NetWaySP4 Series Installation Guide

Typical VLan Setup:

Example

vLan ID 20

for ports 3-4

Pass thru

Fiber to

Next NetWaySP4

Example

vLan ID 10

for ports 1-2

Trunk

(i.e. VLan ID 10 and 20)

Fiber from

Host Switch

- 9 -
