LXE MX3X Reference Manual

Hide thumbs Also See for MX3X:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Programming Manual, Reference Manual
MX3X Reference Guide
Copyright © June 2004 by LXE Inc.
All Rights Reserved
E-EQ-MX3XRG-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX3X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LXE MX3X

Summary of Contents for LXE MX3X

  • Page 1 MX3X Reference Guide Copyright © June 2004 by LXE Inc. All Rights Reserved E-EQ-MX3XRG-A...
  • Page 2 Notices LXE Inc. reserves the right to make improvements or changes in the products described in this guide at any time without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, LXE assumes no liability resulting from any errors or omissions in this document, or from the use of the information contained herein.

  • Page 3: Table Of Contents

    Set The Display Contrast ........................16 Set the Display Backlight Timer ......................16 Set The Display Brightness......................... 16 Set the MX3X Power Schemes Timers....................17 Set The Audio Speaker Volume......................18 Using the Keypad ..........................18 Using the Touch Screen........................18 ActiveSync –...
  • Page 4 PCMCIA Slots ............................ 32 Power Modes......................33 Primary Events Listing........................33 On Mode ............................. 34 The Display ............................34 The MX3X............................34 User Idle Mode ..........................34 System Idle Mode..........................35 Suspend Mode............................. 35 Critical Suspend Mode........................36 Off Mode............................. 36 Physical Controls....................
  • Page 5 Software Load ............................. 62 Software Applications ........................62 Desktop........................63 My Computer Folders ......................... 64 Start Menu Program Options ................. 65 Cisco – Aironet Client Utility (ACU) ....................66 Profiles Tab ............................66 Firmware Tab ........................... 66 E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 6 Mouse..............................81 Network and Dialup Connections ....................... 81 Owner..............................81 Password ............................. 82 PC Connection ............................ 83 PCMCIA ............................. 84 Power ..............................85 Battery .............................. 85 Schemes............................85 Battery Power Scheme........................86 AC Power Scheme ......................... 86 MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 7 Device Name ............................ 93 Copyrights ............................93 Volume and Sounds ..........................94 Good Scan and Bad Scan Sounds..................... 94 Backup MX3X Files using ActiveSync ..............95 Prerequisites ............................95 MX3X and ActiveSync Partnership ....................95 Serial Port Transfer........................... 95 Infrared Port Transfer ........................95 USB Transfer............................
  • Page 8 Table of Contents PPENDIX Keypad ........................105 Key Map 101-Key Equivalencies ..................... 105 Creating Custom Key Maps for the MX3X............110 Introduction............................110 Programmable Scan Buttons and Custom Key Mapping..............111 Keymap Source Format........................111 COLxROWx Format ........................111 GENERAL Section ........................112 SPECIAL Section...........................
  • Page 9 Figure 2-5 Endcap Configurations........................38 Figure 2-6 RS-232 Pinouts ..........................40 Figure 2-7 9-Pin RS-232 Description ........................40 Figure 2-8 MX3X Serial Port and Compatible Cables ..................41 Figure 2-9 USB-Host to Serial Port Cable Pinouts....................41 Figure 2-10 USB-Client to Serial Port Cable Pinouts..................42 Figure 2-11 Programmable Buttons........................43...
  • Page 10 Figure 4-16 Stylus Properties / Recalibration ....................91 Figure 4-17 System / General tab ........................92 Figure 4-18 System / Memory ...........................93 Figure 4-19 System / Device Name ........................93 Figure 4-20 Volume and Sounds ........................94 Figure 4-21 Pinout – Serial Cable for Synchronization ..................99 MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 11: Chapter 1 Introduction

    The MX3X is a rugged, portable, hand-held Microsoft® Windows® CE .NET equipped computer capable of wireless data communications. The MX3X can transmit information using a 2.4 GHz radio (with an internally mounted antenna) and it can store information for later transmission through an RS-232, InfraRed, or USB port.

  • Page 12: Components

    Charger LED Ctrl LED Scan or Enter (programmable) Note: The programmable Scan key (see number 3) is the Field Exit key when the MX3X is an IBM 5250 / TN5250 compatible device. Figure 1-2 Standard Endcap DC Power Jack Serial Com 1 or USB Client Port...

  • Page 13: When To Use This Guide

    This guide takes you through all aspects of installation and configuration for the LXE MX3X. Operating and safety instructions for the general user are contained in the “MX3X User’s Guide.” This chapter, “Introduction”, describes this reference guide's structure, contains setup and installation instruction, briefly describes data entry processes, and explains how to get help.

  • Page 14: Document Conventions

    Keyword that indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. DANGER Keyword that indicates a imminent hazardous situation which, if not avoided, will result in death or serious injury. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 15: Getting Started

    When necessary, protect the work surface, MX3X, and components from electrostatic discharge. Use this guide as you would any other source book -- reading portions to learn about the MX3X, and then referring to it when you need more information about a particular subject. This guide takes you through an introduction to and operation of the LXE MX3X.

  • Page 16: About Lithium-Ion Batteries

    Li-Ion batteries (like all batteries) gradually lose their capacity over time (in a linear fashion) and never just stop working. This is important to remember -- the MX3X is always 'on' even when in the Suspend state and draws battery power at all times. Use the Start | Settings | Control Panel | Power | Battery tab to check the battery status and power reading.

  • Page 17: Attach Handstrap (Optional)

    Stylus Clip so that the ends don’t interfere with placing the stylus in the Stylus Clip or placing the MX3X in a cradle. Place the stylus in the Stylus Clip when not in use.

  • Page 18: Attach To Hip-Flip (Optional)

    #1 flat head screwdriver is not supplied by LXE. A waist belt can be ordered from LXE. Once the MX3X is attached to the hip-flip and the hip-flip securely fastened to the user by a belt around their waist, the MX3X can be operated at a convenient height, leaving the user's hands free.

  • Page 19: Connect External Power Supply (Optional)

    Figure 1-8 US AC/DC 12V Power Supply and Automotive Power Adapter Figure 1-9 International AC/DC 12V Power Supply The MX3X DC power jack is located on the endcap. The cradle power jack is located on the back of the cradle.

  • Page 20: Connect Audio Jack (Optional)

    The MX3X audio jack is located on the endcap. Figure 1-11 Connect Audio Jack Insert the 2.5mm barrel end of the connector into the MX3X audio jack and push in firmly. Note: The audio option draws power from the battery.

  • Page 21: Tapping With A Stylus

    • Place the cursor in a text box prior to typing in data or retrieving data using the integrated barcode scanner or an input/output device connected to the serial port. An extra or replacement stylus can be ordered from LXE. See the section titled "Accessories" for the stylus part number.

  • Page 22: Touch Screen Calibration

    Getting Started Touch Screen Calibration If the MX3X is not responding properly to pen touch taps, you may need to recalibrate your screen. Recalibration involves tapping the center of a target. If you miss the center, keep the stylus on the screen, slide it over the target's center, and then lift the stylus.

  • Page 23: Radio And Network Setup

    Insert a fully charged battery and power up the computer (or connect the computer to an external power source). Set Up the Symbol Radio When the MX3X boots up for the first time and all programs are loaded, the NETWLAN1 windows appears. Select the Wireless Information tab. Select Add New.

  • Page 24: Set Up The Cisco Radio

    If the access point uses authentication protocol (LEAP, etc.) your radio must use the same authentication keys. Please contact your IS department for LEAP encryption keys before contacting LXE. LEAP is an authentication protocol used to encrypt data sent and received from the MX3X to the access point.

  • Page 25: Access Terminal Emulation Parameters

    LAN (802.11B), make sure your mobile client is communicating with the Access Point. 2. From the Start | Programs, run LXE RFTerm or tap the RFTerm icon on the desktop. 3. Select Session | Configure from the application menu and select the "host type" that you require.

  • Page 26: Set The Display Contrast

    Select Start | Settings | Control Panel | Display | Backlight tab. Change the parameter values and tap OK to save the changes. The first option affects the MX3X when it is running on battery power only. The second option affects the MX3X when it is running on external power (e.g. AC adapter, cigarette adapter, powered cradle).

  • Page 27: Set The Mx3X Power Schemes Timers

    Switch state to Suspend: Default is After 5 minutes AC Power Scheme Use this option when the MX3X will be running on external power (e.g. AC adapter, cigarette adapter, powered cradle). Switch state to User Idle: Default is After 2 minute...

  • Page 28: Set The Audio Speaker Volume

    The volume is increased or decreased one step each time the volume key is pressed. The MX3X has an internal speaker and a jack for an external headset. Operational “beeps” are emitted from the speaker.

  • Page 29: Activesync - Initial Setup

    The default is 57600 baud. This will set up the MX3X to use COM 1. If the MX3X has a dual-serial port endcap, the Serial 3 @ 57600 can also be selected. Click OK and ensure the check box for "Allow connection with desktop computer when device is attached"...

  • Page 30: Radio

    Note: You must establish a partnership with a desktop computer prior to running ActiveSync on the MX3X. The initial partnership must be done using direct serial / USB cable connection. Once the relationship is established using the serial port, the ActiveSync link in the Start Menu gives a choice of connections, one of which is radio.

  • Page 31: Endcaps

    Rear IR Port is COM2 Barcode scanners, tethered to the serial port on a cradle, send ASCII data to the MX3X in the cradle through the COM2 Port. See “Chapter 2 Physical Description and Layout”, section titled “Endcaps” for further information.

  • Page 32: Pcmcia And Cf Cards

    Slot 1 – Compact Flash Card The MX3X has one internal Compact Flash card port that supports Type I and II CF+ cards. The slot is accessible when the endcap has been loosened. When removing or installing PCMCIA or CF cards, protect the MX3X internal components from electrostatic discharge.

  • Page 33: Installing / Removing Cards

    2. Use caution not to pull or snag the antenna connector on the Radio card, if installed. If you anticipate keeping the card out of the MX3X for a long period of time place it in an enclosed electrostatic-protected storage container. Store in an area that is protected from dirt, moisture, and electrostatic contact.

  • Page 34: Enter Data

    The keypad is used to manually input data that is not collected otherwise. Almost any function that a full sized computer keyboard can provide is duplicated on the MX3X keypad but it may take a few more keystrokes to accomplish a keyed task.

  • Page 35: Integrated Laser Scanner Data Entry

    To scan with the integrated laser barcode reader, point the laser window towards a barcode and press the Scan button. You will see a red laser beam strike the barcode. The MX3X has an SE923 scan engine. Correct Scan...

  • Page 36: Getting Help

    LXE website. Contact your LXE representative to obtain the LXE Manuals CD. You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals CD, in the file titled "Contacting LXE". This information is also available on the LXE website www.lxe.com.
  • Page 37 Cable, D9F to D9F for ActiveSync only, 6’ See Note MX3XA070CBLD9RS232AS Note: The MX3X Desktop Cradle supports RS-232 ActiveSync communication via the MX3XA070CBLD9RS232AS cable. Cable, USB Host D9F to USB, 6’ (Endcap only) Cable, D9F to D9F for ActiveSync only, 6’ (Cradle use only) Cable, USB Client D9F to USB, 6’...
  • Page 38 Getting Help MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 39: Chapter 2 Physical Description And Layout

    Chapter 2 Physical Description and Layout Hardware Configuration System Hardware The MX3X hardware configuration is shown in the following figure. Figure 2-1 System Hardware E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 40: Central Processing Unit

    (which appears in My Computer as the folder “System”). Any programs or data stored in this folder will not be lost if the memory backup battery fails. The computer has one Type II CF+ slot. The MX3X supports and auto detects up to 256MB of Type I compact flash memory.

  • Page 41: Power Supply

    Power to the COM ports may be turned on and off using the Control Panel option "Scanner". COM Port Switching The COM 2 port is always the IR port on the back of the MX3X, regardless of the type of endcap installed.

  • Page 42: Audio Interface

    Make sure the proper software is pre-loaded and PC cards are properly configured. There is one PC card slot (Slot 0) and one Compact Flash card slot (Slot 1) in the MX3X. Slot 0 powers a radio PC card, PC SRAM card, ATA Flash card or a linear Flash card. The slots hold only one card at a time.

  • Page 43: Power Modes

    Figure 2-2 Power Modes – On, Suspend, Critical Suspend and Off Primary Events Listing Any key on the keypad COM1 activity Stylus touch on the touch screen COM2 activity Power button tap COM3 activity PC card activity USB client connection External power connection Scanner activity E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 44: On Mode

    • when the Main Battery is hot-swapped, the display is turned Off. The MX3X After a new MX3X has been received, a charged Main Battery inserted, and the Power button tapped, the MX3X is always On until both batteries are drained completely of power.

  • Page 45: System Idle Mode

    Once the display is On, the keyboard and touch screen function normally. Suspend Mode The Suspend mode is entered when the MX3X is inactive for a predetermined period of time, the user taps the Power button or the user selects Start | Suspend.

  • Page 46: Critical Suspend Mode

    PCMCIA card. When the MX3X is in the Critical Suspend state (the Main Battery is in place and the unit is being powered by the Backup Battery), the display turns off, the BATT M LED begins to flash red, all peripherals are shut down, the CPU clock is stopped, and power is removed from the PCMCIA card.

  • Page 47: Physical Controls

    MX3X for the first time, the Power button must be pressed. Figure 2-3 Location of the Power (PWR) Button Quickly tapping the Power button places the MX3X immediately in Suspend mode. Quickly tapping the Power button again, or touching the screen, immediately returns the MX3X from Suspend. Reboot Sequence Tap the Start button then tap Restart.

  • Page 48: Endcaps

    Physical Controls Endcaps The MX3X supports three COM port options. Two external serial ports are dependent on the end cap chosen. A third serial port is used to support an infrared transceiver (barcode reader). An additional endcap configuration supports USB input/output at 12 Mbps.

  • Page 49: Integrated Scanner Port

    The internal barcode scanner scans only when the Scan button is pressed. Scan buttons have no effect on tethered barcode scanners connected to a serial port on the MX3X or to the serial port on a cradle holding an MX3X. The SCNR LED illuminates during any MX3X internal scanner activation.

  • Page 50: Serial Port

    Description Carrier Detect Receive Data - Input Transmit Data - Output Data Terminal Ready Signal/Power Ground Data Set Ready Ready To Send Clear To Send Ring Indicator - Input +5V DC Figure 2-7 9-Pin RS-232 Description MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 51: Usb Host / Client Port

    USB Host / Client Port Note: Do not connect a tethered scanner cable to an MX3X USB-C or USB-H labeled endcap port. These ports cannot power a tethered scanner. USB Host / Client connection is made through an optional USB Serial Port if installed. The connector is an industry-standard 9-pin “D”...

  • Page 52: Usb Client Cable

    Tethered scanners read barcode scans only when the trigger on the tethered scanner is pressed. The tethered scanner requires power on pin 9 of the MX3X serial port. To set the MX3X to use a tethered scanner, select Start | Settings | Control Panel | Scanner | COM1 (or 2 or 3).

  • Page 53: Scan Buttons

    The default setting for the right button is Enter. The default setting for the left button is Scan. When the MX3X does not have an integrated scanner, both buttons default to Enter keys and the Scan selection is greyed out.

  • Page 54: The Keypad

    Function Scan (MX3X's with Scanner endcaps only.) The Scan key activates the scanner when a scanner endcap is installed and the Scan button is pressed. The internal scanner scans only when the Scan button is pressed. A Scan button press has no effect on externally attached scanners.

  • Page 55: Caps Key And Capslock Mode

    The Field Exit key is used to exit an input field. If the field is an Auto Enter field, the auto transmit function is activated. This key function is present on the IBM 5250/TN5250 specific keypad only. Keypress Sequences See Appendix A for all key press sequences. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 56: Custom Key Maps

    To return to the default keymap, select 0409 from the keymap popup and click OK. Note: MX3X and Custom Key Maps: before connecting to a host using Remote Desktop Connection, go to Start | Settings | Control Panel | Keyboard and select 0409 from the keymap popup.

  • Page 57: Led Functions

    • Blinking Red – power fail. • Unlit - Main Battery is fully charged. Charger. When on, the MX3X is receiving external power either from the DC power CHGR jack or the MX3X is seated in a powered cradle. •...

  • Page 58: Display

    Display Display The MX3X Touch Screen Display is an LCD unit capable of supporting VGA graphics modes. Display size is 640 x 240 pixels. The display covering is designed to resist stains. The touch screen allows signature capture and touch input. A pen stylus is included. The touch screen responds to an actuation force (touch) of 4 oz.

  • Page 59: Applying The Protective Film To The Display

    Use a clean, damp, lint-free cloth. Do not scrub optical surfaces. If possible, clean only those areas which are soiled. Lint/particulates can be removed with clean, filtered canned air. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 60: Speaker

    The MX3X uses IrDA protocol to send data in both directions, but not simultaneously. When sending data through the IR port, make sure the IR port on the first MX3X and the IR port on the second MX3X are in close proximity to each other. IrDA is not required and not used by terminal emulation programs.

  • Page 61: Storage Cradles

    The MX3X Desktop cradle Product Number is 2381A002DESKCRADLE. There are two types of cradles for LXE's MX3X mobile computer: a desk top cradle for tabletop charging / communication applications and a vehicle mount cradle for vehicle mounted charging / communication applications.
  • Page 62 Storage Cradles MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 63: Chapter 3 Power Supply

    Battery Pack that can be recharged separately by an LXE approved battery charging unit. The Main Battery is recharged, if required, while installed in a powered cradle or when the MX3X is connected to external power using the power jack. There is a 50 mAh Nickel-Cadmium (NiCd) Backup Battery inside the MX3X that is recharged only by the Main Battery Pack.

  • Page 64: Handling Batteries Safely

    The main battery pack has a rugged plastic enclosure that is designed to withstand the ordinary rigors of an industrial environment. Exercise care when transporting the battery pack making sure it does not come in contact with excessive heat or any power source other than the LXE Multi- Charger or the MX3X unit.

  • Page 65: Battery Hot-Swapping

    Battery Hot-Swapping Battery Hot-Swapping When the main battery power level is low, the MX3X will signal the user with a warning dialog box on the display and the BATT M LED illuminates red. The Batt-M LED is illuminated until the main battery is replaced, the battery completely depletes, external power is applied to the MX3X using the power jack, or the MX3X is placed in a powered cradle.

  • Page 66: Backup Battery

    Li-Ion batteries (like all batteries) gradually lose their capacity over time (in a linear fashion) and never just stop working. This is important to remember -- the MX3X is always 'on' even when in the Suspend state and draws battery power at all times. Use the Start | Settings | Control Panel | Power | Battery tab to check the battery status and power reading.

  • Page 67: Battery Chargers

    LXE recommends that the correct MX3 Multicharger Plus always be used to charge the MX3X main battery pack. The Multicharger plus label is located on the back of the device and the charger must have been upgraded to V1.01. Please contact your LXE representative for further information about theV1.01 upgrade kit, if needed.

  • Page 68: External Power Supply (Optional)

    The MX3X DC power jack is located on the endcap. The Main Battery is trickle-charged using external power supplies. The cradle power jack is located on the back of the cradle.The MX3X (and the Desktop Cradle) connect to any of the following power supplies through the DC Power Jack.

  • Page 69: Important Battery Charger Version Information

    LXE does not supply an external timing device with the Multi-Charger Plus. Battery Label Location The MX3X battery pack has a silver label (as opposed to the white labels on LXE’s MX3 and MX3-CE battery packs). 125 Technology Parkway Norcross, GA 30092 USA Risk of fire, explosion, or burns.
  • Page 70 Important Battery Charger Version Information MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 71: Chapter 4 System Configuration

    Chapter 4 System Configuration Introduction There are several different aspects to the setup and configuration of the MX3X. Many of the setup and configuration settings are dependent upon the optional features such as hardware and software installed on the unit. The examples found in this chapter are to be used as examples only, the configuration of your specific MX3X computer may vary.

  • Page 72: Installed Software

    • Microsoft CE .NET version 4.2. Radio Drivers • Only one radio is installed in the MX3X at any one time. The 2.4GHz type of PC radio card resident on the MX3X determines the type of radio driver running on the MX3X.

  • Page 73: Desktop

    For general use instruction, please refer to commercially available CE .NET user's guides or the CE .NET on-line Help application installed with the MX3X. The MX3X Desktop appearance is similar to that of a desktop PC running Windows 95, 98, NT, 2000 or XP.

  • Page 74: My Computer Folders

    Storage Card ATA Card in Compact Flash Slot 1 Windows Operating System in ROM Program Files Applications Application Data Data saved by running applications My Documents Storage for downloaded files / applications Temp Location for temporary files MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 75: Start Menu Program Options

    Stop FTP Server Diagnostics Diagnostic tests for the MX3X Registry Editor Edit the MX3X registry ( c a r e f u l l y ) Test Utility Select a test to run e.g. Display, keyboard, audio. Microsoft File Viewers...

  • Page 76: Cisco - Aironet Client Utility (Acu)

    Access: Start | Aironet Client Utility or ACU Icon on Desktop Note: When making changes to profile parameters, the MX3X should be warmbooted afterwards. Profiles Tab Use this option to manage profiles and review firmware information, status, statistics and wireless radio survey data.

  • Page 77: Symbol

    Tap the Network Connected Icon in the Status Bar IP Information Tab After the IP Address has been assigned to the MX3X, tap the Renew button to renew the IP address if necessary. Tap the Details button to view the Network Connection details.

  • Page 78: Select A User Certificate

    3. In the IEEE 802.1X Authentication box, enable 802.1X authentication 4. Select an EAP type 5. Tap the Properties button. Validate Server is enabled by default. 6. At the Authentication Settings display, tap the Select button to choose a User Certificate. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 79: Communication

    If the MX3X is already in a docking cradle connected to a PC, remove and reinsert the MX3X into the cradle. If the MX3X is connected to a PC by RS-232/USB cable, disconnect the cable from the MX3X and reconnect.

  • Page 80: Connect

    Select "Make New Connection" and follow the instructions on the screen to create a connection while following the directions in the section titled "Backup MX3X Files" later in this chapter. See Also: “Important Information – Cold Boot and Loss of Host Re-connection”...

  • Page 81: Command Prompt

    Inbox as it relates to the general desktop Windows PC Microsoft Outlook Inbox options. Click the "?" button to access Inbox Help. ActiveSync can be used to transfer messages between the MX3X inbox and a desktop inbox. Internet Explorer...

  • Page 82: Remote Desktop Connection

    Experience tabs. Click the "?" button to access Remote Desktop Connection Help. Note: MX3X and Custom Key Maps: before connecting to a host using Remote Desktop Connection, go to Start | Settings | Control Panel | Keyboard and select 0409 from the keymap popup.

  • Page 83: Taskbar

    Tap the checkbox to have the Control Panel folders appear in drop down menu format from the Settings | Control Panel menu option. Clear Contents of Document Folder Tap the Clear button to remove the contents of the Document folder. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 84: Control Panel Options

    Owner Set MX3X owner details. Password Set MX3X access password properties. PC Connection Control the connection between the MX3X and a local desktop or laptop computer. PCMCIA Radio card in Slot 0, Internal ATA in Slot 2. Power Set Power Off, Backlight properties. Review battery status and perform backup battery charging/discharging.

  • Page 85: About

    Current network connection IP and MAC address. User application version information can be shown in the Version window. Version window information is taken from the registry. Modify the Registry using the Registry Editor (see section titled “MX3X Utilities”). LXE recommends caution when editing the Registry and also recommends making a backup copy of the registry before changes are made.

  • Page 86: Battery

    Start | Settings | Control Panel | Certificates Manage digital certificates used for secure communication. Lists the Stored certificates trusted by the MX3X user. These values may change based on the type of radio security resident in the client, access point or the host system.

  • Page 87: Date/Time

    Daylight Savings Disabled Note: Date and time is reset to the default value each time the MX3X is rebooted. Figure 4-4 Date/Time Properties There is no change from general desktop PC Date/Time Properties options. Adjust the settings and click the OK box or the Apply button to save the changes. The changes take effect immediately.

  • Page 88: Display

    Adjust the settings and click the OK box to save the changes. The changes take effect immediately. When the backlight timer expires, the monochrome screen is turned off, the color transmissive backlight is dimmed not turned off. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 89: Input Panel

    Play web sounds Enabled Enable web scripting Enabled Display script error note Disabled Underline links Never Select a tab. Adjust the settings and click the OK box to save the changes. The changes take effect immediately. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 90: Keyboard

    Adjust the volume, record gain, and sidetone for microphone input. Factory Default Settings Master Volume Record Gain 22.5dB Sidetone 12.0dB Input None Figure 4-7 Mixer Select the Input for the mixer. Move the sliders to adjust the decibel level. Tap OK to save the settings. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 91: Mouse

    Set the double-click sensitivity for stylus taps on the touch screen. Network and Dialup Connections Access: Start | Settings | Control Panel | Network and Dialup Connections Create a dialup, direct, or VPN connection on the MX3X. Owner Access: Start | Settings | Control Panel | Owner Icon Set MX3X owner details.

  • Page 92: Password

    Control Panel Options Password Access: Start | Settings | Control Panel | Password Icon Set MX3X access/power up password properties. Factory Default Settings Password Blank At Power On Disabled Note: Once a password is assigned, each Control Panel option requires the password be entered before the Control Panel option can be accessed.

  • Page 93: Pc Connection

    Allow connection with desktop computer when device is attached. Connect using: ‘USB Client’ Change ... Figure 4-10 Communication / PC Connection Tab Please refer to the "Backup MX3X Files" section later in this chapter for parameter setting recommendations. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 94: Pcmcia

    When “Power slot during sleep” is checked, the slot will stay powered up in Suspend at the cost of reduced battery life. When “Disable slot now” is checked, the slot is powered down as soon as the Control Panel is closed and the PCMCIA driver ignores any card in the slot. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 95: Power

    (removable). It also shows the status of the internal Backup Battery. The listed values cannot be changed by the user. Schemes Figure 4-11 Power Schemes Adjust the settings and click the OK box to save the changes. The changes take effect immediately. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 96: Battery Power Scheme

    Switch state to Suspend: Default is After 5 minutes AC Power Scheme Use this option when the MX3X will be running on external power (e.g. AC adapter, auto outlet adapter, powered cradle). Switch state to User Idle: Default is After 2 minute...

  • Page 97: Scanner

    Port 2 Port 1 Send Key Messages (WEDGE) Power Port 1 while asleep Figure 4-12 Scanner Properties / Main Tab Adjust the settings and click the OK box to save the changes. The changes take effect immediately. E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 98: Keys

    If “Send Key Messages …” is checked any data scan is converted to keystrokes and sent to the active window. When this box is not checked, the application will need to use the set of LXE Scanner APIs to retrieve the data from the scanner driver. Note that this latter method is significantly faster than using “Wedge”.

  • Page 99: Change A Virtual Key (F20 Or F21) Value

    Control Panel Options Change a Virtual Key (F20 or F21) Value Modify the Registry using the Registry Editor (see section titled “MX3X Utilities”). LXE recommends caution when editing the Registry and also recommends making a backup copy of the registry before changes are made.

  • Page 100: Storage Manager

    LXE recommends caution when formatting or dismounting storage devices and when creating new partitions or deleting partitions on the storage device. Note: Contact LXE Customer Support prior to using management functions on the internal ATA card. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 101: Stylus

    Double Tap Follow the instructions on the screen and click the OK box to save the changes. The changes take effect immediately. Calibration Figure 4-15 Stylus Properties / Recalibration Start Figure 4-16 Stylus Properties / Recalibration E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 102: System

    64 MB may only report 35 MB memory, since 29 MB is used up by the Windows CE .NET operating system. This is actual DRAM memory, and does not include internal flash or the internal ATA card used for storage. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 103: Memory

    Move the slider to allocate more memory for programs or storage. If there isn’t enough space for a file, increase the amount of storage memory. If the MX3X is running slowly, try increasing the amount of program memory. Adjust the settings and click the OK box to save the changes. The changes take effect immediately.

  • Page 104: Volume And Sounds

    SCANBAD.WAV. These are unprotected WAV files and can be replaced by a WAV file of the user’s choice. By default a good scan sound on the MX3X is a single 2700 Hz beep, and a bad scan sound is a double beep.

  • Page 105: Backup Mx3X Files Using Activesync

    – Initial Setup” in Chapter 1 “Introduction”, “Getting Started”. Serial Port Transfer • A desktop or laptop PC with an available serial port and an MX3X with a serial port. The desktop or laptop PC must be running Windows 95, 98, NT or 2000.

  • Page 106: Disconnect

    An ActiveSync partnership between a unique client can be established to two hosts. If the MX3X is cold booted, the random number is deleted – and the partnership with the last one of the two hosts is also deleted. The host retains the random numbers and unique names of all devices having a partnership with it.

  • Page 107: Troubleshooting

    Backup MX3X Files using ActiveSync Troubleshooting ActiveSync on the host says that a device is trying to connect, but it cannot identify it One or more control lines are not connected. This is usually a cable problem, but on a laptop or other device, it may indicate a bad serial port.

  • Page 108: Create A Communication Option

    Backup MX3X Files using ActiveSync Create a Communication Option 1. On the MX3X, select Start | Settings | Control Panel | Network and Dialup Connections. A window is displayed showing the existing connections. 2. Assuming the one you want does not exist, double-click Make New Connection.

  • Page 109: Technical Specifications - Connection Cable

    Backup MX3X Files using ActiveSync Technical Specifications – Connection Cable The exact serial cable is crucial. Many commercial null modem cables will not work. LXE recommends the following cable: Serial cable: 9000A054CBL6D9D9 Pinout: DB9 female DB9 female 6, 8 6, 8 no connection Figure 4-21 Pinout –...

  • Page 110: Mx3X Utilities

    Then, information is added to the registry, if desired, to make the CAB file auto- launch at startup. The registry information needed is under the key HKEY_LOCAL_MACHINE \ Software \ LXE \ Persist, as follows. The main subkey is any text, and is a description of the file. Then 3 values are added: FileName is the name of the CAB file, with the path (usually \System).

  • Page 111: Pregedit.exe

    [HKEY_LOCAL_MACHINE\SOFTWARE\LXE\Persist\Symbol Radio] "FileName"="\System\SYMBOL.CAB" "Installed"=dword:0 "FileCheck"="\WINDOWS\NICTT.EXE" PREGEDIT.EXE Pocket Registry Editor - part of Microsoft Power Tools for Windows CE. LXE recommends caution when editing the Registry and also recommends making a backup copy of the registry before changes are made. REGLOAD.EXE Double-tapping a registry settings file (e.g.

  • Page 112: Api Calls

    CD, which are the C/C++ include files and the link library for the DLL, respectively. Note that this DLL is installed in MX3X images with a version number of 1.2 or higher (as displayed on the screen during bootup).

  • Page 113: Reflash The Mx3X

    Requirement: A screwdriver (not supplied by LXE) Preparation • LXE recommends that installation of the CF card be performed on a clean, well-lit surface. • Remove the screws on the endcap and slide the endcap to the side, being very careful not to disconnect the ribbon cables, damage the leads to the external power jack, the headphone jack or the antenna.
  • Page 114 Clearing Persistent Storage MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 115: Appendixa Key Maps

    Appendix A Key Maps Keypad Note: The key mapping in this appendix relates to the physical keypad on the MX3X. See section titled “Input Panel” for the Virtual (or Soft) Keypad used with the stylus. Key Map 101-Key Equivalencies Note: This key mapping is used on hand held computers that are NOT running an LXE Terminal Emulator.
  • Page 116 BackTab Break Pause Up Arrow Up Arrow Down Arrow Down Arrow Right Arrow Right Arrow Left Arrow Left Arrow Insert BkSp Delete Home Left Arrow Right Arrow Page Up Up Arrow Page Down Down Arrow ScrollLock MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 117 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 118 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock < > : (colon) ; (semicolon) _ (underscore) MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 119 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock , (comma) ‘ (apostrophe) ~ (tilde) “ & E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 120: Creating Custom Key Maps For The Mx3X

    System Administrator can convert a sample default key map text file into a custom key map text file which, when loaded onto the MX3X, can be chosen by the user to replace the default MX3X keymap and then switched back when they are finished using the customized keys.

  • Page 121: Programmable Scan Buttons And Custom Key Mapping

    However, if the scanner control panel is used to change the Scan button to generate an ENTER, the original ENTER key is maintained as well. Note: Tethered scanners are not activated/affected by the Scan buttons on the MX3X. Keymap Source Format The source file DEFAULT.KEY is supplied with the keymap compiler. This is the commented source for the default keymap 0409.

  • Page 122: General Section

    4 specific modifier keys, in COLxROWx format. Note the row and column for these keys can be outside the keymap limits specified in the GENERAL section, since these are not loaded as part of the keymap proper. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 123: Map Section

    When these maps are selected, the keyboard driver handles the up arrow and down arrow as adjusting the particular parameter up and down, and any other key exits the adjustment state. Keys in these modes are handled completely inside the keyboard driver, and are not propagated to the operating system. E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 124 OPEN an unused key position, does nothing when pressed Valid ACTION codes are as follows: SCAN1 Scan key 1 (left side of display on MX3X) SCAN2 Scan key 2 (right side of display on MX3X) SCAN3 Handle trigger button (unused on MX3X, but specified)

  • Page 125: Keycomp Error Messages

    The specified MAPROWS exceeds the limits of the KEYCOMP compiler. Invalid ROWCOL format A COLxROWx was expected, but the format was not correct. The only valid formats are: COLxROWx, COLxxROWx, COLxROWxx, or COLxxROWxx, where xx are decimal numeric digits (0-9). E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 126 The MAP section must contain a MAP value, so the data fields can be parsed. MAPNAME must be all numerics Because of limitations in Microsoft Layout Manager, the map name must be all numeric (4, 5, or 6 digits). The name parsed did not fit this limitation. MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 127 No definition for MapHead.keyscan1 No Scan Key 1 definition was found. The keyboard driver requires this key to be defined somewhere in one of the keymaps. This message comes from the post-parse validation, so no line # is specified. E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 128 The ALGOR algorithm specified is not one that KEYCOMP understands. Value outside of section A value (defined as value=data) is only valid within a section (defined as [section]). A value line was found when a section header line was expected. MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 129: Sample Input File

    Appendix A Key Maps Sample Input File ;;---------------------------------------------------- ;; keymap file for MX3X default keyboard ;;---------------------------------------------------- ;;---------------------------------------------------- ;; general parms give the size of arrays ;; all numeric values are decimal ;; these numbers are validated with the data below ;;...
  • Page 130 COL4ROW0=VK_F9 COL4ROW1='S' COL4ROW2=VK_RIGHT COL4ROW3='F' COL4ROW4='H' COL4ROW5='K' COL4ROW6='2' COL4ROW7=VK_UP ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL5ROW0='6' COL5ROW1='Z' COL5ROW2=VK_BACK COL5ROW3='C' COL5ROW4='B' COL5ROW5='M' COL5ROW6=VK_PERIOD COL5ROW7=VK_DOWN ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL6ROW0=VK_F10 COL6ROW1='W' COL6ROW2=VK_RETURN COL6ROW3='R' COL6ROW4='Y' COL6ROW5='I' COL6ROW6='5' COL6ROW7='P' ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL7ROW0='E' COL7ROW1=open COL7ROW2=VK_F3 COL7ROW3=VK_F4 COL7ROW4=VK_F6 COL7ROW5='7' COL7ROW6=VK_F8 COL7ROW7=open ;;;;;;;;;;;;;;;;;;;;;;;;;;; MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 131 COL1ROW5=VK_EQUAL COL1ROW6=SHIFT+'9' COL1ROW7=ACTION+SCAN2 ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL2ROW0=SHIFT+VK_BACKSLASH COL2ROW1=open COL2ROW2=SHIFT+VK_SEMICOLON COL2ROW3=SHIFT+VK_APOSTROPHE COL2ROW4=VK_COMMA COL2ROW5=VK_LBRACKET COL2ROW6=SHIFT+VK_SLASH COL2ROW7=SHIFT+VK_PERIOD ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL3ROW0=open COL3ROW1=open COL3ROW2=open COL3ROW3=open COL3ROW4=VK_BACKQUOTE COL3ROW5=SHIFT+VK_COMMA COL3ROW6=VK_HOME COL3ROW7=SHIFT+VK_TAB ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL4ROW0=open COL4ROW1=VK_BACKSLASH COL4ROW2=VK_END COL4ROW3=VK_SEMICOLON COL4ROW4=VK_APOSTROPHE COL4ROW5=VK_PERIOD COL4ROW6=VK_RBRACKET COL4ROW7=VK_PRIOR ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL5ROW0=SHIFT+VK_RBRACKET COL5ROW1=open COL5ROW2=VK_INSERT COL5ROW3=open COL5ROW4=SHIFT+VK_BACKQUOTE E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 132 ;; this is the map for keys with 2ND and SHIFT ;;---------------------------------------------------- [Map] MAP=MAP_2NDSHIFT ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL0ROW0=open COL0ROW1=VK_F11 COL0ROW2=ACTION+POWER COL0ROW3=VK_F12 COL0ROW4=open COL0ROW5=open COL0ROW6='8' COL0ROW7=ACTION+SCAN1 ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL1ROW0=open COL1ROW1='9' COL1ROW2=ACTION+SCAN3 COL1ROW3=open COL1ROW4=open COL1ROW5='4' COL1ROW6=open COL1ROW7=ACTION+SCAN2 ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL2ROW0=open COL2ROW1=open COL2ROW2=open COL2ROW3=open COL2ROW4=open COL2ROW5='1' COL2ROW6=open COL2ROW7='3' ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL3ROW0=open COL3ROW1=open MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 133 COL4ROW0=open COL4ROW1=open COL4ROW2=open COL4ROW3=open COL4ROW4=open COL4ROW5=open COL4ROW6='2' COL4ROW7=open ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL5ROW0='6' COL5ROW1=open COL5ROW2=open COL5ROW3=open COL5ROW4=open COL5ROW5=open COL5ROW6=open COL5ROW7=open ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL6ROW0=open COL6ROW1=open COL6ROW2=open COL6ROW3=open COL6ROW4=open COL6ROW5=open COL6ROW6='5' COL6ROW7=open ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL7ROW0=open COL7ROW1=open COL7ROW2=VK_PAUSE COL7ROW3=VK_SCROLL COL7ROW4=VK_SNAPSHOT COL7ROW5='7' COL7ROW6=open COL7ROW7=open ;;;;;;;;;;;;;;;;;;;;;;;;;;; E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 134 COL1ROW6=SHIFT+'O' COL1ROW7=ACTION+SCAN2 ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL2ROW0=SHIFT+'A' COL2ROW1=open COL2ROW2=SHIFT+'D' COL2ROW3=SHIFT+'G' COL2ROW4=SHIFT+'J' COL2ROW5=SHIFT+'1' COL2ROW6=SHIFT+'L' COL2ROW7=SHIFT+'3' ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL3ROW0=SHIFT+' ' COL3ROW1=open COL3ROW2=SHIFT+'X' COL3ROW3=SHIFT+'V' COL3ROW4=SHIFT+'N' COL3ROW5=SHIFT+'0' COL3ROW6=SHIFT+VK_LEFT COL3ROW7=SHIFT+VK_TAB ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL4ROW0=SHIFT+VK_F9 COL4ROW1=SHIFT+'S' COL4ROW2=SHIFT+VK_RIGHT COL4ROW3=SHIFT+'F' COL4ROW4=SHIFT+'H' COL4ROW5=SHIFT+'K' COL4ROW6=SHIFT+'2' COL4ROW7=SHIFT+VK_UP ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL5ROW0=SHIFT+'6' COL5ROW1=SHIFT+'Z' COL5ROW2=SHIFT+VK_BACK COL5ROW3=SHIFT+'C' COL5ROW4=SHIFT+'B' MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 135 Appendix A Key Maps COL5ROW5=SHIFT+'M' COL5ROW6=SHIFT+VK_PERIOD COL5ROW7=SHIFT+VK_DOWN ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL6ROW0=SHIFT+VK_F10 COL6ROW1=SHIFT+'W' COL6ROW2=SHIFT+VK_RETURN COL6ROW3=SHIFT+'R' COL6ROW4=SHIFT+'Y' COL6ROW5=SHIFT+'I' COL6ROW6=SHIFT+'5' COL6ROW7=SHIFT+'P' ;;;;;;;;;;;;;;;;;;;;;;;;;;; COL7ROW0=SHIFT+'E' COL7ROW1=open COL7ROW2=SHIFT+VK_F3 COL7ROW3=SHIFT+VK_F4 COL7ROW4=SHIFT+VK_F6 COL7ROW5=SHIFT+'7' COL7ROW6=SHIFT+VK_F8 COL7ROW7=open E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 136: Sample Output File

    00,14,DF,13,00,00,BD,87,31,BB,89,35,37,BB,39,88,\ DC,00,BA,DE,BC,DB,BF,BE,00,00,00,00,C0,BC,24,09,\ 00,DC,23,BA,DE,BE,DD,21,DD,00,2D,00,C0,BD,2E,22,\ 8A,32,00,34,36,38,DB,30,33,00,00,00,00,BF,00,00 ;; Flag1 is the shift codes for the 2ND key map "Flag1"=hex:\ 00,00,A0,10,00,86,00,A0,10,10,A0,10,10,00,10,A0,\ 10,00,10,10,00,00,10,10,00,00,00,00,00,10,00,10,\ 00,00,00,00,00,00,00,00,10,00,00,00,10,10,00,00,\ A0,10,00,10,10,10,10,10,10,00,00,00,85,00,84,00 ;; Map2 is the scancode values for the 2ND-SHIFT key map "Map2"=hex:\ 00,7A,DF,7B,00,00,38,87,00,39,89,00,00,34,00,88,\ 00,00,00,00,00,31,00,33,00,00,00,00,00,30,00,00,\ 00,00,00,00,00,00,32,00,36,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,35,00,00,00,13,91,2C,37,00,00 MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 137 00,00,A0,00,00,00,00,A0,00,00,A0,00,00,00,00,A0,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00 ;; Map3 is the scancode values for the SHIFT key map "Map3"=hex:\ 1B,70,DF,71,74,76,38,87,51,39,89,54,55,34,4F,88,\ 41,00,44,47,4A,31,4C,33,20,00,58,56,4E,30,25,09,\ 78,53,27,46,48,4B,32,26,36,5A,08,43,42,4D,BE,28,\ 79,57,0D,52,59,49,35,50,45,00,72,73,75,37,77,00 ;; Flag3 is the shift codes for the SHIFT key map "Flag3"=hex:\ 10,10,A0,10,10,10,10,A0,10,10,A0,10,10,10,10,A0,\ 10,00,10,10,10,10,10,10,10,00,10,10,10,10,10,10,\ 10,10,10,10,10,10,10,10,10,10,10,10,10,10,10,10,\ 10,10,10,10,10,10,10,10,10,00,10,10,10,10,10,00 E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 138: List Of Valid Vk Codes For Ce .Net

    VK_DECIMAL VK_RMENU VK_EXSEL VK_NEXT VK_DIVIDE VK_SEMICOLON VK_EREOF VK_END VK_F1 VK_EQUAL VK_PLAY VK_HOME VK_F2 VK_COMMA VK_ZOOM VK_LEFT VK_F3 VK_HYPHEN VK_NONAME VK_UP VK_F4 VK_PERIOD VK_PA1 VK_RIGHT VK_F5 VK_SLASH VK_OEM_CLEAR VK_DOWN VK_F6 VK_BACKQUOTE VK_SELECT VK_F7 VK_BROWSER_BACK VK_PRINT VK_F8 VK_BROWSER_FORWARD MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 139: Appendixb Technical Specifications

    Endcap - incl Scanner (COM 3), 9 Pin “D” (male) Connector. Provides DA-9 or DB-9 Connector (COM connection to external devices such as a printer. Endcap – incl Scanner (COM 3), Scanner – SE923 Symbol engine DA-9 (COM 1) E-EQ-MX3XRG-A MX3X Reference Guide...

  • Page 140: Display Specifications

    LCD - Transflective Monochrome, Transmissive Color Electroluminescent Backlighting Resolution 640x240 pixels Size ½ VGA landscape Diagonal Viewing Area 5.92 in (150.4mm) Dot Pitch 0.22mm Dot Size 0.20mm x 0.20mm Color Scale Monochrome - 16 Shades of Gray Transmissive – 256 colors MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 141: Environmental Specifications

    Appendix B Technical Specifications Environmental Specifications MX3X and Endcaps Operating Temperature -4°F to 122°F (-20°C to 50°C) monochrome 32°F to 122°F (0°C to 50°C) color Storage Temperature -22°F to 158°F (-30°C to 70°C) Water and Dust IEC IP66 Operating Humidity Up to 90% non-condensing at 104°F (40°C)

  • Page 142: International Ac Adapter

    47 - 63 Hz Input Connector Customer supplied Output Connector Barrel connector, female, 5.5 x 2.5 x 11mm, Center Positive Output Voltage +12VDC, regulated Output Voltage Regulation +/- 5% Output Current 0 Amps min, 1.00 Amps max MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 143: Radio Specifications

    RF Data Rates 11 Mbps RF Power Level 100 mW max. Channels 11 US, 13 Europe, 4 France, 14 Japan Operating Temperature see MX3X Environmental Specs Storage Temperature see MX3X Environmental Specs Connectivity Novell, TCP/IP, Ethernet, ODI Antenna Internal PCMCIA Symbol 11Mb 2.4GHz Type II Bus Interface: PCMCIA 2.0, Type II slot...
  • Page 144 Appendix B Technical Specifications MX3X Reference Guide E-EQ-MX3XRG-A...

  • Page 145: Index

    COM port settings tab ........89 Maintenance............56 COM Port Switching .......... 31 Replacement............56 COM Ports............87 Time Limit ............55 Configurations ..........31 Backup Data Files..........95 Command Prompt..........71 Barcode Scanner Communications..........70 E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 146 Display brightness and contrast ......16 Enter Key ............44 Display Contrast ..........16 Field Exit Key........... 45 Display Timer ............. 48 Scan Key............44 ..........4 Document Conventions Shft Key ............45 Spc Key............. 45 MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 147 ON Mode characteristics ........34 Keys tab .............. 88 Operating Temperature........131 US AC to DC ..........131 WW AC to DC..........132 LAUNCH.EXE..........100 Owner LEDs Identification............. 81 2nd function ............47 Notes ..............81 ALT function ............ 47 E-EQ-MX3XRG-A MX3X Reference Guide...
  • Page 148 Rate..............80 SRAM or Flash PCMCIA....... 129 Recalibrate ............12 Weights ............129 Recalibration............91 Specs Reflash .............. 103 AC Adapter..........131, 132 Regional Setting ..........86 Environmental..........131 REGLOAD.EXE ..........101 LCD Panel ............130 MX3X Reference Guide E-EQ-MX3XRG-A...
  • Page 149 Stylus sensitivity..........91 Display.............. 48 Suspend button ........... 63 Virtual Key, change..........89 Suspend Timer............ 17 Virtual Keyboard ..........79 Synchronize desktop computer with the MX3X VK_Code List........... 128 ActiveSync............69 Volume System Configuration ......... 61 adjust audio volume .......... 18 System Hardware Configuration ......
  • Page 150 Index MX3X Reference Guide E-EQ-MX3XRG-A...

Table of Contents
