Page 1 Ring Scanner / Ring Imager Programming Guide (For LXE HX2/HX3 Ring Scanners, Ring Imagers, tethered to Windows® CE Devices) Barcodes in this guide must be printed on a 600dpi printer. The barcodes cannot be scanned from a computer monitor. Copyright © 2008 by LXE Inc.
Page 2: Revision Notice
Notice: LXE Inc. reserves the right to make improvements or changes to the information in this guide at any time without notice. While reasonable efforts have been made in the preparation of this guide to assure its accuracy, LXE assumes no liability resulting from any errors or omissions in this guide, or from the use of the information contained herein.
Page 3: Table Of Contents
HAPTER NTRODUCTION Barcodes and Scanner Engines ... 1 LXE Mobile Devices with Integrated Scanners ... 2 LXE Tethered Scanners and Bluetooth Scanners... 3 Identify Your Barcode Scanner Type ... 3 How To ..4 Cleaning the Beam Aperture ... 5 Troubleshooting ...
Page 4 Scanner Parameters – General ... 23 Aim Duration...23 Bi-Directional Redundancy ...24 Data Options...25 Prefix and Suffix...25 Prefix ...25 Suffix 1 ...26 Suffix 2 ...26 Scan Data Transmission Format...27 Transmit Code ID Character ...29 Transmit No Code ID Character ...29 Transmit Symbol Code ID Character...29 Transmit AIM Code ID Character ...30 Laser On Time...32 Linear Code Type Security Level (Redundancy Level) ...33...
Page 5 Table of Contents Code 39 Full ASCII Conversion...63 Set Lengths for Code 39...64 One Discrete Length (Parameter L1)...64 Two Discrete Lengths (Parameter L2) ...65 Length Within Range...65 Any Length ...65 Transmit Code 39 Check Digit ...66 Trioptic Code 39 ...67 Code 93...68 Set Lengths for Code 93...68 One Discrete Length (Parameter L1)...69...
Page 6 Decode UPC/EAN Supplementals...95 Decode UPC/EAN Supplemental Redundancy ...96 EAN-8 Zero Extend...97 UCC Coupon Extended Code...98 UPC/EAN Security Level...99 GS1 DataBar Codes (RSS Codes) ...101 GS1 DataBar Omnidirectional (RSS-14)...101 GS1 DataBar Limited (RSS-Limited)...101 GS1 DataBar Expanded (RSS-Expanded) ...101 Convert GS1 DataBar (RSS) to UPC/EAN ...102 Keypad Number Symbols ...
Page 7 Table of Contents Transmit No Code ID Character ...133 Transmit Symbol Code ID Character...133 Transmit AIM Code ID Character ...134 Prefix / Suffix Values ...138 Prefix ...138 Suffix 1 ...138 Suffix 2 ...139 Scan Data Transmission Format...140 Transmit “No Read” Message...141 UPC/EAN ...
Page 8 Interleaved 2 of 5 (ITF) ... 169 Set Lengths for I 2 of 5...169 One Discrete Length (Parameter L1) ...169 Two Discrete Lengths (Parameter L2)...170 Length Within Range...170 Any Length ...170 I 2 of 5 Check Digit Verification ...171 Transmit I 2 of 5 Check Digit...172 Convert I 2 of 5 to EAN 13 ...173 Discrete 2 of 5 (DTF)...
Page 9 Table of Contents Data Matrix Inverse...196 Maxicode...197 QR Code...197 MicroQR ...198 QR Inverse...198 Aztec...199 Aztec Inverse ...199 Redundancy Level... 200 Security Level ... 202 Intercharacter Gap Size ...203 Imager Keypad Number Symbols ... 204 HAPTER NGINE ECHNICAL Scanner Identification Label ... 207 Decode Zones ...
Page 10 viii Illustrations Figure 1-1 Chart – Identify Your Barcode Scanner Type ...3 Figure 1-2 Scanning Angle for Linear Barcodes...4 Figure 1-3 Scanning a 2D Barcode ...5 Figure 2-1 Supported SE955 Barcode Symbologies ...9 Figure 3-1 Supported SE4400 Barcode Symbologies ...105 Figure 4-1 Decode Zones –...
Page 11: Chapter 1 Introduction
The linked devices are directly cabled to the mobile device. LXE mobile devices can pair with more than one Bluetooth barcode reader at a time and they can support more than one ring scanner/imager. But the mobile device can only manipulate the data received from one ring scanner/imager or Bluetooth device at a time.
Page 12: Lxe Mobile Devices With Integrated Scanners
Supported scanning ranges for the different barcode readers are contained in Chapter 4 “Decode Zones”. Bluetooth scanners and Bluetooth imager programming barcodes and user instruction is not included in this guide. Please refer to the section titled LXE Tethered Scanners and Bluetooth Scanners. LXE Mobile Devices with Integrated Scanners LXE mobile devices with integrated scanners encase the scanning mechanism within the device.
Page 13: Lxe Tethered Scanners And Bluetooth Scanners
This guide does not include the barcodes to be used when programming tethered scanners connected to a COM port or serial port on LXE mobile devices and their cradles, the LXE 8300 and 8500 series specifically, or mobile Bluetooth scanners/imagers. Please refer to the scanner and imager manufacturer’s User Guide...
Page 14: How To
The linear barcodes in this guide were created using Code 128 symbology. Your mobile device has been set up by LXE to automatically read / decode Code 128 barcodes. Using the barcodes contained in this guide, you can change scanning system parameters or reset all parameters to their factory default values.
Page 15: Cleaning The Beam Aperture
Introduction - Cleaning the Beam Aperture To scan with the imager, point the beam aperture at an barcode and press the Scan button. You will see a bracketed crosshair strike the barcode. Align the brackets so that the center (or one of the four corners of the center box) of the barcode is covered by the crosshair.
Page 16: Troubleshooting
Ring decoding devices do not have the ability to emit a good read or bad read sound. Beep After Good Decode Audible scan progress indicators are generated by the scanner driver on LXE mobile devices, not the ring decoder engine. Use the Windows CE Control Panel options to set up the mobile device audible indicators.
Page 17: Factors That May Impact Scanner Performance
Code 39. The use of Code 128 or other more complex symbologies will almost always result in a reduction in maximum read distance. LXE will not support scanner maximum distances (from Decode Zones) when symbologies other than Code 39 are used.
Page 18: Getting Help
Getting Help LXE user and reference guides are now available on one CD and they can also be viewed and downloaded from the LXE ServicePass website on the ServicePass / Documentation page. Contact your LXE representative to obtain the LXE Manuals CD or logon information for the ServicePass web pages.
Page 19: Chapter 2 Se955 Laser Barcodes
GS1 DataBar (RSS) UPC/EAN Scanner Identification Label Look on the labels on your LXE mobile device, ring scanning device or ring imaging device. The type of installed scan engine should be clearly labeled. Contact your system administrator for assistance. E-SW-RINGSCANPG-C Scan the appropriate barcode in this chapter.
Page 20: Aiming Modes
SE955 scanner engine prefix and suffix parameters cannot be set, changed, or reset using the barcodes in this chapter. Refer to the chapter titled “Scanner” in the [device specific e.g. HX2, HX3] Reference Guide for information and instruction on setting up the following scanner parameters: •...
Page 21: Pre-Configured Default Values
SE955 Laser Barcodes - Pre-Configured Default Values Pre-Configured Default Values SE955 Parameter Set Default Parameter Scanning Options Aim Duration Aiming Mode Beeper Volume Bi-directional Redundancy Laser On Time Linear Code Type Security Levels Parameter Scanning Power Mode Raster Expansion Rate Raster Height Scan Angle (Clipping) Scan Angle...
Page 22 SE955 Parameter Code 128 Code 128 UCC/EAN-128 ISBT 128 Code 128 Decode Performance Code 128 Decode Performance Level Code 39 Code 39 Trioptic Code 39 Convert Code 39 to Code 32 Code 32 Prefix Set Length(s) for Code 39 Code 39 Check Digit Verification Transmit Code 39 Check Digit Code 39 Full ASCII Conversion Code 39 Decode Performance...
Page 23 SE955 Laser Barcodes - Pre-Configured Default Values SE955 Parameter MSI Plessey Check Digits Transmit MSI Plessey Check Digit MSI Plessey Check Digit Algorithm PDF417/MicroPDF417 PDF417 MicroPDF417 Decode Linked Symbol Code 128 Emulation GS1 DataBar (RSS) GS1 DataBar Omnidirectional (RSS-14) GS1 DataBar Limited (RSS Limited) GS1 DataBar Expanded (RSS Expanded) Convert GS1 DataBar (RSS) to UPC/EAN Composite...
Page 24 SE955 Parameter Transmit Sender Transmit Addressee Transmit Checksum Transmit File Size Transmit Macro PDF Control Header Last Block Marker Flush Macro Buffer Abort Macro PDF Entry Ring Scanner / Ring Imager Programming Guide SE955 Laser Barcodes - Pre-Configured Default Values Default Not Supported Not Supported...
Page 25: Frequently Used Barcodes - Se955
SE955 Laser Barcodes - Frequently Used Barcodes – SE955 Frequently Used Barcodes – SE955 Reset/Cancel Barcodes Restore Defaults If custom defaults were set by scanning Write Custom Defaults, scan Restore Defaults to retrieve and restore the scanner’s custom default settings. If no custom defaults were set, scan Restore Defaults to restore the factory default values.
Page 26: Configure The Decoder For Barcode Types
Configure The Decoder For Barcode Types Scan either the Enable or the Disable barcode to the right to turn a barcode type on or off. See also the barcode type’s main section in this chapter. For example, see section “UPC/EAN” for the remainder of the UPC/EAN parameters –...
Page 27: Codabar
SE955 Laser Barcodes - Frequently Used Barcodes – SE955 Codabar Code 11 Code 128 Enable Code 128 Disable Code 128 E-SW-RINGSCANPG-C Enable Codabar Disable Codabar Enable Code 11 Disable Code 11 Ring Scanner / Ring Imager Programming Guide...
Page 28: Code 39
Code 39 Enable Code 39 Disable Code 39 Note: Trioptic Code 39 symbols always contain 6 characters. Trioptic Code and Code 39 Full ASCII should not be enabled simultaneously. Code 93 Enable Code 93 Disable Code 93 Ring Scanner / Ring Imager Programming Guide SE955 Laser Barcodes - Frequently Used Barcodes –...
Page 29: Discrete 2 Of 5
SE955 Laser Barcodes - Frequently Used Barcodes – SE955 Discrete 2 of 5 EAN-13 Enable EAN-13 Disable EAN-13 EAN-8 E-SW-RINGSCANPG-C Enable Discrete 2 of 5 Disable Discrete 2 of 5 Enable EAN-8 Disable EAN-8 Ring Scanner / Ring Imager Programming Guide...
Page 30: Interleaved 2 Of 5
Interleaved 2 of 5 Enable Interleaved 2 of 5 Disable Interleaved 2 of ISBT 128 MSI Plessey Enable MSI Plessey Disable MSI Plessey Ring Scanner / Ring Imager Programming Guide SE955 Laser Barcodes - Frequently Used Barcodes – SE955 Enable ISBT 128 Disable ISBT 128 E-SW-RINGSCANPG-C...
Page 31: Ucc/Ean-128
SE955 Laser Barcodes - Frequently Used Barcodes – SE955 UCC/EAN-128 UPC-A Enable UPC-A Disable UPC-A UPC-E E-SW-RINGSCANPG-C Enable UCC/EAN-128 Disable UCC/EAN-128 Enable UPC-E Disable UPC-E Ring Scanner / Ring Imager Programming Guide...
Page 32: Upc-E1
UPC-E1 Enable UPC-E1 Disable UPC-E1 Ring Scanner / Ring Imager Programming Guide SE955 Laser Barcodes - Frequently Used Barcodes – SE955 E-SW-RINGSCANPG-C...
Page 33: Scanner Parameters - General
SE955 Laser Barcodes - Scanner Parameters – General Scanner Parameters – General Aim Duration Note: For correct operation, reboot the mobile device after changing this value. When a scanner with an aim mode is triggered either by a Scan button press, or a Start_Decode command, this parameter sets the duration the aiming pattern is seen before a scan attempt begins.
Page 34: Bi-Directional Redundancy
Bi-Directional Redundancy Parameter Default Value: Use this parameter to decide whether a barcode is successfully scanned in both directions before being decoded. Note: This parameter is only valid when a Linear Code Type Security Level has been enabled. The default for Security Level parameter is Level 1. Select an option by scanning either of the barcodes shown below.
Page 35: Data Options
SE955 Laser Barcodes - Scanner Parameters – General Data Options SE955 scanner engine prefix and suffix parameters cannot be set, changed, or reset using the barcodes in this chapter. See previous section titled Prefix / Suffix. Prefix and Suffix Prefix (P) Parameter Default Value: Suffix1 (S1) Parameter Default Value: Suffix2 (S2) Parameter Default Value: Note:...
Page 36: Suffix 1
Suffix 1 To begin setting Suffix 1 value, scan this barcode: Next, scan four numeric barcodes that correspond to the computer keycode using the “Keypad Number Symbols” at the end of this chapter. If you wish to change your selection, scan Cancel on the “Keypad Number Symbols” page. Suffix 2 To begin setting Suffix 2 value, scan this barcode: Next, scan four numeric barcodes that correspond to the computer keycode using the “Keypad...
Page 37: Suffix 2
SE955 Laser Barcodes - Scanner Parameters – General Scan Data Transmission Format Parameter Default Value: Note: Parameter “Prefix/Suffix Values” should be set after setting this parameter. Use this option when you want to append a prefix and suffix to the decode data. Set this parameter by scanning one of the following barcodes.
Page 38 [Prefix] [Data] [Suffix 1] [Prefix] [Data] [Suffix 2] [Prefix] [Data] [Suffix 1] [Suffix 2] Now you are ready to scan one of the “Prefix/Suffix Values” barcodes. Ring Scanner / Ring Imager Programming Guide SE955 Laser Barcodes - Scanner Parameters – General <Prefix><Data><Suffix 1>...
Page 39: Transmit Code Id Character
SE955 Laser Barcodes - Scanner Parameters – General Transmit Code ID Character Parameter Default Value: A code ID character identifies the code type of a scanned barcode. This may be useful when the scanner is decoding more than one code type. In addition to any single character prefix already selected, the code ID character is inserted between the prefix and the decoded symbol.
Page 40: Transmit Aim Code Id Character
Transmit AIM Code ID Character Each AIM Code Identifier contains the three character string ]cm where: = Flag Character (ASCII 93) = Code Character = Modifier Character The modifier character is the sum of the applicable option values based on the following table. Code Type Code39...
Page 41 SE955 Laser Barcodes - Scanner Parameters – General Code Type I 2 of 5 Codabar Code 93 MSI Plessey D 2 of 5 UPC/EAN Bookland EAN According to AIM standards, a UPC with supplemental barcode is transmitted in the following format: ]EO (UPC chars) (terminator) ]E2 (supplemental) (terminator) Therefore, a UPC with two supplemental characters, 01234567890510, is transmitted to the host...
Page 42: Laser On Time
Laser On Time Note: For correct operation, reboot the mobile device after changing this value. Parameter Default Value: This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. If a label has not been decoded before this time expires and the session is terminated, the system regards it as a failed scan attempt.
Page 43: Linear Code Type Security Level (Redundancy Level)
SE955 Laser Barcodes - Scanner Parameters – General Linear Code Type Security Level (Redundancy Level) Parameter Default Value: Use this parameter to determine the security level appropriate for barcode quality. The security level indicates how many times the barcode must be successfully read by the scanner before being decoded.
Page 44 Linear Security Level 4 Ring Scanner / Ring Imager Programming Guide SE955 Laser Barcodes - Scanner Parameters – General All code types (Code 128 exception) must be successfully read three times before being decoded. Linear Security Level 4 Cancel E-SW-RINGSCANPG-C...
Page 45: Parameter Scanning
SE955 Laser Barcodes - Scanner Parameters – General Parameter Scanning Parameter Default Value: Use this parameter to decide whether scanner parameters can be set using the barcodes in this chapter. Note: When this parameter is disabled, scan the Set Defaults parameter barcode to enable parameter scanning.
Page 46: Power Mode
Power Mode Note: LXE mobile devices are designed to be operated in Low Power Mode. LXE recommends leaving this value unchanged. Parameter Default Value: A parameter setting of Continuous On means the laser scanner will not power down until the mobile device is powered off.
Page 47: Scan Angle
SE955 Laser Barcodes - Scanner Parameters – General Scan Angle Parameter Default Value: Wide Angle Choose one of the options below to set the scan angle to narrow or wide. The scan angle can be selected through scanning a parameter barcode. Once the parameter barcode is scanned, the Scan Angle setting is persistently stored.
Page 48: Set Default Parameter
Set Default Parameter Restore Defaults If custom defaults were set by scanning Write Custom Defaults, scan Restore Defaults to retrieve and restore the scanner’s custom default settings. If no custom defaults were set, scan Restore Defaults to restore the factory default values. Set Factory Defaults Restore the factory default values.
Page 49: Simple Serial Interface (Ssi) Options
Decode Data Packet Format Host Character Time-out Host Serial Response Time- Intercharacter Delay Parity Software Handshaking Stop Bit Select Note: LXE recommends setting/maintaining the Baud Rate Parameter at 9600 bps at all times. E-SW-RINGSCANPG-C Default 9600 Not Supported Not Supported Unpacketed...
Page 50: Baud Rate
Baud Rate Baud Rate Parameter Default Value Baud rate is the number of bits of data transmitted per second. The scanner’s baud rate setting should match the data rate setting of the host device. If not, data may not reach the host device or may reach it in distorted form.
Page 51: Decode Data Packet Format
SE955 Laser Barcodes - Scanner Parameters – General 19,200 bps 38,400 bps Cancel Decode Data Packet Format Decode Data Packet Parameter Default Value Unpacketed This parameter selects whether decoded data is transmitted in raw format (unpacketed), or transmitted with the packet format as defined by the serial protocol. If the raw format is chosen, ACK/NAK handshaking is automatically disabled for decode data.
Page 52: Host Character Time-Out
Host Character Time-out Host Character Time-out Parameter Default Value This parameter determines the maximum time the decoder waits between characters transmitted by the host before discarding the received data and declaring an error. The time-out is set in 0.01 second increments from 0.01 seconds to 0.99 seconds. After scanning the barcode below, scan two numerical barcodes to set the desired time-out.
Page 53: Host Serial Response Time-Out
SE955 Laser Barcodes - Scanner Parameters – General Host Serial Response Time-out Host Serial Response Time-out Parameter Default Value This parameter determines the maximum time the decoder waits for an ACK or NAK before resending. Also, if the decoder wants to send, and the host has already been granted permission to send, the decoder waits for the designated time-out before declaring an error.
Page 54: Parity
Parity Parity Parameter Default Value A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. Set this parameter by scanning one of the following barcodes. Odd Parity The Odd parity bit has a value 0 or 1, based on data, to ensure that an odd number of 1 bits is contained in the coded...
Page 55: Software Handshaking
SE955 Laser Barcodes - Scanner Parameters – General Software Handshaking Default Value Enable This parameter offers control of the data transmission process in addition to that offered by hardware handshaking. Hardware handshaking is always enabled and cannot be disabled by the user. Scan one of the following barcodes to set software handshaking.
Page 56: Stop Bit Select
Stop Bit Select Parity Parameter Default Value The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. The number of stop bits selected (one or two) depends on the number the receiving computer is programmed to accommodate.
Page 57: Transmit "No Read / Decode" Message
SE955 Laser Barcodes - Scanner Parameters – General Transmit “No Read / Decode” Message Parameter Default Value: Use this parameter to decide whether a message is sent to the host when a barcode symbol does not decode. When enabled, and a symbol does not decode within either: •...
Page 58: Trigger Mode
Trigger Mode Note: HX2 and HX3 mobile devices with linked scanners are designed to be operated in Host Trigger Mode. LXE recommends leaving the Trigger Mode default value unchanged. Parameter Default Value: Use this parameter to determine when the laser is activated and decoding begins, how long the laser remains on and what determines the cessation of the laser scan and decode process.
Page 59 SE955 Laser Barcodes - Scanner Parameters – General Host E-SW-RINGSCANPG-C Triggering signal comes from a host command. Any actual Scan button press will be interpreted by the scanner engine as a Level triggering option. Host Ring Scanner / Ring Imager Programming Guide Cancel...
Page 60: Scanner Parameters - Se955 Barcode Type Specific
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Scanner Parameters – SE955 Barcode Type Specific Chinese 2 of 5 Parameter Default Value: When enabled, Chinese 2 of 5 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Disable Codabar...
Page 61: Clsi Editing
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific CLSI Editing Parameter Default Value: When enabled, the start and stop characters are stripped from the barcode and a space is inserted after the 1 , and 10 Set this parameter by scanning either of the barcodes shown below. Note: Symbol length does not include start and stop characters.
Page 62: Set Lengths For Codabar
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Set Lengths for Codabar L1 Parameter Default Value: L2 Parameter Default Value: Lengths for Codabar may be set for: • any length, • one or two discrete lengths, • or lengths within a specific range.
Page 63: Two Discrete Lengths (Parameter L2)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only Codabar symbols containing 2 or 14 characters, scan the “Codabar Two Discrete Lengths”...
Page 64: Code 11
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Code 11 Parameter Default Value: When enabled, Code 11 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Disable Set Lengths for Code 11 L1 Parameter Default Value: L2 Parameter Default Value:...
Page 65: One Discrete Length (Parameter L1)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 11 symbols containing 14 characters, scan the “Code 11 One Discrete Length” barcode and then “1”...
Page 66: Any Length
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Any Length This option decodes Code 11 barcodes containing any number of characters. To set any length, scan this barcode: Code 11 Check Digit Verification Parameter Default Value: When enabled, this parameter checks the integrity of a Code 11 symbol to ensure it complies with the specified check digit algorithm.
Page 67: Transmit Code 11 Check Digits
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Transmit Code 11 Check Digits Parameter Default Value: Note: Code 11 Check Digit Verification must be enabled for this parameter to function. Transmit (Enable) Do Not Transmit (Disable) E-SW-RINGSCANPG-C Do Not Transmit (Disable) Enable Transmit Check Dig Disable Transmit Check D...
Page 68: Code 128
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Code 128 Parameter Default Value: Set this parameter by scanning either of the barcodes shown below. Enable Disable UCC/EAN-128 Parameter Default Value: Set this parameter by scanning either of the barcodes shown below. Enable Disable UCC/EAN-128 is a convention for printing data fields with standard Code 128 barcode symbols.
Page 69 SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Standard Code 128 barcodes which do not have a leading FNC1 may still be used, but are not encoded according to the EAN-128 convention. Standard Code 128 and UCC/EAN-128 may be mixed in an application.
Page 70: Isbt-128
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific ISBT-128 Parameter Default Value: Set this parameter by scanning either of the barcodes shown below. Enable Disable Lengths for Code 128 No length setting is required for Code 128. The default setting is Any Length.
Page 71: Code 39
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Code 39 Parameter Default Value: Note: This parameter must be enabled when “Convert Code 39 to Code 32” is to be enabled. Set this parameter by scanning either of the barcodes shown below. Enable Disable Code 39 Check Digit Verification...
Page 72: Code 32 Prefix
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Code 32 Prefix Parameter Default Value: This parameter adds the prefix character “A” to all Code 32 barcodes. Note: When enabled, “Convert Code 39 to Code 32” parameter must also be enabled. Set this parameter by scanning either of the barcodes shown below.
Page 73: Code 39 Full Ascii Conversion
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Code 39 Full ASCII Conversion Parameter Default Value: Note: Code 39 Full ASCII and Trioptic Code 39 should not be enabled simultaneously. When enabled, the ASCII character set assigns a code to letter, punctuation marks, numerals, and most control keystrokes on the keyboard.
Page 74: Set Lengths For Code 39
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Set Lengths for Code 39 L1 Parameter Default Value: L2 Parameter Default Value: Lengths for Code 39 may be set for: • any length, • one or two discrete lengths, •...
Page 75: Two Discrete Lengths (Parameter L2)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only Code 39 symbols containing 2 or 14 characters, scan the “Code 39 Two Discrete Lengths”...
Page 76: Transmit Code 39 Check Digit
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Transmit Code 39 Check Digit Parameter Default Value: When enabled, the check digit is transmitted with the data. Parameter setting for “Code 39 Check Digit Verification” has no effect on this parameter value. Set this parameter by scanning either of the barcodes shown below.
Page 77: Trioptic Code 39
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Trioptic Code 39 Parameter Default Value: Trioptic Code 39 symbols always contain six characters. When Trioptic Code 39 is enabled, set the “Code 39 Full ASCII” parameter to disabled. Both parameters should not be enabled simultaneously.
Page 78: Code 93
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Code 93 Parameter Default Value: When enabled, Code 93 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Disable Set Lengths for Code 93 L1 Parameter Default Value: L2 Parameter Default Value:...
Page 79: One Discrete Length (Parameter L1)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 93 symbols containing 14 characters, scan the “Code 93 One Discrete Length” barcode and then “1”...
Page 80: Length Within Range
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 93 symbols containing between 4 and 12 characters, scan the “Code 93 Length Within Range”...
Page 81: Discrete 2 Of 5
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Discrete 2 of 5 Parameter Default Value: When enabled, Discrete 2 of 5 (D 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Disable Set Lengths for Discrete 2 of 5...
Page 82: One Discrete Length (Parameter L1)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only D 2 of 5 symbols containing 14 characters, scan the “D 2 of 5 One Discrete Length” barcode and then “1”...
Page 83: Length Within Range
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only D 2 of 5 symbols containing between 4 and 12 characters, scan the “D 2 of 5 Length Within Range”...
Page 84: Interleaved 2 Of 5
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Interleaved 2 of 5 Parameter Default Value: When enabled, Interleaved 2 of 5 (I 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Disable Ring Scanner / Ring Imager Programming Guide...
Page 85: Check Digit Verification
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Check Digit Verification Parameter Default Value: When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification) or OPCC (Optical Product Code Council).
Page 86: Convert I 2 Of 5 To Ean-13
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Convert I 2 of 5 to EAN-13 Parameter Default Value: A successful barcode conversion requires the following to be true: • Interleaved 2 of 5 scanning is enabled. • One of the I 2 of 5 lengths is set to 14.
Page 87: Set Lengths For I 2 Of 5
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Set Lengths for I 2 of 5 L1 Parameter Default Value: L2 Parameter Default Value: Lengths for I 2 of 5 may be set for: • any length, • one or two discrete lengths, •...
Page 88: Two Discrete Lengths (Parameter L2)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only I 2 of 5 symbols containing 2 or 14 characters, scan the “I 2 of 5 Two Discrete Lengths”...
Page 89: Any Length
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Any Length This option decodes I 2 of 5 barcodes containing any number of characters. Note: Selecting this option may lead to misdecodes for I 2 of 5 codes. To set any length, scan this barcode: Transmit I 2 of 5 Check Digit Parameter Default Value:...
Page 90: Msi Plessey
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific MSI Plessey Parameter Default Value: When enabled, MSI Plessey symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Disable MSI Plessey Check Digit Algorithm Parameter Default Value: When the “Two MSI Plessey Check Digits”...
Page 91: Msi Plessey Check Digits
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific MSI Plessey Check Digits Parameter Default Value: Check digits placed at the end of the MSI Plessey barcode verify the integrity of the data. At least one check digit is always required. Check digits are not automatically transmitted with the data. Note: When Two Check Digits is selected, an “MSI Plessey Check Digit Algorithm”...
Page 92: One Discrete Length (Parameter L1)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only MSI Plessey symbols containing 14 characters, scan the “MSI Plessey One Discrete Length”...
Page 93: Length Within Range
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only MSI Plessey symbols containing between 4 and 12 characters, scan the “MSI Plessey Length Within Range”...
Page 94: Transmit Msi Plessey Check Digit
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Transmit MSI Plessey Check Digit Parameter Default Value: When enabled, the check digit is transmitted with the data. Set this parameter by scanning either of the barcodes shown below. Enable Transmit MSI Plessey Check Digit Disable Transmit MSI...
Page 95: Upc/Ean
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UPC/EAN UPC-A Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Disable UPC-E Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Disable E-SW-RINGSCANPG-C...
Page 96: Upc-E1
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UPC-E1 Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Disable EAN-8 Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Disable Ring Scanner / Ring Imager Programming Guide...
Page 97: Ean-13
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific EAN-13 Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Disable Bookland EAN Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Disable E-SW-RINGSCANPG-C...
Page 98: Check Digits
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Check Digits Transmit UPC-A Check Digit Parameter Default Value: This parameter determines whether the symbol will be transmitted with or without the UPC-A check digit. Select an option by scanning either of the barcodes shown below. Enable Transmit UPC- A Check Digit Disable Transmit UPC-...
Page 99: Transmit Upc-E1 Check Digit
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Transmit UPC-E1 Check Digit Parameter Default Value: This parameter determines whether the symbol will be transmitted with or without the UPC-E1 check digit. Select an option by scanning either of the barcodes shown below. Enable Transmit UPC- E1 Check Digit Disable Transmit UPC-...
Page 100: Conversions
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Conversions Convert UPC-E to UPC-A Parameter Default Value: When this parameter is enabled, UPC-E (zero suppressed) decoded data is converted to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC- A programming selections (e.g.
Page 101: Convert Ean-8 To Ean-13 Type
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Convert EAN-8 to EAN-13 Type Parameter Default Value: When “EAN-8 Zero Extend” is enabled, this parameter setting labels the extended symbol as either an EAN-13 barcode or an EAN-8 barcode. When “EAN-8 Zero Extend”...
Page 102: Preambles
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Preambles UPC-A Preamble Parameter Default Value: A preamble is a lead-in character for UPC-A symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble System Character...
Page 103: Upc-E Preamble
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UPC-E Preamble Parameter Default Value: A preamble is a lead-in character for UPC-E symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble System Character System Character and Country Code...
Page 104: Upc-E1 Preamble
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UPC-E1 Preamble Parameter Default Value: A preamble is a lead-in character for UPC-E1 symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble System Character System Character and Country Code...
Page 105: Supplementals
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Supplementals Decode UPC/EAN Supplementals Parameter Default Value: Note: In order to minimize the risk of invalid data transmission, we recommend that you select whether to read or ignore supplemental characters. Supplementals are additionally appended characters (2 or 5) according to specific code format conventions (e.g.
Page 106: Decode Upc/Ean Supplemental Redundancy
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Enable 978 Supplemental Mode Enable Smart Supplemental Mode Decode UPC/EAN Supplemental Redundancy Parameter Default Value: With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of times a symbol without supplementals will be decoded before transmission. The range is from 2 to 20 times.
Page 107: Ean-8 Zero Extend
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific EAN-8 Zero Extend Parameter Default Value: When this parameter is enabled, five leading zeros are added to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Use parameter “Convert EAN-8 to EAN-13 Type”...
Page 108: Ucc Coupon Extended Code
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UCC Coupon Extended Code Note: UCC Coupon Extended Code replaces UPC/EAN Coupon Code. Parameter Default Value: The UCC Coupon Extended Code is an additional barcode adjacent to a UCC Coupon Code. To enable or disable UCC Coupon Extended Code, scan the appropriate barcode below.
Page 109: Upc/Ean Security Level
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UPC/EAN Security Level Parameter Default Value: Use this parameter to determine the security level appropriate for UPC/EAN barcode quality. There is an inverse relationship between security and scanner aggressiveness, so be sure to choose only that level of security necessary for any given application.
Page 110 SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific UPC/EAN Security Level 3 Ring Scanner / Ring Imager Programming Guide Select this security level if you have tried security level 2 and are still experiencing mis-decodes. Using this level is an extreme measure against mis-decoding severely out of spec barcodes.
Page 111: Gs1 Databar Codes (Rss Codes)
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific GS1 DataBar Codes (RSS Codes) Parameter Default Value: GS1 DataBar Omnidirectional (RSS-14) Enable Disable GS1 DataBar Limited (RSS-Limited) Enable Disable GS1 DataBar Expanded (RSS-Expanded) Enable Disable E-SW-RINGSCANPG-C All Parameters : Disable Ring Scanner / Ring Imager Programming Guide...
Page 112: Convert Gs1 Databar (Rss) To Upc/Ean
SE955 Laser Barcodes - Scanner Parameters – SE955 Barcode Type Specific Convert GS1 DataBar (RSS) to UPC/EAN Parameter Default Value: This parameter only applies to GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS Limited) symbols. When this conversion is enabled, GS1 DataBar Omnidirectional (RSS- 14) and GS1 DataBar Limited (RSS Limited) symbols encoding a single zero as the first digit have the leading ‘010’...
Page 113: Keypad Number Symbols
SE955 Laser Barcodes - Keypad Number Symbols Keypad Number Symbols The barcode labels shown below represent a numeric keypad, with decimal values 0 through 9. Each label can be scanned individually to enter a numeric value. Use these numeric value symbols to enter numeric input in the course of performing a scan engine system configuration.
Page 114 SE955 Laser Barcodes - Keypad Number Symbols Ring Scanner / Ring Imager Programming Guide E-SW-RINGSCANPG-C...
Page 115: C Hapter 3 Se4400 I Mager B Arcodes
Scan engine manufacturers may offer more barcodes and options than are contained in this chapter. Please note that the barcodes in this chapter are only those supported by LXE and the mobile devices it manufactures or supports. If you need assistance when using the barcodes in this chapter, please contact your LXE representative.
Page 116: Imager Identification Label
Imager Identification Label Look on the labels on your LXE mobile device or ring scanning device. The type of installed scan engine should be clearly labeled. Contact your system administrator for assistance. Prefix / Suffix Refer to the chapter titled “Scanner” in the [device specific e.g. HX2, HX3] Reference Guide for information and instruction on setting up the following imager parameters: •...
Page 117: Miscellaneous Programmable Barcodes
The tethered ring imager does not have beep capability. Beep After Good Decode Audible scan progress indicators are generated by the scanner driver on LXE mobile devices, not the barcode reader engine. Use Control Panel options to set up the mobile device audible indicators.
Page 118: Pre-Configured Default Values
Pre-Configured Default Values SE4400 Parameter Set Default Parameter Parameter Scanning Operational Mode Beep After Good Decode Beeper Tone Beeper Volume Decode Session Timeout Power Mode PL4407 Power Mode MS4407 Presentation Mode Session Timeout Report Version Time Delay to Low Power Mode Timeout between Decodes, Same Symbol Trigger Modes PL4407 Trigger Mode MS4407...
Page 119 SE4400 Imager Barcodes - Pre-Configured Default Values Convert UPC-E to A Convert UPC-E1 to A EAN-8/JAN-8 Extend UCC Coupon Extended Code Code 128 Code 128 UCC/EAN-128 ISBT 128 Code 39 Code 39 Trioptic Code 39 Convert Code 39 to Code 32 (Italian Pharmacy Code) Code 32 Prefix Set Length(s) for Code 39 Code 39 Check Digit Verification...
Page 120 Postal Codes 4State Postal US Postnet US Planet UK Postal Transmit UK Postal Check Digit Japan Postal Australian Postal Dutch Postal Transmit US Postal Check Digit GS1 DataBar (RSS) GS1 DataBar Omnidirectional (RSS 14) GS1 DataBar Limited (RSS Limited) GS1 DataBar Expanded (RSS Expanded) Convert GS1 DataBar (RSS) to UPC/EAN Composite Composite CC-C...
Page 121: Frequently Used Barcodes – Se4400
SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 Frequently Used Barcodes – SE4400 Reset/Cancel Barcodes Use the Set All Defaults barcode to return all parameters to their default values. Scanning this barcode does not affect the mobile device’s operating system, wireless client or installed software (e.g.
Page 122: Configure Imager For Barcode Types
Configure Imager For Barcode Types Scan either the Enable or the Disable barcode to the right to turn a barcode type on or off. See also the barcode type’s main section in this chapter. For example, see section “UPC/EAN” for the remainder of the UPC/EAN parameters -- such as UPC-A Preamble, UPC/EAN Security Level, etc.
Page 123: Codabar
SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 Data Matrix Enable Data Matrix Disable Data Matrix Maxicode Enable Maxicode Disable Maxicode QR Code Enable QR Code Disable QR Code Codabar Refer to this symbology’s main section later in this chapter for more programming barcodes. Disable Codabar Enable Codabar E-SW-RINGSCANPG-C...
Page 124 Code 11 Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable Code 11 Disable Code 11 Code 39 Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable Code 39 Disable Code 39 Code 93 Refer to this symbology’s main section later in this chapter for more programming barcodes.
Page 125: Composite
SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 Code 128 Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable Code 128 Disable Code 128 Composite Refer to this symbology’s section later in this chapter for more programming barcodes. Composite CC-C Enable Composite CC-C Disable Composite CC-C...
Page 126: Interleaved 2 Of 5
Composite TLC-39 Enable Composite TLC-39 Disable Composite TLC-39 Interleaved 2 of 5 Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Discrete 2 of 5 Refer to this symbology’s main section later in this chapter for more programming barcodes.
Page 127: Msi (Plessey Code)
SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 ISBT-128 Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable ISBT-128 Disable ISBT-128 MSI (Plessey Code) Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable MSI Disable MSI Postal Codes...
Page 128 US Planet Enable US Planet Disable US Planet UK Postal Enable UK Postal Disable UK Postal Japan Postal Enable Japan Postal Disable Japan Postal Australian Postal Enable Australian Postal Disable Australian Postal Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 E-SW-RINGSCANPG-C...
Page 129: Gs1 Databar (Rss)
SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 Dutch Postal Enable Dutch Postal Disable Dutch Postal GS1 DataBar (RSS) Refer to this symbology’s main section later in this chapter for more programming barcodes. Enable GS1 DataBar Omnidirectional (RSS-14) Disable GS1 DataBar Omnidirectional (RSS-14) E-SW-RINGSCANPG-C Ring Scanner / Ring Imager Programming Guide...
Page 130: Upc/Ean
UPC/EAN Refer to this symbology’s main section later in this chapter for more programming barcodes. UPC-A Enable UPC-A Disable UPC-A UPC-E Enable UPC-E Disable UPC-E UPC-E1 Enable UPC-E1 Disable UPC-E1 EAN-8/JAN-8 Enable EAN-8/JAN-8 Disable EAN-8/JAN-8 Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - Frequently Used Barcodes –...
Page 131 SE4400 Imager Barcodes - Frequently Used Barcodes – SE4400 EAN-13/JAN-13 Enable EAN-13/JAN-13 Disable EAN-13/JAN-13 Bookland EAN Enable Bookland EAN Disable Bookland EAN E-SW-RINGSCANPG-C Ring Scanner / Ring Imager Programming Guide...
Page 132: Imager Parameters – General
Imager Parameters – General Except for the General imager attributes in this section that can be set by the end-user, imager programming attributes are set using the CE Control Panel Scanner panel resident on the mobile device. Barcode manipulation parameters assigned using the Control Panel Scanner panels are applied to the data resulting from successful barcode scans.
Page 133: Decode Aiming Pattern
SE4400 Imager Barcodes - Imager Parameters – General Decode Aiming Pattern Note: This parameter only applies when in Decode Mode. See Operational Mode. Parameter Default Value: Scan Enable Decode Aiming Pattern to project the aiming pattern during barcode capture, or Disable Decode Aiming Pattern to turn the aiming pattern off.
Page 134: Decoding Illumination
Decoding Illumination Note: When this parameter is disabled, any LED Illumination parameter setting is ignored. Parameter Default Value: The decoder has three small bright LEDs situated above the scan aperture. Enable this parameter for LED illumination upon every decode. The effectiveness of the illumination decreases as the distance to the target increases.
Page 135: Focus Mode
SE4400 Imager Barcodes - Imager Parameters – General Focus Mode Parameter Default Value: Select a focus mode to control the working range of the imager. When Far Focus is selected, the imager is optimized to read at its far position. With Near Focus, the imager is optimized to read at its near position.
Page 136: Led Illumination
LED Illumination Note: This parameter only applies for decoding if Decoding Illumination is enabled. If Decoding Illumination is disabled, all illumination is off for that mode, regardless of this LED Illumination setting. Parameter Default Value: The decoder has three small bright LEDs situated above the scan aperture. Internal LED illumination turns the LEDs on during scan mode.
Page 137: Operational Mode
SE4400 Imager Barcodes - Imager Parameters – General Operational Mode Parameter Default Value: In Decode Mode (the default mode), upon a Scan button event, the imager attempts to locate and decode enabled barcodes within its field of view. The decoder remains in this mode as long as the Scan button is pressed or until a barcode is decoded.
Page 138: Power Mode
Power Mode Note: LXE mobile devices are designed to be operated in Low Power Mode. LXE recommends leaving this value unchanged. Parameter Default Value: A parameter setting of Continuous On means the laser will not power down until the mobile device is powered off.
Page 139: Presentation Mode Session Timeout
SE4400 Imager Barcodes - Imager Parameters – General Presentation Mode Session Timeout This parameter, and the Presentation Mode parameter, are directed toward ring decoders that can scan a barcode that enters its field of view, determine a good read/bad read, then scan again. This parameter determines how long the ring decoder will attempt to decode a barcode before determining if it is a good read or a bad read.
Page 140: Time Delay To Low Power Mode
Time Delay to Low Power Mode Parameter Default Value: This parameter sets the time the decoder remains active after decoding. The decoder wakes upon a Scan button press or when the host attempts to communicate with the decoder. This parameter only applies when Power Mode is set to Low Power. See Power Mode. 1 Second Delay to Low Power Mode 5 Second Delay to Low...
Page 141: Time-Out Between Decodes, Same Symbol
SE4400 Imager Barcodes - Imager Parameters – General Time-out between Decodes, Same Symbol Parameter Default Value: This option is used in presentation mode to prevent multiple reads of a symbol left in the ring decoder’s field of view. The timeout begins when the barcode is removed from the field of view. It is programmable in 0.1 second increments from 0.0 to 9.9 seconds.
Page 142: Trigger Modes
Trigger Modes Note: HX2 and HX3 mobile devices with ring decoders are designed to be operated in Host Trigger Mode. LXE recommends leaving the Trigger Mode default value unchanged. Parameter Default Value: Use this parameter to determine when the laser is activated and decoding begins, how long the laser remains on and what determines the cessation of the laser scan and decode process.
Page 143: Transmit No Code Id Character
SE4400 Imager Barcodes - Imager Parameters – General Transmit Code ID Character Parameter Default Value: A code ID character identifies the code type of a scanned barcode. This may be useful when the imager is decoding more than one code type. In addition to any single character prefix already selected, the code ID character is inserted between the prefix and the decoded symbol.
Page 144: Transmit Aim Code Id Character
Transmit AIM Code ID Character Each AIM Code Identifier contains the three character string ]cm where: = Flag Character (ASCII 93) = Code Character = Modifier Character The modifier character is the sum of the applicable option values based on the following table. Code Type Code39...
Page 145 SE4400 Imager Barcodes - Imager Parameters – General Code Type I 2 of 5 Codabar Code 93 MSI Plessey D 2 of 5 UPC/EAN Bookland EAN Code 11 E-SW-RINGSCANPG-C Option Value Option Example: A Code (EAN) 128 barcode with Function 1 character in the first position, transmitted as ]ClAimId No check digit processing.
Page 146 Code Type GS1 DataBar (RSS) Family EAN.UCC Composites (GS1 DataBar (RSS), UCC/EAN-128, 2D portion of UPC composite) PDF417, Micro PDF417 Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - Imager Parameters – General Option Value Option No option specified at this time. Always transmit 0. GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS-Limited) transmit with an Application Identifier “01”.
Page 147 SE4400 Imager Barcodes - Imager Parameters – General Code Type Data Matrix MaxiCode QR Code According to AIM standards, a UPC with supplemental barcode is transmitted in the following format: ]EO (UPC chars) (terminator) ]E2 (supplemental) (terminator) Therefore, a UPC with two supplemental characters, 01234567890510, is transmitted to the host as a 21-character string, ]E00012345678905]E110.
Page 148: Prefix / Suffix Values
Prefix / Suffix Values SE4400 imager engine prefix and suffix parameters cannot be set, changed, or reset using the barcodes in this section. See previous section titled Prefix / Suffix for an explanation. Prefix (P) Parameter Default Value: Suffix1 (S1) Parameter Default Value: Suffix2 (S2) Parameter Default Value: Note: Parameter “Scan Data Transmission Format”...
Page 149: Suffix 2
SE4400 Imager Barcodes - Imager Parameters – General Suffix 2 To begin setting Suffix 2 value, scan this Scan Suffix 2 barcode: Next, scan four numeric barcodes that correspond to the computer keycode using the “Imager Keypad Number Symbols” at the end of this chapter. If you wish to change your numeric selection, scan Cancel on the “Imager Keypad Number Symbols”...
Page 150: Scan Data Transmission Format
Scan Data Transmission Format Parameter Default Value: Note: Parameter “Prefix/Suffix Values” should be set after setting this parameter. Use this option when you want to append a prefix and suffix to the decode data. Set this parameter by scanning one of the following barcodes. Data As Is [Data] [Suffix 1] [Data] [Suffix 2]...
Page 151: Transmit "No Read" Message
SE4400 Imager Barcodes - Imager Parameters – General [Prefix] [Data] [Suffix 2] [Prefix] [Data] [Suffix 1] [Suffix 2] Now you are ready to scan one of the “Prefix/Suffix Values” barcodes. Transmit “No Read” Message Parameter Default Value: Scan a barcode below to select whether or not to transmit a No Read message. When enabled, the characters NR are transmitted when a barcode is not decoded.
Page 152: Upc-A
UPC/EAN UPC-A Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable UPC-A Disable UPC-A UPC-E Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable UPC-E Disable UPC-E UPC-E1 Parameter Default Value: Select an option by scanning either of the barcodes shown below.
Page 153: Ean-8/Jan 8
SE4400 Imager Barcodes - UPC/EAN EAN-8/JAN 8 Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable EAN-8/JAN-8 Disable EAN-8/JAN-8 EAN-13/JAN 13 Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable EAN-13/JAN 13 Disable EAN-13/JAN 13 E-SW-RINGSCANPG-C...
Page 154: Bookland Ean
Bookland EAN Parameter Default Value: Select an option by scanning either of the barcodes shown below. Enable Bookland EAN Disable Bookland EAN Bookland Format Parameter Default Value: This parameter is used to control the Bookland Format. Select an option by scanning either of the barcodes shown below.
Page 155: Decode Upc/Ean/Jan Supplementals (2 And 5 Digits)
SE4400 Imager Barcodes - UPC/EAN Decode UPC/EAN/JAN Supplementals (2 and 5 digits) Parameter Default Value: Supplementals are barcodes appended according to specific format conventions (e.g. UPC A+2, UPC E+2, EAN 13+2). Six options are available: Note: In order to minimize the risk of invalid data transmission, we recommend that you select whether to read or ignore supplemental characters.
Page 156 Enable 978 Supplemental Mode Enable Smart Supplemental Mode Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - UPC/EAN The scanner will identify supplementals for EAN-13 barcodes that start with a 978 prefix only. All other UPC/EAN codes are decoded immediately and the supplemental characters ignored.
Page 157: Upc/Ean/Jan Supplemental Redundancy
SE4400 Imager Barcodes - UPC/EAN UPC/EAN/JAN Supplemental Redundancy Parameter Default Value: With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of times a symbol without supplementals is decoded before transmission. The range is from 2 to 30 times. Five or above is recommended when decoding a mix of UPC/EAN/JAN symbols with and without supplementals, and the autodiscriminate option is selected.
Page 158: Transmit Upc-E Check Digit
Transmit UPC-E Check Digit Parameter Default Value: This parameter determines whether the symbol will be transmitted with or without the UPC-E check digit. Select an option by scanning either of the barcodes shown below. Enable Transmit UPC-E Check Digit Disable Transmit UPC-E Check Digit Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - UPC/EAN...
Page 159: Upc-A Preamble
SE4400 Imager Barcodes - UPC/EAN Transmit UPC-E1 Check Digit Parameter Default Value: This parameter determines whether the symbol will be transmitted with or without the UPC-E1 check digit. Select an option by scanning either of the barcodes shown below. Enable Transmit UPC-E1 Check Digit Disable Transmit UPC-E1 Check Digit...
Page 160: Upc-E Preamble
UPC-E Preamble Parameter Default Value: A preamble is a lead-in character for UPC-E symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble System Character System Character and Country Code Select an option by scanning one of the barcodes shown below.
Page 161: Upc-E1 Preamble
SE4400 Imager Barcodes - UPC/EAN UPC-E1 Preamble Parameter Default Value: A preamble is a lead-in character for UPC-E1 symbols transmitted to the host device. The lead-in characters are considered part of the symbol. Data is sent to the host in the following format: No Preamble System Character System Character and Country Code...
Page 162: Convert Upc-E To Upc-A
Convert UPC-E to UPC-A Parameter Default Value: When this parameter is enabled, UPC-E (zero suppressed) decoded data is converted to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC- A programming selections (e.g. Preamble, Check Digit, etc.). When disabled, UPC-E (zero suppressed) decoded data is transmitted without conversion.
Page 163: Convert Upc-E1 To Upc-A
SE4400 Imager Barcodes - UPC/EAN Convert UPC-E1 to UPC-A Parameter Default Value: When this parameter is enabled, UPC-E1 (zero suppressed) decoded data is converted to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC- A programming selections (e.g.
Page 164: Ucc Coupon Extended Code
UCC Coupon Extended Code Note: UCC Coupon Extended Code replaces UPC/EAN Coupon Code. Parameter Default Value: The UCC Coupon Extended Code is an additional barcode adjacent to a UCC Coupon Code. To enable or disable UCC Coupon Extended Code, scan the appropriate barcode below. When enabled, this parameter decodes UPC-A barcodes starting with digit “5”, EAN-13 barcodes starting with digit “99”...
Page 165: Code 128
SE4400 Imager Barcodes - Code 128 Code 128 Parameter Default Value: Set this parameter by scanning either of the barcodes shown below. Enable Code 128 Disable Code 128 UCC/EAN-128 Parameter Default Value: Set this parameter by scanning either of the barcodes shown below. Enable UCC/EAN-128 Disable UCC/EAN-128 ISBT-128...
Page 166: Trioptic Code 39
Code 39 Parameter Default Value: Note: This parameter must be enabled when “Convert Code 39 to Code 32” is to be enabled. Set this parameter by scanning either of the barcodes shown below. Enable Code 39 Disable Code 39 Trioptic Code 39 Parameter Default Value: Trioptic Code 39 symbols always contain six characters.
Page 167: Convert Code 39 To Code 32
SE4400 Imager Barcodes - Code 39 Convert Code 39 to Code 32 Note: Code 39 must be enabled in order for this parameter to function. Parameter Default Value: Note: When parameter “Code 32 Prefix” is to be enabled, this Convert Code 39 to Code 32 (Italian Pharmacy Code) parameter must also be enabled.
Page 168: Set Length(S) For Code 39
Set Length(s) for Code 39 L1 Parameter Default Value: L2 Parameter Default Value: Lengths for Code 39 may be set for: • any length, • one or two discrete lengths, • or lengths within a specific range. The length of a code refers to the number of characters, including check digits, the code contains. If Code 39 Full ASCII is enabled, Length Within a Range or Any Length are the preferred options.
Page 169: Length Within Range
SE4400 Imager Barcodes - Code 39 Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 39 symbols containing between 4 and 12 characters, scan the “Code 39 Length Within Range”...
Page 170: Code 39 Check Digit Verification
Code 39 Check Digit Verification Parameter Default Value: When enabled, this parameter checks the integrity of a Code 39 symbol to ensure it complies with specified check digit algorithms. Only Code 39 symbols which include a Modulo 43 check digit are decoded when this parameter is enabled.
Page 171: Code 39 Full Ascii Conversion
SE4400 Imager Barcodes - Code 39 Code 39 Full ASCII Conversion Parameter Default Value: Note: Code 39 Full ASCII and Trioptic Code 39 should not be enabled simultaneously. Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set.
Page 172: Set Lengths For Code 93
Code 93 Parameter Default Value: L1 Parameter Default Value: L2 Parameter Default Value: When enabled, Code 93 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Code 93 Disable Code 93 Set Lengths for Code 93 L1 Parameter Default Value: L2 Parameter Default Value:...
Page 173: One Discrete Length (Parameter L1)
SE4400 Imager Barcodes - Code 93 One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only Code 93 symbols containing 14 characters, scan the “Code 93 One Discrete Length” barcode and then “1”...
Page 174: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only Code 93 symbols containing between 4 and 12 characters, scan the “Code 93 Length Within Range” barcode and then “0”, “4”, “1” and “2” barcodes using the “Imager Keypad Number Symbols”...
Page 175: Set Lengths For Code 11
SE4400 Imager Barcodes - Code 11 Code 11 Parameter Default Value: When enabled, Code 11 symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Code 11 Disable Code 11 Set Lengths for Code 11 L1 Parameter Default Value: L2 Parameter Default Value: Lengths for Code 11 may be set for:...
Page 176: Two Discrete Lengths (Parameter L2)
Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only Code 11 symbols containing 2 or 14 characters, scan the “Code 11 Two Discrete Lengths” barcode and then “0”, “2”, “1” and “4” barcodes using the “Imager Keypad Number Symbols”...
Page 177: Code 11 Check Digit Verification
SE4400 Imager Barcodes - Code 11 Code 11 Check Digit Verification Parameter Default Value: Enable this parameter by scanning either One Check Digit barcode or Two Check Digits barcode. When enabled, this parameter checks the integrity of a Code 11 symbol to ensure it complies with the specified check digit algorithm.
Page 178: Transmit Code 11 Check Digits
Transmit Code 11 Check Digits Parameter Default Value: Code 11 Check Digit Verification must be enabled for this parameter to function. Transmit (Enable) Code 11 Check Digits Do Not Transmit (Disable) Code 11 Check Digits Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - Code 11 Do Not Transmit (Disable) E-SW-RINGSCANPG-C...
Page 179: Interleaved 2 Of 5 (Itf)
SE4400 Imager Barcodes - Interleaved 2 of 5 (ITF) Interleaved 2 of 5 (ITF) Parameter Default Value: When enabled, Interleaved 2 of 5 (I 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Set Lengths for I 2 of 5...
Page 180: Two Discrete Lengths (Parameter L2)
Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only I 2 of 5 symbols containing 2 or 14 characters, scan the “I 2 of 5 Two Discrete Lengths”...
Page 181: I 2 Of 5 Check Digit Verification
SE4400 Imager Barcodes - Interleaved 2 of 5 (ITF) I 2 of 5 Check Digit Verification Parameter Default Value: When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification) or OPCC (Optical Product Code Council).
Page 182: Transmit I 2 Of 5 Check Digit
Transmit I 2 of 5 Check Digit Parameter Default Value: When enabled, the check digit is transmitted with the data. Parameter setting for “I 2 of 5 Check Digit Verification” has no effect on this parameter value. Set this parameter by scanning either of the barcodes shown below. Enable Transmit I 2 of 5 Check Digit Disable Transmit I 2 of 5...
Page 183 SE4400 Imager Barcodes - Interleaved 2 of 5 (ITF) Convert I 2 of 5 to EAN 13 Parameter Default Value: A successful barcode conversion requires the following to be true: • Interleaved 2 of 5 scanning is enabled. • One of the I 2 of 5 lengths is set to 14. •...
Page 184: Set Lengths For Discrete 2 Of 5
Discrete 2 of 5 (DTF) Parameter Default Value: When enabled, Discrete 2 of 5 (D 2 of 5) symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Discrete 2 of 5 Disable Discrete 2 of 5 Set Lengths for Discrete 2 of 5 L1 Parameter Default Value:...
Page 185: One Discrete Length (Parameter L1)
SE4400 Imager Barcodes - Discrete 2 of 5 (DTF) One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only D 2 of 5 symbols containing 14 characters, scan the “D 2 of 5 One Discrete Length” barcode and then “1”...
Page 186: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only D 2 of 5 symbols containing between 4 and 12 characters, scan the “D 2 of 5 Length Within Range” barcode and then “0”, “4”, “1” and “2” barcodes using the “Imager Keypad Number Symbols”...
Page 187: Codabar
SE4400 Imager Barcodes - Codabar Codabar Parameter Default Value: When enabled, Codabar symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable Codabar Disable Codabar CLSI Editing Parameter Default Value: When enabled, the start and stop characters are stripped from the barcode and a space is inserted after the 1 , and 10 Set this parameter by scanning either of the barcodes shown below.
Page 188: Notis Editing
NOTIS Editing Parameter Default Value: When enabled, the start and stop characters are stripped from a decoded Codabar symbol. Set this parameter by scanning either of the barcodes shown below. Enable NOTIS Editing Disable NOTIS Editing Set Lengths for Codabar L1 Parameter Default Value: L2 Parameter Default Value: Lengths for Codabar may be set for:...
Page 189: Two Discrete Lengths (Parameter L2)
SE4400 Imager Barcodes - Codabar Two Discrete Lengths (Parameter L2) This option decodes only those codes containing two selected lengths. For example, when you want to scan only Codabar symbols containing 2 or 14 characters, scan the “Codabar Two Discrete Lengths” barcode and then “0”, “2”, “1” and “4” barcodes using the “Imager Keypad Number Symbols”...
Page 190: Set Length(S) For Msi
Parameter Default Value: When enabled, MSI symbols will be scanned, decoded and transmitted. Set this parameter by scanning either of the barcodes shown below. Enable MSI Disable MSI Set Length(s) for MSI Length Within Range L1 Parameter Default Value: L2 Parameter Default Value: Lengths for MSI may be set for: •...
Page 191: One Discrete Length (Parameter L1)
SE4400 Imager Barcodes - MSI One Discrete Length (Parameter L1) This option decodes only those codes containing a selected length. For example, when you want to scan only MSI symbols containing 14 characters, scan the “MSI One Discrete Length” barcode and then “1”...
Page 192: Length Within Range
Length Within Range This option decodes a code type within a specified minimum and maximum range. For example, when you want to scan only MSI symbols containing between 4 and 12 characters, scan the “MSI Length Within Range” barcode and then “0”, “4”, “1” and “2” barcodes using the “Imager Keypad Number Symbols”...
Page 193: Msi Check Digits
SE4400 Imager Barcodes - MSI MSI Check Digits Parameter Default Value: With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits barcode to enable verification of the second check digit.
Page 194: Msi Check Digit Algorithm
MSI Check Digit Algorithm Parameter Default Value: With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits barcode to enable verification of the second check digit.
Page 195: Postal Codes
SE4400 Imager Barcodes - Postal Codes Postal Codes US Postnet Parameter Default Value: To enable or disable US Postnet, scan the appropriate barcode: Enable US Postnet Disable US Postnet US Planet Parameter Default Value: To enable or disable US Planet, scan the appropriate barcode: Enable US Planet Disable US Planet E-SW-RINGSCANPG-C...
Page 196: Uk Postal
UK Postal Parameter Default Value: To enable or disable UK Postal, scan the appropriate barcode: Enable UK Postal Disable UK Postal Transmit UK Postal Check Digit Parameter Default Value: Select whether to transmit UK Postal data with or without the check digit: Transmit UK Postal Check Digit Do Not Transmit UK Postal...
Page 197: Australian Postal
SE4400 Imager Barcodes - Postal Codes Australian Postal Parameter Default Value: To enable or disable Australian Postal, scan the appropriate barcode: Enable Australian Postal Disable Australian Postal Dutch Postal Parameter Default Value: To enable or disable Dutch Postal, scan the appropriate barcode: Enable Dutch Postal Disable Dutch Postal E-SW-RINGSCANPG-C...
Page 198: Transmit Us Postal Check Digit
Transmit US Postal Check Digit Parameter Default Value: Select whether to transmit US Postal data with or without the check digit: Transmit US Postal Check Digit Do Not Transmit US Postal Check Digit 4State Postal Parameter Default Value: To enable or disable 4State Postal, scan the appropriate barcode: Enable 4State Postal Disable 4State Postal Ring Scanner / Ring Imager Programming Guide...
Page 199: Gs1 Databar Omnidirectional (Rss-14)
SE4400 Imager Barcodes - GS1 DataBar (RSS) GS1 DataBar (RSS) Note: RSS (Reduced Space Symbology) has been replaced with GS1 DataBar. GS1 DataBar Limited (RSS Limited) and GS1 DataBar Expanded (RSS Expanded) versions have stacked variants. Scan the appropriate barcodes that follow to enable or disable each supported variant of GS1 DataBar (RSS).
Page 200: Gs1 Databar Expanded (Rss Expanded)
GS1 DataBar Expanded (RSS Expanded) Parameter Default Value: To enable or disable GS1 DataBar Expanded (RSS Expanded) , scan the appropriate barcode: Enable GS1 DataBar Expanded (RSS Expanded) Disable GS1 DataBar Expanded (RSS Expanded) Convert GS1 DataBar (RSS) to UPC/EAN Parameter Default Value: This parameter only applies to GS1 DataBar Omnidirectional (RSS-14) and GS1 DataBar Limited (RSS Limited) symbols not decoded as part of a Composite symbol.
Page 201: Composite Cc-C
SE4400 Imager Barcodes - Composite Composite Composite CC-C Parameter Default Value: Scan one of the following barcodes to enable or disable Composite barcodes of type CC-C. Enable Composite CC-C Disable Composite CC-C Composite CC-A/B Parameter Default Value: Scan one of the following barcodes to enable or disable Composite barcodes of type CC-A/B. Enable Composite CC-A/B Disable Composite CC-A/B Composite TLC-39...
Page 202: Upc Composite Mode
UPC Composite Mode Parameter Default Value: UPC symbols can be linked with a 2D symbol during transmission as if they were one symbol. There are three options for these symbols: UPC Never Linked Transmit UPC barcodes regardless of whether a 2D symbol is detected.
Page 203: Ucc/Ean Code 128 Emulation Mode
SE4400 Imager Barcodes - Composite UCC/EAN Code 128 Emulation Mode Select whether to enable or disable UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes. Parameter Default Value: Enable UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes Disable UCC/EAN Code 128 Emulation Mode for UCC/EAN Composite Codes E-SW-RINGSCANPG-C...
Page 204: D Symbologies
2D Symbologies PDF417 Parameter Default Value: To enable or disable PDF417, scan the appropriate barcode below. Enable PDF417 Disable PDF417 MicroPDF417 Parameter Default Value: To enable or disable MicroPDF417, scan the appropriate barcode below. Enable MicroPDF417 Disable MicroPDF417 Ring Scanner / Ring Imager Programming Guide SE4400 Imager Barcodes - 2D Symbologies Enable Disable...
Page 205: Code 128 Emulation
SE4400 Imager Barcodes - 2D Symbologies Code 128 Emulation Parameter Default Value: To enable or disable Code 128 Emulation, scan the appropriate barcode below. Enable Code 128 Emulation Disable Code 128 Emulation When this parameter is enabled, the scanner transmits data from certain MicroPDF417 symbols as if it was encoded in Code 128 symbols.
Page 206: Data Matrix
Data Matrix Parameter Default Value: To enable or disable Data Matrix, scan the appropriate barcode below. Enable Data Matrix Disable Data Matrix Data Matrix Inverse Parameter Default Value: This parameter controls the setting of the DataMatrix inverse decoder. Scan the appropriate barcode below.
Page 207: Maxicode
SE4400 Imager Barcodes - 2D Symbologies Maxicode Parameter Default Value: To enable or disable Maxicode scan the appropriate barcode below. Enable Maxicode Disable Maxicode QR Code Parameter Default Value: To enable or disable QR Code scan the appropriate barcode below. Enable QR Code Disable QR Code E-SW-RINGSCANPG-C...
Page 208: Microqr
MicroQR Parameter Default Value: To enable or disable MicroQR scan the appropriate barcode below. Enable MicroQR Disable MicroQR QR Inverse Parameter Default Value: This parameter controls the setting of the QR Inverse decoder. Scan the appropriate barcode below. Regular Only Inverse Only Inverse Auto Detect Ring Scanner / Ring Imager Programming Guide...
Page 209: Aztec
SE4400 Imager Barcodes - 2D Symbologies Aztec Parameter Default Value: To enable or disable Aztec scan the appropriate barcode below. Enable Aztec Disable Aztec Aztec Inverse Parameter Default Value: This parameter controls the setting of the Aztec Inverse decoder. Scan the appropriate barcode below.
Page 210: Redundancy Level
Redundancy Level Parameter Default Value: The decoder offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality. As redundancy levels increase, the decoder’s aggressiveness decreases. Select the redundancy level appropriate for the barcode quality and select from the barcodes on the following page.
Page 211 SE4400 Imager Barcodes - Redundancy Level Redundancy Level 1 Redundancy Level 2 Redundancy Level 3 Redundancy Level 4 E-SW-RINGSCANPG-C Ring Scanner / Ring Imager Programming Guide Cancel...
Page 212: Security Level
Security Level Parameter Default Value: The decoder offers four levels of decode security for delta bar codes, which include the Code 128 family, UPC/EAN, and Code 93. Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and decoder aggressiveness, so choose only that level of security necessary for any given application.
Page 213: Intercharacter Gap Size
SE4400 Imager Barcodes - Security Level Intercharacter Gap Size Parameter Default Value: The Code 39 and Codabar symbologies have an intercharacter gap that is typically quite small. Due to various bar code-printing technologies, this gap can grow larger than the maximum size allowed, preventing the decoder from decoding the symbol.
Page 214: Imager Keypad Number Symbols
Imager Keypad Number Symbols The barcode labels shown below represent a numeric keypad, with decimal values 0 through 9. Each label can be scanned individually to enter a numeric value. Use these numeric value symbols to enter numeric input in the course of performing an imager engine system configuration.
Page 215 SE4400 Imager Barcodes - Imager Keypad Number Symbols E-SW-RINGSCANPG-C Cancel Ring Scanner / Ring Imager Programming Guide...
Page 216 SE4400 Imager Barcodes - Imager Keypad Number Symbols Ring Scanner / Ring Imager Programming Guide E-SW-RINGSCANPG-C...
Page 217: Scanner Identification Label
Chapter 4 Scan Engine Technical Specifications Scanner Identification Label The label specifying which laser engine is installed in the LXE mobile device is usually on the back of the mobile device, next to the laser warning label. Decode Zones The scan ranges listed in the following tables are based on the following factors: •...
Page 218: Se955-I000Wr Standard Range Laser Scanner
SE955-I000WR Standard Range Laser Scanner Factory Default Scan Angle – Wide (47°) Typical Working Ranges Symbol Density Near 4 mil 1.0 in / 2.50 cm 5 mil 1.25 in / 3.18 cm 7.5 mil 1.50 in / 3.81 cm 10 mil 1.50 in / 3.81 cm 13 mil 1.50 in / 3.81 cm...
Page 219: Se4400 Laser Imager
Scan Engine Technical Specifications - Decode Zones SE4400 Laser Imager Near Focus Decode Distances PL4407 Typical Working Ranges Symbol Density Near 5.0 mil 3.5 in / 8.9 cm 6.67 mil 3.75 in / 9.5 cm 7.5 mil 2.75 in / 7.0 cm 10 mil 3.25 in / 8.3 cm 13 mil...
Page 220: Far Focus Decode Distances Stopped Here
Far Focus Decode Distances stopped here PL4407 Symbol Density Near 5.0 mil 6.5 in / 16.5 cm 6.67 mil 7.5 mil 4.25 in / 10.8 cm 10 mil 5.75 in / 14.6 cm 13 mil 3.0 in / 7.6 cm 15 mil Note 1 20 mil...
Page 221: Pl4407
Scan Engine Technical Specifications - Decode Zones Toggled Focus Decode Distances PL4407 Typical Working Ranges Symbol Density Near 5.0 mil 3.5 in / 8.9 cm 6.67 mil 3.75 in / 9.5 cm 7.5 mil 2.75 in / 7.0 cm 10 mil 3.25 in / 8.3 cm 13 mil 2.25 in / 5.7 cm...
Page 222: Pl4407
Decode Distances in Darkness PL4407 MS4407 – Not Applicable Symbol Density 5.0 mil 6.67 mil 7.5 mil 10 mil 13 mil Notes: 1. Near distances are FOV limited. 2. Working range specifications at temperature = 23°C, pitch=15°, roll=0°, skew=0°, photographic quality, humidity 45-70%RH. 3.
Page 223: Figure 4-6 Ascii Character Equivalents
Scan Engine Technical Specifications - ASCII Character Equivalents ASCII Character Equivalents Values from 1128 through 1255 (hex values 80h through FFh) may also be set. But the conversion of those characters to printable characters is not standardized. the table. Scan Value 1000 1001 1002...
Page 224 Scan Value 1031 1032 1033 1034 1035 1036 1037 1038 1039 1040 1041 1042 1043 1044 1045 1046 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 1061 1062 1063 1064 1065 1066 1067 Ring Scanner / Ring Imager Programming Guide Scan Engine Technical Specifications - ASCII Character Equivalents Hex Value Full ASCII Code 39 Encode Char.
Page 225 Scan Engine Technical Specifications - ASCII Character Equivalents Scan Value 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100...
Page 226 1124 1125 1126 1127 Beep Related Programming Barcodes for Ring Scanners and Ring Imagers are not supported by LXE. Ring Scanner / Ring Imager Programming Guide Scan Engine Technical Specifications - ASCII Character Equivalents Hex Value Full ASCII Code 39 Encode Char.
Page 227: Revision History
• Chapter 1 – Introduction - Included HX3 as a device that can use the same tethered ring scanners as the HX2. Added HX3 and MX8 to Identify Your Barcode Scanner Type • Chapter 3 – SE4400 Imager Barcodes - Updated. Noted differences between default values for PL4407 Ring Imager and MS4407 Ring Imager.
Page 228 Scan Engine Technical Specifications - Revision History Ring Scanner / Ring Imager Programming Guide E-SW-RINGSCANPG-C...
Page 229: Index
2D Imager...5 4State Postal SE4400...188 ACK NAK Handshaking ...46 Symbology Identifiers SE955 ...59 AIM Code UPC with Supplemental Characters SE4400 ...137 SE955 ...32 AIM Code Identifier SE4400...134 SE955...31 AIM Code Modifier SE4400...134 SE955...31 Aim Duration...10 SE955...24 Aiming Dot ...10 Duration ...10 Mode ...10 Algorithm SE4400 ...184...
Page 230 Cancel SE955 Parameter Scanning ...36 CE Control Panel Scanner panel...122 Change scanning parameters ...2 Character Equivalents, ASCII ...213 Check Digit I 2 of 5...80, 172 SE4400 ...171 SE955 ...76 MSI Plessey SE955 ...82 Verification, Code 11 SE4400 ...167 SE955 ...57 Verification, Code 39 SE4400 ...160 SE955 ...62...
Page 231 Code ID Character SE4400...133 SE955...30 Composite CC-A/B SE4400...115, 191 Composite CC-C SE4400...115, 191 Composite TLC-39 SE4400...116, 191 Contacting LXE...8 Convert Code 39 to Code 32 SE955 ...63 EAN-8 to EAN-13 SE955 ...92 I 2 of 5 to EAN-13 SE4400 ...173 SE955 ...77 UPC-E to UPC-A SE4400 ...152...
Page 232 Discrete 2 of 5 SE4400...174 SE955...72 Discrete Length Codabar SE4400 ...178 SE955 ...53 Code 11 SE4400 ...165 SE955 ...56 Code 39 SE4400 ...158 SE955 ...65, 66 Code 93 SE4400 ...163 SE955 ...70 D 2 of 5 SE4400 ...175 SE955 ...73 I 2 of 5 SE4400 ...169 SE955 ...78...
Page 233 MSI Plessey SE955 ...84 Lengths for I 2 of 5 ...78, 169 Linear Code Type Security Level and Bi-Directional Redundancy...25 SE955...34 Getting Help...8 LXE Tethered Scanners and Bluetooth ...3 Manuals on the WWW ...8 Maxicode SE4400...197 MaxiCode AIM Code SE4400...137 MicroPDF417 SE4400...194...
Page 234 SE4400 ...182 MSI Plessey SE955 ...84 Mod 10/Mod 10 SE4400...184 SE955...81 Mod 10/Mod 11 SE4400...184 SE955...81 modulo 43 check digit SE4400...160 SE955...62 Any Length SE4400 ...182 Check Digit Algorithm SE4400 ...184 Length Within Range SE4400 ...182 One Discrete Length SE4400 ...181 Two Discrete Lengths SE4400 ...181 MSI Check Digit...85...
Page 235 SE4400...140 SE955...28 Scan Data Transmission Format SE4400...140 SE955...28 Scan Range ...207 Scan Value...213 Scan, function ...5 Scanner Performance LXE Support ...7 Scanner Power Mode SE955...37 Scanner Setup How To ...4 SE4400 Barcode Types ...112 SE4400 Defaults Codabar Lengths SE4400 ...178 Code 11 Lengths SE4400 ...165...
Page 236 SE955 ...89 UPC-E Check Digit SE4400 ...148 SE955 ...89 UPC-E1 Check Digit SE4400 ...149 SE955 ...90 Transmit Check Digit, Code 11 SE4400...168 SE955...58 Transmit Code 39 Check Digit and Code 39 Check Digit Verification SE4400 ...160 SE955 ...67 Transmit Code ID Character SE4400...133 SE955...30 Transmit No Read Message...
Page 237 Index SE955 ...90 Preamble SE4400 ...151 SE955 ...95 SE4400...142 SE955...87 to UPC-A SE4400 ...153 SE955 ...91 US Planet SE4400...185 US Postal data SE4400...188 US Postnet SE4400...185 User guides on the WWW ...8 USS (Uniform Symbology Specification) SE4400...171 SE955...76 USS-128 SE4400...155 SE955...59 E-SW-RINGSCANPG-C Verify Check Digit...
Page 238 Index Ring Scanner / Ring Imager Programming Guide E-SW-RINGSCANPG-C...

This manual is also suitable for:

Hx3

LXE HX2 Programming Manual

Chapter 1 Introduction

Barcodes and Scanner Engines

LXE Mobile Devices with Integrated Scanners

LXE Tethered Scanners and Bluetooth Scanners

Identify Your Barcode Scanner Type

How to

Cleaning the Beam Aperture

Troubleshooting

Printing Barcodes in this Guide

Miscellaneous Programmable Barcodes

Factors that May Impact Scanner Performance

Getting Help

Chapter 2 SE955 Laser Barcodes

Introduction

Scanner Identification Label

Aiming Modes

Prefix / Suffix

Pre-Configured Default Values

Frequently Used Barcodes - SE955

Reset/Cancel Barcodes

Configure the Decoder for Barcode Types

Scanner Parameters - General

Aim Duration

Bi-Directional Redundancy

Data Options

Laser on Time

Linear Code Type Security Level (Redundancy Level)

Parameter Scanning

Power Mode

Scan Angle

Set Default Parameter

Simple Serial Interface (SSI) Options

Trigger Mode

Scanner Parameters - SE955 Barcode Type Specific

Chinese 2 of 5

Codabar

Code 11

Code 128

Code 39

Code 93

Discrete 2 of 5

Interleaved 2 of 5

MSI Plessey

Upc/Ean

UCC Coupon Extended Code

GS1 Databar Codes (RSS Codes)

GS1 Databar Omnidirectional (RSS-14)

Keypad Number Symbols

Chapter 3 Se4400 Imagerbarcodes

Imager Identification Label

Enable / Disable Parameter Scanning

Configure Imager for Barcode Types

Decode Session Timeout

Decode Aiming Pattern

Decoding Autoexposure

Decoding Illumination

Focus Mode

LED Illumination

Operational Mode

Presentation Mode Session Timeout

Report Version

Time Delay to Low Power Mode

Time-Out between Decodes, same Symbol

Trigger Modes

Prefix / Suffix Values

Upc-A

Upc-E1

Ean-8/Jan 8

Ean-13/Jan 13

Bookland Format

Decode UPC/EAN/JAN Supplementals (2 and 5 Digits)

UPC/EAN/JAN Supplemental Redundancy

Transmit UPC-E1 Check Digit

UPC-A Preamble

Convert UPC-E to UPC-A

EAN-8/JAN-8 Extend

Code 128

Convert Code 39 to Code 32

Set Length(S) for Code 39
