7

Commissioning

7.1

Software update

If an update is required for one of the following programs, this must be carried out
first:
• HMI
• OPC
• Flow computer app
7.2

Wireless communication (can be used on a tablet PC)

All process values from the flow computer, MM and DUT are linked via an industrial
switch and transmitted to the tablet PC via an industrial, wireless router.
Check the wireless connection on the tablet PC to ensure that communication is working
correctly.
The I/O Diagnostics screen shows the process parameters that are transmitted via
Modbus from the field device in question, once Modbus communication has been
successfully established.
To ensure that communication is functioning correctly, verify that the values shown on the
display are meaningful.
For further information →  33
7.3

HMI settings

7.3.1

Test settings

Prior to commissioning the system, a number of test-related settings must be
correctly defined and entered. These include:
• Customer name, customer location
• Default settings for verification mode
• Default settings for verification method
• MM configuration (e.g. serial number, tag name, manufacturer, etc.)
• DUT configuration
• Units
For further information →  36
7.3.2

System settings

The system settings generally include user settings (e.g. date and time, file path),
communication (e.g. IP address) and other configurations.
For further information →  42
