Analog Devices Linear DC2331A-A Demo Manual page 15

PARTS LIST
ITEM QTY REFERENCE
DC2331A-B Required Circuit Components
1 4 CIN1, CIN2, CIN3, CIN5
2 8 CIN6, CIN7, CIN8, CIN9, CIN10, CIN11, CIN14,
CIN15
3 3 CIN17, CIN18, CIN19
4 4 COUT1, COUT2, COUT3, COUT4
5 8 COUT6, COUT7, COUT8, COUT9, COUT10,
COUT11, COUT12, COUT13
6 1 C1
7 2 C2, C33
8 1 C3
9 7 C8, C9, C10, C11, C12, C13, C35
10 1 C6
11 4 C17, C18, C19, C20
12 1 C24
13 1 C26
14 1 C27
15 1 C28
16 1 C32
17 2 C34, C62
18 1 C55
19 4 D1, D2, D3, D4
20 4 L1, L2, L3, L4
21 1 L6
22 16 Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8, Q9, Q10,
Q11, Q12, Q13, Q14, Q15, Q16
23 1 Q21
24 4 RSNS1, RSNS2, RSNS3, RSNS4
25 1 R2
26 1 R3
27 6 R7, R12, R13, R14, R15, R26
28 1 R10
29 1 R27
30 1 R28
31 1 R29
32 1 U1
33 1 U3
DC2331A-A/DC2331A-B
PART DESCRIPTION
CAP ., X7S, 4.7µF, 100V, 10%, 1210
CAP ., X7R, 15µF, 100V, 10%, 2220
(J-LEAD)
CAP ., ALUM., POLYMER, 47µF, 63V,
20%
CAP ., X7R, 22µF, 16V, 20%, 1210
CAP ., ALUM., 150µF, 16V, 20%
CAP ., X7R, 2.2µF, 100V, 20%, 1206
CAP ., X5R, 2.2µF, 16V, 10%, 0603
CAP ., X5R, 10µF, 16V, 10%, 0603
CAP ., X7R, 1000pF, 25V, 10%, 0603
CAP ., X7R, 100pF, 16V, 10%, 0603
CAP ., X7R, 0.22µF, 16V, 10%, 0603
CAP ., X7R, 1µF, 16V, 10%, 0603
CAP ., NP0, 10pF, 50V, 5%, 0603
CAP ., X7R, 10nF, 16V, 10%, 0603
CAP ., X7R, 2.2µF, 100V, 10%, 1210
CAP ., X5R, 47µF, 16V, 10%, 1210
CAP ., X7R, 0.1µF, 16V, 10%, 0603
CAP ., X7R, 220pF, 25V, 10%, 0603
DIODE, SCHOTTKY, 100V, SOD323
IND., 6.8µH
IND., 47µH
XSTR., MOSFET, 60V, PG-TDSON-8
MOSFET, P-CH 100V 2.6A SOT223
RES., SENSE, 0.0025Ω, 3W, 1%,
2512
RES., 118k, 1/10W, 1%, 0603
RES., 13k, 1/10W, 1%, 0603
RES., CHIP , 10Ω, 1/10W, 5%, 0603
RES., CHIP , 1Ω, 1/10W, 5%, 0603
RES., 19.6k, 1/10W, 1%, 0603
RES., 75k, 1/10W, 1%, 0603
RES., 1M, 1/10W, 1%, 0603
I.C., LT8550, 52QFN
I.C., REG., TSSOP28FE-EA
DEMO MANUAL
MANUFACTURER/PART NUMBER
MURATA, GRJ32DC72A475KE11L
MURATA, KRM55WR72A156MH01K
SUN ELEC., 63HVH47M
MURATA, GRM32ER71C226MEA8L
PANASONIC, 16SVP150M
MURATA, GRM31CR72A225MA73L
MURATA, GRM188R61C225KE15D
MURATA, GRM188R61C106KAALD
MURATA, GRM188R71E102KA01D
AVX, 0603YC101KAT2A
MURATA, GRM188R71C224KA01D
MURATA, GRM188R71C105KA12D
MURATA, GRM1885C1H100JA01D
MURATA, GRM188R71C103KA01D
MURATA, GRM32ER72A225KA35L
MURATA, GRM32ER61C476KE15K
MURATA, GRM188R71C104KA01D
AVX, 06033C221KAT4A
NXP , BAT46WJ,115
COILCRAFT, SER2915L-682KL
Wurth Elektronik, 744771147
INFINEON, BSC100N06LS3
DIODES INC., ZXMP10A18G
NIC, NCSR300F2M50DTRGF
IRC/TT ELECTRONICS, ULRG32512R0025FLFSLT
PANASONIC, ERJMP4PF2M5U
VISHAY, CRCW0603118KFKEA
VISHAY, CRCW060313K0FKEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW06031R00JNEA
VISHAY, CRCW060319K6FKEA
VISHAY, CRCW060375K0FKEA
VISHAY, CRCW06031M00FKEA
ANALOG DEVICES, LT8550EUKG#PBF
ANALOG DEVICES, LT8631EFE#PBF
Rev. 0
15
