Operation
38
"Master Meter" tab
The operator can configure the following parameters for the MM:
• Serial Number
• Tagname
• Manufacturer
• Meter Type
• Meter Size
• K-Factor (in pulses/t)
The operator can also enable or disable the "Flow Rate Deviation Check" and define the
following settings:
• Max. Allowable Flow Deviation
• Delay Time
"Duty Meter" tab
The operator can define the number of DUTs used (up to 12) and determine whether "Free
Select Duty Meter" should be enabled or disabled.
The operator can configure the following parameters under the specific configuration for
each DUT:
• Serial Number
• Tagname
• Manufacturer
• Meter Model
• Meter Size
• K-Factor (in pulses/t)
• Type Mass
• Product Name
The current software version supports only "Coriolis" under "Type Mass".
