Settings | Control Panel Options

Power

Access:
Please refer to Chapter 2 - Physical Description and Layout section titled Power Modes.
The mode timers are cumulative. The System Idle timer begins the countdown after the User Idle
timer has expired and the Suspend timer begins the countdown after the System Idle timer has
expired. When the User Idle timer is set to "Never", the power scheme timers never place the
device in User Idle, System Idle or Suspend modes (even when the device is idle).
Because of the cumulative effect, and using the Battery Power Scheme Defaults listed above:
• The backlight turns off after 3 seconds of no activity,
• The display turns off after 18 seconds of no activity (15sec + 3sec),
• And the device enters Suspend after 5 minutes and 18 seconds of no activity.
Adjust the settings and tap the OK button to save the changes. Changes are saved across tabs. Tap
the X button to discard any changes. Tap the ? for Help. The changes take effect immediately.
E-EQ-HX2RG-D
| Settings | Control Panel | Power
Factory Default Settings
Battery
Turbo Enabled
Schemes
AC Power User Idle
AC Power System Idle
AC Power Suspend
Battery Power User Idle
Battery Power System Idle
Battery Power Suspend
2 minutes
2 minutes
5 minutes
3 seconds
15 seconds
5 minutes

Figure 3-36 Power

123
