6.13

Volume Mode (Address 16h)

7 6
MUTE DELAY[1:0]
6.13.1 Mute Delay
Sets the delay between the volume steps during muting and unmuting of a signal when attenuation mode
is set to soft ramp. Each step of the ramp is equal to
times the base period.
MUTE DELAY
00
01
10
11
6.13.2 Minimum Delay
Sets the minimum delay before each volume transition. Settings are given in "x" times the base period.
See Section 4.6.5 Volume Control
MIN DELAY
000
001
010
011
100
101
110
111
6.13.3 Maximum Delay
Sets the maximum delay before the volume transition. Settings are given in "x" times the base period. See
Section 4.6.5 Volume Control
MAX DELAY
000
001
010
011
100
101
110
111
DS900F2
5 4
MIN DELAY[2:0]
Delay is:
1x
4x
16x
64x
for more details regarding the operation of the volume control.
Minimum Delay is:
1x
2x
4x
8x
16x
32x
64x
128x
for more details regarding the operation of the volume control.
Maximum Delay is:
1x
2x
4x
8x
16x
32x
64x
128x
3 2
MAX DELAY[2:0]
6.02
/ dB ~= 0.094 dB. Settings are given as "x"
64
CS4244
1 0
