PARTS LIST

ITEM QTY REFERENCE
18 24 E1, E2, E3, E4, E5, E6, E7, E8, E9,
E10, E11, E12, E13, E14, E15, E16,
E17, E20, E21, E22, E23, E24, E29,
E30
19 1 J1
20 2 JP1, JP2
21 1 J2
22 3 J3, J4, J12
23 6 J5, J6, J7, J8, J9, J10
24 1 J11
25 1 J13
26 1 LB1
27 4 MH1, MH2, MH3, MH4
28 1 PCB
29 1 Q1
30 1 Q19
31 2 R2, R22
32 13 R3, R5, R7, R8, R25, R28, R32,
R63, R65, R66, R91, R92, R93
33 0 R6, R9, R23, R26, R28, R29, R31,
R35, R38, R41, R42, R61, R62,
R64, R67, R68, R74, R75, R83,
R88, R89
34 12 R10, R11, R12, R13, R14, R15,
R16, R18, R19, R24, R52, R77
35 1 R27
38 1 R30
39 1 R48
40 0 R49
41 0 R50, R51
DEMO MANUAL DC3089A
PART DESCRIPTION
TEST POINT, TURRET, 0.064 MTG. HOLE, PCB
0.062 THK
CONN., HDR, MALE, 2x7, 2mm, R, A THT
CONN., HDR., MALE, 1x3, 2mm, VERT, ST, THT
CONN., HDR, FEMALE, 2x7, 2mm, R, A THT
CONN., RF , BNC, RCPT, JACK, 5-PIN, ST, THT, 50Ω
CONN., BANANA JACK, FEMALE, THT, NON-
INSULATED, SWAGE, 0.218
CONN., HDR, SHROUDED, MALE, 2x6, 2mm, VERT,
ST, THT
CONN., HDR, SHROUDED, MALE, 1x4, 2mm, VERT,
ST, THT
LABEL SPEC, DEMO BOARD SERIAL NUMBER
STANDOFF , NYLON, SNAP-ON, 0.50
PCB, DC3089A
XSTR., MOSFET, N-CH, 40V, 14A, DPAK (TO-252)
XSTR., MOSFET, P-CH, 30V, 3.5A, SOT23-3,
AEC-Q101
RES., 7.5k, 1%, 1, 10W, 0603
RES., 0Ω, 1, 10W, 0603, AEC-Q200
RES., OPTION, 0603
RES., 10k, 1%, 1, 10W, 0603, AEC-Q200
RES., 12.7k, 1%, 1, 10W, 0603
RES., 0.787k, 1%, 1, 10W, 0603, AEC-Q200
RES., 0Ω, 3, 4W, 2010, AEC-Q200
RES., OPTION, 2010
RES., OPTION, 300Ω, 1%, 2512
MANUFACTURER, PART NUMBER
MILL-MAX, 2308-2-00-80-00-00-07-0
MOLEX, 0877601416
MOLEX, 87760-1416
SULLINS CONNECTOR SOLUTIONS,
NRPN031PAEN-RC
SULLINS CONNECTOR SOLUTIONS,
NPPN072FJFN-RC
AMPHENOL RF , 112404
KEYSTONE, 575-4
AMPHENOL, 98414-G06-12ULF
FCI, 98414-G06-12ULF
HIROSE ELECTRIC, DF3A-4P-2DSA
BRADY, THT-96-717-10
KEYSTONE, 8833
ADI APPROVED SUPPLIER, 600-DC3089A
VISHAY, SUD50N04-8M8P-4GE3
DIODES INC., DMP3130LQ-7
VISHAY, CRCW06037K5FKEA
NIC, NRC06ZOTRF
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW06030000Z0EB
KOA SPEER, RK73H1JTTD1002F
PANASONIC, ERJ3EKF1002V
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060312K7FKEA
NIC., NRC06F7870TRF
NIC, NRC50ZOTRF
PANASONIC, ERJ12ZY0R00U
VISHAY, CRCW20100000Z0EF
