2. Raise the bow of the bandsaw to the

vertical position, close the feed ON/OFF

valve to lock the bow in place and open

the wheel access cover.

3. Remove the blade guards.

4. Turning anti-clockwise, loosen the

blade tension handle, as shown, and

slip the blade off the wheels.

5. Install new blade around the bottom wheel and through both blade guide

bearings.

6. With the blade around the

bottom wheel, slip it around

the top wheel as shown,

keeping the blade between

the blade guide bearings
