Summit Client Configuration

Summit Tray Icon

The Summit tray icon
The Summit tray icon is displayed when:
• The Summit radio is installed and active.
• The Windows Zero Config utility is not active.
• The Tray Icon setting is On.
Tap the icon to launch the Summit Configuration Utility.
Use the tray icon to view the link status:
Summit client is not currently associated or authenticated to an Access Point.
The signal strength for the currently associated/authenticated Access Point is -80
dBm or weaker.
The signal strength for the currently associated/authenticated Access Point is
stronger than -80dBm but not stronger than -60 dBm.
The signal strength for the currently associated/authenticated Access Point is
stronger than -60 dBm but not stronger than -40 dBm.
The signal strength for the currently associated/authenticated Access Point is
stronger than -40 dBm.
E-EQ-HX2RG-D
provides access to the SCU and is a visual indicator of link status.
185
