1-3. Specifications
For a detailed list of printer specifications refer to the User's Reference Manual, P/N 108534-001.
1-4. Operation
a. Operating Procedures
For detailed operating procedures, refer to Operator's Guide, P/N 108525-001.
b. Controls and Indicators
a.
External Controls and Indicators. External controls and indicators are illustrated in
Figure 1-2 and described in Table 1-1.
b.
Internal Controls and Indicators. Internal controls and indicators are illustrated in
Figure 1-3 and described in Table 1-2.
KEY
CONTROL OR
(FIG 1-2)
INDICATOR
1
ON/POWER/OFF
1
2
POWER
3
ON LINE
4
TOP OF FORM
5
Display
6
SET
TOF
7
PRINT MODE
8
CONFIG
VALUE
9
CLEAR
FAULT
10
RUN/STOP
TEST
1-4
Table 1-1. External Controls and Indicators
Sets AC power on or off.
0
Indicates power is applied to printer.
Places printer online or offline.
Advances paper one form length to top of next
form.
Displays printer status and error messages.
Establishes TOF (top of form) position.
Selects and displays current print mode.
Selects and displays individual parameters with-
in configuration menu.
When configuration values are displayed, this
switch selects and displays the next config-
uration menu. When fault message is dis-
played, resets printer after fault is corrected.
Executes one of three basic functions:
1. Saves newly selected parameters or loads
default parameters.
2. Runs or stops configuration and self-tests.
3. Runs or stops hex dump.
FUNCTION
P6040/P6080 Maintenance Overview
