6

Template hydraulics with installation parameters

NOTICE!
The sample hydraulic schematic shown below is only to be used as a planning aid, and does not replace
an installation drawing! Technical modifications reserved!
The design and planning of customer-provided hydraulic systems must be performed by a specialist
installer!
We recommend adapting plant-specific parameters, such a heating limits and bivalence point, to the
design data!
You can find further hydraulics examples at www.remko.de
Hydraulic circuit diagram
Functions: Heating and hot water incl. Smart-Serv emergency heating coil
Fig. 12: Example hydraulic diagram
A: Combination buffer tank
B: Room temperature/humidity probe
1: Heat pump inlet line
2: Heat pump return flow
A
1
M
2
3 4 5 6
3: Hot water
4: Cold water
5: Unmixed cycle
6: Mixed cycle
B
89
