Product description
12
All real-time signals are synchronized via the wireless network on the tablet PC or panel
PC and thus made available to the operator via the HMI. Reports with test results are also
logged and can be retrieved, displayed and exported.
3.3

Interfaces

Various wireless communication channels and ports are available on the tablet PC:
• WWAN LTE + GPS Combo (US & EU) + Intel Wireless AC7260 802.11 a/b/g/n/ac +
Bluetooth 4.0 Class 1
• 2x USB 3.0
• 1x port for headphones/microphone
• 1x docking connection
• 1x extension connection for add-on modules
• 2x RF pass-through connections for WWAN & GPS
• 1x Micro SD card slot to support SDHC/SDXC
• 1x SIM card slot for WWAN data communication
3.4

Using the system

The system may be used only if it has no technical defects. Furthermore, it may be used
only as intended and in accordance with the instructions provided in this user manual.
It may be used only by safety-conscious and appropriately trained personnel who are fully
aware of the possible risks.
3.5

Modifying the system

Only appropriately trained and qualified staff are permitted to modify the system.
Modifications to the hardware or software may be performed only by Endress+Hauser
Service prior to implementing updates or upgrades. If you require further support, contact
your local Endress+Hauser Sales Center.
