PARTS LIST

ITEM QTY REFERENCE
1 1 PCB
2 1 CC1
3 1 CC2
4 4 C , C , C
FF1 FF2
C
HF4
5 1 C
IN1
6 2 C , C
OPT1 OPT2
7 2 C , C
OUT1 OUT2
8 2 C , C
OUT1B OUT2B
9 2 C , C
VREF VREG
10 2 D1, D2
11 1 D3
12 1 INPUT
13 1 L1
14 1 L2
15 2 OUTPUT1,
OUTPUT2
16 2 P1, P2
17 1 R1
18 11 R4, R6, R7, R8,
R10, R11, R12,
R13, R14, R17,
R18
19 5 R3, R5, R9, R15,
R16
20 1 R2
21 1 R
C1
22 1 R
C2
23 1 R
FB1
24 1 R
FB2
25 2 R , R
FF1 FF2
26 1 R
FT1
27 1 R
FT2
28 1 SYNC
29 1 U1
30 2 VIOC1, VIOC2
Note 1. These items are not stuffed (DNI).
DEMO MANUAL SCP-ADP5070-EVALZ
PART DESCRIPTION
PCB
CAP CER 47nF 16V X7R 0603
CAP CER 68nF 16V X7R 0603
, RES TBD 0402 (Note 1)
HF3
CAP 10uF 25V CER X7R 1206
CAP TBD CER 0603 (Note 1)
CAP CER 10UF 50V X5R 1206
CAP TBD CER 1206 (Note 1)
CAP 1uF 10V CER X7R 0603
DIODE SCHOTTKY BARRIER RECTIFIER
DIODE ZENER, 6.0V, 500mW
CONN MALE 3POS 2.54MM PITCH R/A
6.8uH 3.9A 74.1mOHM INDUCTOR
15uH 2.8A 120mOHM INDUCTOR
CONN FEMALE 3POS 2.54MM PITCH R/A
CONN-PCB 3POS HEADER WIRE TO BRD ASSY STRAIGHT 2MM
PITCH (Note 1)
RES 14.3k 1% THICK FILM 0805
RES THICK FILM 0805 (Note 1)
RES 0.0 5% STANDARD THICK FILM CHIP
RES 11.0k 1% THICK FILM 0805
RES 12.0k 1% THICK FILM 0603
RES 10.0k 1% THICK FILM 0603
RES 137k 1% THICK FILM 0805
RES 118k 1% THICK FILM 0805
RES TBD THICK FILM 0402 (Note 1)
RES 2.43M 1% THICK FILM 0805
RES 2.32M 1% THICK FILM 0805
CONN-PCB STRAIGHT SMA PCB DIE CAST (Note 1)
IC-ADI 1A/0.6A, DC TO DC SWITCHING REGULATOR WITH
INDEPENDENT POSITIVE AND NEGATIVE OUTPUTS
CONN FEMALE 2POS 2.54MM PITCH R/A
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_051364b
YAGEO CC0603KRX7R7BB473
AVX 0603YC683KAZ2A
N/A
TAIYO YUDEN TMK316B7106KL-TD
TBD
SAMSUNG CL31A106MBHNNNE
TBD
SAMSUNG CL10B105KP8NNNC
DIODES INC DFLS240-7
DIODES INC MMSZ5233B-7-F
SULLINS PBC03SBAN
COILCRAFT XAL4030-682MEC
COILCRAFT XAL4040-153MEB
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
PANASONIC ERJ-6ENF1432V
N/A
VISHAY CRCW08050000Z0EA
PANASONIC ERJ-6ENF1102V
PANASONIC ERJ-3EKF1202V
PANASONIC ERJ-3EKF1002V
PANASONIC ERJ-6ENF1373V
PANASONIC ERJ-6ENF1183V
TBD
YAGEO RC0805FR-072M43L
YAGEO RC0805FR-072M32L
TE CONNECTIVITY 5-1814832-1
ANALOG DEVICES ADP5070AREZ
SULLINS PPPC021LGBN-RC
