Analog Devices Linear DC2331A-A Demo Manual page 13

PARTS LIST
ITEM QTY REFERENCE
31 2 R1, R50
32 1 R2
33 1 R3
34 2 R4, R98
35 6 R7, R11, R12, R13, R14, R15
36 1 R8
37 1 R10
38 1 R16
39 1 R17
40 1 R18
41 1 R19
42 1 R20
43 3 R21, R22, R25
44 1 R27
45 1 R28
46 1 R29
47 1 R82
48 1 U1
49 1 U2
50 1 U3
DC2331A-A Additional Demo Board Circuit Components
1 1 CIN16
2 0 CIN20(OPT)
3 1 C7
4 1 C16
5 0 C37, C38, C39, C40, C41, C42, C43, C44, C45,
C46, C47, C48, C49, C50, C51, C52, C53, C54,
C55, C56, C58, C59(OPT)
6 1 C61
7 0 Q22(OPT)
8 1 RT1
9 15 R5, R6, R23, R34, R35, R36, R37, R38, R39,
R40, R41, R49, R53, R56, R62
10 0 R9, R26, R30, R31, R32, R33, R42, R43, R44,
R45, R46, R47, R57, R58, R59, R60, R63,
R64, R65, R66, R67, R68, R69, R70, R71,
R76, R77, R78, R79, R80, R81, R84, R85,
R86, R87, R88, R89, R90, R91, R92, R93,
R94, R95, R102, R103, R104, R105, R107,
R108, R109, R110, R111, R112, R113, R114,
R115, R116, R117, R118, R119(OPT)
DC2331A-A/DC2331A-B
PART DESCRIPTION
RES., 100k, 1/10W, 1%, 0603
RES., 118k, 1/10W, 1%, 0603
RES., 13k, 1/10W, 1%, 0603
RES., 47k, 1/10W, 5%, 0603
RES., CHIP , 10Ω, 1/10W, 5%, 0603
RES., CHIP , 20Ω, 1/10W, 5%, 0603
RES., CHIP , 1Ω, 1/10W, 5%, 0603
RES., 210k, 1/10W, 1%, 0603
RES., 12.1k, 1/10W, 1%, 0603
RES., 107k, 1/10W, 1%, 0603
RES., 909Ω, 1/10W, 1%, 0603
RES, 10k, 1/10W, 5%, 0603
RES., 10Ω, 1/10W, 5%, 0603
RES., 19.6k, 1/10W, 1%, 0603
RES., 75k, 1/10W, 1%, 0603
RES., 1M, 1/10W, 1%, 0603
RES., 150k, 1/10W, 1%, 0603
I.C., LT8550, 52QFN
I.C., LED DRIVER, 28TSSOP
I.C., REG., TSSOP28FE-EA
CAP ., ALUM., 470µF, 20%, 63V
CAP ., ALUM., OPTION
CAP ., X7R, 1000pF, 25V, 10%, 0603
CAP ., ALUM., 10µF, 100V, 20%
CAP ., OPTION, 0603
CAP ., X7R, 0.1µF,16V, 10%, 0603
TRAN., OPTION, SOT-23
THERMISTOR, NTC, 470KΩ, 0603
RES., CHIP , 0Ω, 1/10W, 1%, 0603
RES., OPTION, 0603
DEMO MANUAL
MANUFACTURER/PART NUMBER
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603118KFKEA
VISHAY, CRCW060313K0FKEA
VISHAY, CRCW060347K0JNEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW060320R0JNEA
VISHAY, CRCW06031R00JNEA
VISHAY, CRCW0603210KFKEA
VISHAY, CRCW060312K1FKEA
VISHAY, CRCW0603107KFKEA
VISHAY, CRCW0603909RFKEA
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW060319K6FKEA
VISHAY, CRCW060375K0FKEA
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW0603150KFKEA
ANALOG DEVICES, LT8550EUKG#PBF
ANALOG DEVICES, LT3763EFE#PBF
ANALOG DEVICES, LT8631EFE#PBF
PANASONIC, EEV-FK1J471M
MURATA, GRM188R71E102KA01D
SUN ELEC., 100CE10BS
MURATA, GRM188R71C104KA01D
MURATA, NCP18WM474J03RB
VISHAY, CRCW06030000Z0EA
Rev. 0
13
