporation tempera-
µPC
ture being too high
The compressor is disabled due to the condensation tempera-
µPC
ture being too high
Communication error between com. kit and outdoor unit. F1/F2
twisted or cable break
Communication error between com. kit and outdoor unit - com-
munication could not be established or incorrect board version
Short circuit or open contact - evaporator temperature probe
motherboard outdoor unit CN43 Pin 3&4
Short circuit or open contact - hot gas temperature probe
motherboard outdoor unit CN43 Pin 5&6
Short circuit or open contact - overload switch probe (OLP)
motherboard outdoor unit CN43 Pin 7&8
Compressor stopped by overheating protection
S14 Open contact - 2nd mixed heating cycle return flow temp.
S14 Short circuit - 2nd mixed heating cycle return flow temp.
S12.2 Open contact - 3rd mixed heating cycle inlet temp.
S12.2 Short circuit - 3rd mixed heating cycle inlet temp.
S11.2 Open contact - 3rd mixed heating cycle return flow temp.
S11.2 Short circuit - 3rd mixed heating cycle return flow temp.
S06.2 Open contact - 4th mixed heating cycle inlet temp.
S06.2 Short circuit - 4th mixed heating cycle inlet temp.
S14.2 Open contact - 4th mixed heating cycle return flow temp.
S14.2 Short circuit - 4th mixed heating cycle return flow temp.
