1.2.6

Symbols in graphics

Symbol Meaning
1, 2, 3, ... Item numbers
, , , ... Series of steps
1. 2. 3.
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
Hazardous area
-
Safe area (non-hazardous area)
.
Flow direction
1.3

Highlighting of text

Emphasis Meaning
Bold Keys, buttons, program icons, tabs, menus, commands
1.4

Acronyms used

Acronym
CSV
DUT
HMI
MM
OPC
1.5

Valid versions

Component
HMI application, version
Flow computer app, version
Flow computer app, name
Flow computer app, firmware version
1.6

Documentation

For an overview of the scope of the associated Technical Documentation, refer to the
following:
• W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number
from the nameplate
• Endress+Hauser Operations App: Enter the serial number from the nameplate or
scan the matrix code on the nameplate
Detailed list of the individual documents incl. documentation code →  55
About this document
Example
Start → Programs → Endress+Hauser
In the File menu, select the Print option.
Meaning
Comma Separated Values
Device Under Test
Human-Machine Interface
Master Meter
OLE (Object Linking and Embedding) for
Process Control
Version
01.00.00
0v4r20
E+H MM application
4v7r8770-R
7
