MX5 User's Guide
(For Microsoft Windows Pocket PC Equipped MX5's)
IMPORTANT NOTICE
LXE's MX5 running Pocket PC 2000/2002 is obsolete.
This electronic LXEbook has been made available as a courtesy to LXE's
customers. Please contact your LXE customer support representative for
assistance and mobile device replacement.
Copyright © 2005 by LXE Inc.
All Rights Reserved
E-EB-MX5UG-F-ARC
Notices
Warning: Standard MX5 units are not approved for Hazardous Location use. The
unit described in this user guide is a "standard" MX5 unit.
LXE Inc. reserves the right to make improvements or changes in the products
described in this manual at any time without notice. While reasonable efforts
have been made in the preparation of this document to assure its accuracy, LXE
assumes no liability resulting from any errors or omissions in this document, or
from the use of the information contained herein. Further, LXE Incorporated,
reserves the right to revise this publication and to make changes to it from time
to time without any obligation to notify any person or organization of such
revision or changes.
Copyright:
This manual is copyrighted. All rights are reserved. This document may not, in whole or in
part, be copied, photocopied, reproduced, translated or reduced to any electronic medium
or machine-readable form without prior consent, in writing, from LXE Inc.
