Parts List - Analog Devices LTC6955 Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 15 C1, C2, C5, C6, C9-C12, C17, C18,
C21, C22, C50, C56, C57
2 0 C3, C4, C7, C8, C13-C16, C19, C20
3 12 C25-C36
4 11 C38-C48
5 1 C49
6 1 C62
7 10 E1-E10
8 1 JP1
9 16 J1, J2, J5, J6, J9-J12, J17, J18,
J21-J26
10 0 J3, J4, J7, J8, J13-J16, J19, J20
11 2 J27, J28
12 2 R1, R2
13 1 R3
14 5 R4, R5, R6, R7, R12
15 1 R18
16 4 SW0, SW1, SW2, SW3
17 1 SHUNT ON JP1 (1&2)
18 4 MH1-MH4
19 1 DUST CAP FOR J26
DEMO MANUAL DC2611A
PART DESCRIPTION
CAP ., X7R, 0.1µF, 10V, 10%, 0402
CAP ., 0402
CAP ., X7R, 0.01µF, 6.3V, 10%, 0201
CAP ., X5R, 1µF, 16V, 10%, 0402
CAP ., X7R, 10µF, 25V, 10%, 1206
CAP ., TANT., 330µF, 10V, 10%, 7343
TURRET, TESTPOINT 0.064"
CONN., HEADER, MALE, 1X3, 2mm, THT
CONN., SMA 50Ω EDGE-LAUNCH, CON-SMA-R
CONN., SMA 50Ω EDGE-LAUNCH, CON-SMA-R
CONN, JACK, BANANA
RES., CHIP , 10k, 1/10W, 1% 0402
RES., CHIP , 100k, 1/10W, 1% 0402
RES., CHIP , 100Ω, 1/16W, 1% 0402
RES., CHIP , 0Ω, 1/10W, 0402
SWITCH, SLIDE SPDT 200MA 30V, SW-EG1218
SHUNT, 2mm
STANDOFF , NYLON, 0.5, 1/2"
WYHP DUST CAP FOR SMA FEMALE RF CONN
MANUFACTURER/PART NUMBER
MURATA, GRM155R71A104KA01D
OPT
MURATA, GRM033R70J103KA01D
MURATA, GRM155R61C105KE01D
MURATA, GRM31CR71E106KA12L
AVX, TPME337K010R0035
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
CCSJ, 142-0701-851
OPT
KEYSTONE, 575-4
VISHAY, CRCW040210K0FKED
VISHAY, CRCW0402100KFKED
VISHAY, CRCW0402100RFKED
VISHAY, CRCW04020000Z0ED
E-SWITCH, EG1218
WURTH ELEKTRONIK, 60800213421
WURTH ELEKTRONIK, 702935000
AMAZON
Rev. 0
7
