About this document
6
Symbol Meaning
Bluetooth
Wireless data transmission between devices over a short distance.
LED
Light emitting diode is off.
LED
Light emitting diode is on.
LED
Light emitting diode is flashing.
1.2.4

Tool symbols

Symbol Meaning
Torx screwdriver
Flat-blade screwdriver
Phillips head screwdriver
Allen key
Open-ended wrench
1.2.5

Symbols for certain types of information

Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
Reference to page
A
Reference to graphic
Notice or individual step to be observed
, , ... Series of steps
1. 2. 3.
Result of a step
Help in the event of a problem
Visual inspection
Master Meter System
Endress+Hauser
