DEMO MANUAL
DC2331A-A/DC2331A-B

PARTS LIST

ITEM QTY REFERENCE
DC2331A-A Required Circuit Components
1 5 CIN1, CIN2, CIN3, CIN4, CIN5
2 10 CIN6, CIN7, CIN8, CIN9, CIN10, CIN11, CIN12,
CIN13 CIN14, CIN15
3 3 CIN17, CIN18, CIN19
4 5 COUT1, COUT2, COUT3, COUT4, COUT5
5 10 COUT6, COUT7, COUT8, COUT9, COUT10,
COUT11, COUT12, COUT13, COUT14, COUT15
6 1 C1
7 3 C2, C25, C33
8 1 C3
9 10 C4, C5, C8, C9, C10, C11,
C12, C13, C15, C35
10 1 C6
11 4 C14, C27, C36, C57
12 5 C17, C18, C19, C20, C21
13 1 C22
14 1 C23
15 1 C24
16 1 C26
17 1 C28
18 1 C29
19 1 C30
20 1 C31
21 1 C32
22 2 C34, C62
23 1 C60
24 7 D1, D2, D3, D4, D5, D6, D7
25 1 D8
26 5 L1, L2, L3, L4, L5
27 1 L6
28 20 Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8, Q9, Q10,
Q11, Q12, Q13, Q14, Q15, Q16, Q17, Q18,
Q19, Q20
29 1 Q21
30 5 RSNS1, RSNS2, RSNS3, RSNS4, RSNS5
12
PART DESCRIPTION
CAP ., X7S, 4.7µF, 100V, 10%, 1210
CAP ., X7R, 15µF, 100V, 10%, 2220
(J-LEAD)
CAP ., ALUM., POLYMER, 47µF, 63V,
20%
CAP ., X7R, 22µF, 16V, 20%, 1210
CAP ., ALUM., 150µF, 16V, 20%
CAP ., X7R, 2.2µF, 100V, 20%, 1206
CAP ., X5R, 2.2µF, 16V, 10%, 0603
CAP ., X5R, 10µF, 16V, 10%, 0603
CAP ., X7R, 1000pF, 25V, 10%, 0603
CAP ., X7R, 100pF, 16V, 10%, 0603
CAP ., X7R, 0.01µF, 16V, 10%, 0603
CAP ., X7R, 0.22µF, 16V, 10%, 0603
CAP ., NP0, 47pF, 50V, 5%, 0603
CAP ., X7R, 1µF, 100V, 10%, 1206
CAP ., X7R, 1µF, 16V, 10%, 0603
CAP ., NP0, 10pF, 50V, 5%, 0603
CAP ., X7R, 2.2µF, 100V, 10%, 1210
CAP ., X5R, 22µF, 16V, 20%, 0805
CAP ., X7R, 0.033µF, 16V, 10%, 0603
CAP ., X7R, 4700pF, 16V, 10%, 0603
CAP ., X5R, 47µF, 16V, 10%, 1210
CAP ., X7R, 0.1µF, 16V, 10%, 0603
CAP ., NP0, 22pF, 50V, 5%, 0603
DIODE, SCHOTTKY, 100V, SOD323
DIODE, 80V, SOD523
IND., 6.8µH
IND., 47µH
XSTR., MOSFET, 60V, PG-TDSON-8
MOSFET, P-CH 100V 2.6A SOT223
RES., SENSE, 0.0025Ω, 3W, 1%,
2512
MANUFACTURER/PART NUMBER
MURATA, GRJ32DC72A475KE11L
MURATA, KRM55WR72A156MH01K
SUN ELEC., 63HVH47M
MURATA, GRM32ER71C226MEA8L
PANASONIC, 16SVP150M
MURATA, GRM31CR72A225MA73L
MURATA, GRM188R61C225KE15D
MURATA, GRM188R61C106KAALD
MURATA, GRM188R71E102KA01D
AVX, 0603YC101KAT2A
MURATA, GRM188R71C103KA01D
MURATA, GRM188R71C224KA01D
MURATA, GRM1885C1H470JA01D
MURATA, GRM31CR72A105KA01L
MURATA, GRM188R71C105KA12D
MURATA, GRM1885C1H100JA01D
MURATA, GRM32ER72A225KA35L
MURATA, GRM21BR61C226ME44L
MURATA, GRM188R71C333KA01D
MURATA, GRM188R71C472KA01D
MURATA, GRM32ER61C476KE15K
MURATA, GRM188R71C104KA01D
MURATA, GRM1885C1H220JA01D
NXP , BAT46WJ,115
DIODES INC.,1N4448HWT-7
COILCRAFT, SER2915L-682KL
Wurth Elektronik, 744771147
INFINEON, BSC100N06LS3
DIODES INC., ZXMP10A18G
NIC, NCSR300F2M50DTRGF
IRC/TT Electronics, ULRG32512R0025FLFSLT
Panasonic, ERJMP4PF2M5U
Rev. 0
