DEMO MANUAL DC2468A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C2, C12
2 1 C6
3 1 C8
4 1 C9
5 1 C16
6 1 C17
7 1 C20
8 1 L1
9 2 R1, R5
10 1 R2
11 1 R3
12 1 R7
13 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 2 C3, C10
3 1 C4
4 1 C14
5 0 C18 (OPT)
6 0 C19 (OPT)
7 1 FB1
8 0 R6 (OPT)
9 1 R8
Hardware: For Demo Board Only
1 8 E1, E5-E9, E11, E14
2 4 E2, E10, E12, E13
3 1 JP1
4 1 XJP1
5 4 J1-J4
6 4 MH1-MH4
6
PART DESCRIPTION
CAP ., X7R, 0.47μF, 100V, 10%, 0805
CAP ., X5R, 100μF, 10V, 20%, 1210
CAP ., X7R, 0.1μF, 25V, 10%, 0603
CAP ., X5R, 10μF, 25V, 20%, 0603
CAP ., C0G, 4.7pF, 50V, ±0.25pF, 0603
CAP ., X7S, 4.7μF, 100V, 10%, 1210
CAP ., X7R, 1μF, 16V, 10%, 0603
INDUCTOR, 1.0μH, XEL6030
RES., CHIP , 100k, 1/10W, 1%, 0603
RES., CHIP , 17.8k, 1/10W, 1%, 0603
RES., CHIP , 243k, 1/10W, 1%, 0603
RES., CHIP , 1M, 1/10W, 1%, 0603
I.C., STEP-DOWN SWITCHER, 6mmX4mm LQFN
CAP ., ALUM 22μF, 100V, 10%
CAP ., X7R, 2.2μF, 100V, 10%, 1210
CAP ., X7R, 0.1μF, 100V, 10%, 0603
CAP ., X5R, 0.1μF, 100V, 10%, 0402
CAP ., 0603
CAP ., 1210
FERRITE BEAD 100Ω 8A SMD 1812
RES., OPTION, 0603
RES., CHIP , 0Ω, 1/10W, 1%, 0603
TESTPOINT, TURRET, 0.094"
TESTPOINT, TURRET, 0.061"
2X4, 0.079" DOUBLE ROW HEADER
SHUNT, 0.079" CENTER
JACK BANANA
STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM21BR72A474KA73L
MURATA, GRM32ER61A107ME20L
MURATA, GRM188R71E104KA01D
MURATA, GRM188R61E106MA73D
MURATA, GRM1885C1H4R7CA01D
MURATA, GRJ32DC72A475KE11L
MURATA, GRM188R71C105KA12D
COILCRAFT, XEL6030-102MEC
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060317K8FKEA
VISHAY, CRCW0603243KFKEA
VISHAY, CRCW06031M00FKEA
LINEAR TECH., LT8645SEV#PBF
SUNCON, 100CE22BS
MURATA, GRM32ER72A225KA35L
MURATA, GRM188R72A104KA35D
MURATA, GRM155R62A104KE14D
WURTH ELEKTRONIK, 74279226101
VISHAY, CRCW06030000Z0EA
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000821121
WURTH ELEKTRONIK, 60800213421
KEYSTONE, 575-4
WURTH ELEKTRONIK, 702935000
