DEMO MANUAL
DC2331A-A/DC2331A-B
PARTS LIST
ITEM QTY REFERENCE
11 2 R24, R52
12 1 R51
13 1 R48
14 1 R54
15 1 R55
16 1 R61
17 0 R72, R73, R74, R75(OPT)
18 0 R83(OPT)
19 0 R106(OPT)
20 0 U4 (OPT)
DC2331A-A Hardware: For Demo Board Only
1 31 E1, E2, E3, E4, E5, E6, E7, E8, E9, E10, E11,
E12, E13, E14, E15, E16, E17, E18, E19, E20
E21, E22, E23, E24, E25, E26, E27, E28 E29,
E30, E31
2 2 JP1, JP2
3 2 JP3, JP4
4 1 JP5
5 5 XJP1, XJP2, XJP3, XJP4, XJP5
6 4 J1-J4
7 8 (J1-J4)
8 12 (J1-J4)
9 4 (J1-J4)
10 2 J5, J6
11 4 MH1-MH4
14
PART DESCRIPTION
RES., 47k, 1/10W, 5%, 0603
RES., 100k, 1/10W, 1%, 0603
RES., 133k, 1/10W, 1%, 0603
RES., 10k, 1/10W, 5%, 0603
RES., 15k, 1/10W, 1%, 0603
RES., 1M, 1/10W, 1%, 0603
RES., OPTION, 0805
RES., OPTION, 0805
RES., OPTION, 2512
I.C., OPTION, OPAMP , 8MSOP
TESTPOINT, TURRET, .061"
HEADER 4 PIN 0.079 SINGLE ROW
HEADER 3 PIN 0.079 SINGLE ROW
HEADER 2X4 PIN, 0.079
SHUNT, 2mm
STUD, TEST PIN
NUT, BRASS NUTS # 10-32
RING, LUG RING # 10
WASHER, TIN PLATED BRASS
HEADER, 2X7PIN, 0.079"
STAND-OFF , NYLON 1.0"
MANUFACTURER/PART NUMBER
VISHAY, CRCW060347K0JNEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603133KFKEA
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW060315K0FKEA
VISHAY, CRCW06031M00FKEA
ANALOG DEVICES, LT1636CMS8#PBF
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000411121
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 62000821121
WURTH ELEKTRONIK, 60800213421
PEM, KFH-032-10ET
ANY, 10-32M/S BR PL
KEYSTONE, 8208
ANY, #10EXT- BZ TN
MOLEX, 87831-1420
WURTH ELEKTRONIK, 702939000
Rev. 0
