DEMO MANUAL
DC2331A-A/DC2331A-B
PARTS LIST
ITEM QTY REFERENCE
DC2331A-B Additional Demo Board Circuit Components
1 0 CIN4, COUT5(OPT)
2 0 CIN12, CIN13(OPT)
3 1 CIN16
4 0 CIN20(OPT)
5 0 COUT14, COUT15(OPT)
6 0 C4, C5, C14, C15, C21, C22, C25, C30, C31,
C36, C37, C38, C39, C40, C41, C42, C43, C44,
C45, C46, C47, C48, C49, C50, C51, C52, C53,
C54, C56, C57, C58, C59, C60, C61(OPT)
7 1 C7
8 1 C16
9 0 C23(OPT)
10 0 C29(OPT)
11 0 D5, D6, D7(OPT)
12 0 D8(OPT)
13 0 L5(OPT)
14 0 Q17, Q18, Q19, Q20(OPT)
15 0 Q22(OPT)
16 0 RSNS5, R106(OPT)
17 0 RT1(OPT)
18 0 R1, R4, R6, R9, R11, R16, R17, R18, R19,
R20, R21, R22, R24, R25, R33, R34, R35,
R36, R37, R38, R39, R40, R41, R42, R43,
R44, R45, R46, R47, R49, R50, R51, R52,
R53, R55, R56, R57, R58, R59, R60, R62,
R63, R64, R65, R66, R67, R68, R69, R70,
R71, R76, R77, R78, R79, R81, R82, R84,
R85, R86, R87, R88, R89, R90, R91, R92,
R93, R94, R98, R99, R100, R101, R102,
R103, R104, R105, R108, R109, R110, R111,
R112, R113, R114, R115, R116, R117, R118,
R119(OPT)
19 11 R3, R5, R8, R30, R31, R32, R80, R95, R96,
R97, R107
20 1 R48
21 1 R54
22 1 R61
23 0 R72, R73, R74, R75,
R83(OPT)
16
PART DESCRIPTION
CAP ., OPTION, 1210
CAP ., OPTION, 2220 (J-LEAD)
CAP ., ALUM., 470µF, 20%, 63V
CAP ., ALUM., OPTION
CAP ., ALUM., OPTION
CAP ., OPTION, 0603
CAP ., X7R, 1000pF, 25V, 10%, 0603
CAP ., ALUM., 10µF, 100V, 20%
CAP ., OPTION, 1206
CAP ., OPTION, 0805
DIODE, SCHOTTKY, OPTION, SOD323
DIODE, OPTION, SOD523
IND., OPTION
XSTR., MOSFET, OPTION,
PG-TDSON-8
MOSFET, OPTION, SOT223
RES.,. OPTION, 2512
THERMISTOR, OPTION, 0603
RES., OPTION, 0603
RES., CHIP , 0Ω, 1/10W, 1%, 0603
RES., 133k, 1/10W, 1%, 0603
RES., 10k, 1/10W, 5%, 0603
RES., 1M, 1/10W, 1%, 0603
RES., OPTION, 0805
MANUFACTURER/PART NUMBER
PANASONIC, EEV-FK1J471M
MURATA, GRM188R71E102KA01D
SUN ELEC., 100CE10BS
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603133KFKEA
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW06031M00FKEA
