PARTS LIST

ITEM QTY REFERENCE
5 0 R2, R3, R5, R6, R11, R12, R15,
R21, R22, R43, R44, R45, R46,
R47, R48, R49, R51, R52, R53,
R54, R56, R58, R59, R61, R62,
R64, R65, R67, R69, R92, R93,
R95, R97, R99, R100, R105,
R106, R107, R108, R109
6 0 R60, R63, R66, R68, R75
7 2 R70, R71
8 2 C45, C46
9 4 R72, R74, R85, R114
10 1 R73
11 1 U2
12 1 R79
13 2 R80, R83
14 1 R77
15 4 R78, R94, R96, R98
16 1 R82
17 1 R84
18 1 U3
19 1 U4
20 2 C49, C53
21 1 R86
22 1 R90
23 1 R91
24 1 R81
25 1 R87
26 1 C50
27 1 R76
28 1 R88
29 1 Q1
30 4 COUT21, COUT25, C51, C52
31 6 COUT19, COUT20, COUT23,
COUT24, C47, C48
32 4 COUT17, COUT18, COUT22,
33 1 U5
34 2 R103, R104
35 3 R110, R111, R115
36 2 R112, R113
37 1 R116
38 1 D2
39 2 D5, D6
DEMO MANUAL DC2672A-A
PART DESCRIPTION
RES, 0603 OPTION
RES, 2010 OPTION
RES, 1206 100 OHMS 1% 1/4W
CAP , 1210 10uF 10% 16V X7R
RES, 0603 10K OHMS 5% 1/10W
RES, 0603 34.8K OHM 1% 1/10W
IC, REGULATOR
RES, 0603 154K OHMS 1% 1/10W
RES, 0603 20K OHMS 5% 1/10W
RES, 2010 0 OHM JUMPER
RES, 0603 0 OHMS JUMPER
RES, 0603 1M OHMS 5% 1/10W
RES, 0603 681K OHMS 1% 1/10W
IC, LTC6992
IC, SINGLE OP AMP
CAP , 0603 100nF 20% 16V X7R
RES, 0603 182 OHMS 1% 1/10W
RES, VARIABLE 5K
RES, 0603 649 OHMS 1% 1/10W
RES, 0603 3.3 OHMS 1% 1/10W
RES, 0603 82.5 OHMS 1% 1/10W
CAP , 0603 150pF 5% 50V NPO
RES, 0603 2 OHMS 5% 1/10W
RES, 2512 0.01 OHMS 1% 1W
XSTR, MOSFET, N-CHANNEL 40V
CAP , 0603 1uF 20% 25V X5R
CAP , 1210 100uF 20% 6.3V X5R
CAP , 7343 470uF 20% 2.5V SPCAP
IC, 24LC05-I/ST
RES, 0603 4.99K OHMS 1% 0.1W
RES, 0603 127 OHMS 1% 1/10W
RES, 0603 200 OHMS 5% 1/10W
RES, 0603 15.8K OHMS 1% 1/10W
DIODE, ULTRA LOW SCHOTTKY RECTIEIER
LED, 0603 GREEN
MANUFACTURER/PART, NUMBER
OPTION
OPTION
PANASONIC, ERJ-8ENF1000V
MURATA, GRM32DR71C106KA01
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW060334K8FKEA
ANALOG DEVICES, LT1761ES5-SD
VISHAY, CRCW0603154KFKEA
VISHAY, CRCW060320K0JNEA
VISHAY, WSL201000000ZEA9
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW06031M00JNEA
VISHAY, CRCW0603681KFKEA
ANALOG DEVICES, LTC6992IS6-1
ANALOG DEVICES, LT1803IS5
AVX, 0603YC104MAT2A
VISHAY, CRCW0603182RFKEA
BOURNS, 3386P-1-502-LF
VISHAY, CRCW0603649RFKEA
VISHAY, CRCW06033R30FKEA
VISHAY, CRCW060382R5FKEA
AVX, 06035A151JAT2A
VISHAY, CRCW06032R00JNEA
VISHAY, WSL2512R0100FEA
VISHAY, SUD50N04-8M8P-4GE3
AVX, 06033D105MAT2A
AVX, 12106D107MAT2A
PANASONIC, EEF-GX0E471L
MICROCHIP , 24LC025-I/ST
VISHAY, CRCW06034K99FKEA
VISHAY, CRCW0603127RFKEA
VISHAY, CRCW0603200RJNEA
VISHAY, CRCW060315K8FKEA
NXP SEMI., PMEG2005AEL, 315
WURTH ELEKTRONIK, 150060GS75000
