ORDERING INFORMATION

BILL OF MATERIALS (BOM)

Table 2. Daughterboard BOM
Item Quantity Reference Designator
1 1 U1
2 2 C19, C20
3 1 C1
4 2 J1, J2
5 3 LK1, LK2, LK3
Table 3. Motherboard BOM
Item Quantity Reference
1 5 R12, R21, R25, R27, R30
2 7 C1, C3, C5, C8, C29, C31, C33
3 16 C2, C4, C6, C7, C9, C11, C12, C13,
C21, C22, C26 to C28, C30, C32, C34
4 2 C10, C16
5 6 C14, C15, C17, C18, C23, C24
6 1 C25
7 22 D1 to D11, D18, D19, D21 to D27, D30
8 2 D12, D13
9 1 JP1
10 18 J1 to J8, J13 to J22
11 1 J9
12 1 J10
13 2 J11, J12
14 3 LK8 to LK10
15 22 R1 to R11, R13, R15, R18, R43 to R46,
R51, R52, R59
16 3 R17, R19, R22
17 23 R31 to R42, R47 to R50, R55 to R58
18 1 R20
19 1 R26
20 2 R28, R29
21 18 SW1 to SW18
22 81 S1 to S81
23 5 U1, U2, U9 to U11
24 1 U3
25 1 U4
26 3 U5, U7
27 1 U8
28 1 Y1
Description Manufacturer/Vendor
ADP5588 IC Analog Devices
0.1 μF capacitor Murata
1 μF capacitor Murata
10 × 2 connector Samtec
1-way link Sullins Connector Solutions
Description
Resistor, 10 kΩ, 0402
Capacitor MLCC, 10 μF,
16 V, 0805, X5R
Capacitor MLCC, 0.1 μF,
16 V, 0603, X5R
Capacitor MLCC, 6.2 pF,
50 V, 0603, X5R
Capacitor MLCC, 2.2 μF,
16 V, 0603, X5R
Capacitor MLCC, 47 μF,
16 V, 1210, X5R
White LED
Photo-sensor
USB connector
3 × 2 connector
4 × 2 connector
4 × 1 connector
10 × 2 connector
2-way link
Resistor, 681 Ω, 0603
Resistor, 100 kΩ, 0402
Resistor, 100 kΩ, 0603
Resistor, 24.3 kΩ, 0402
Resistor, 31.6 kΩ, 0402
Resistor, 2.21 kΩ, 0805
3-way Switch
Push-button switch
ADG712
ADG802
USB microcontroller
ADP1715
Serial EEPROM
Crystal 24 MHz
Rev. 0 | Page 19 of 20
Manufacturer/Vendor
Vishay
Murata
Murata
Murata
Murata
Murata
Lite-On, Inc.
Avago Technologies
Hirose Electric
Sullins Connector Solutions
Sullins Connector Solutions
Sullins Connector Solutions
Sullins Connector Solutions
Sullins Connector Solutions
Vishay
Vishay
Vishay
Vishay
Vishay
Vishay
APEM Components, Inc.
ITT Industries, C&K
Analog Devices
Analog Devices
Cypress Semiconductor Corp.
Analog Devices
Microchip
CTS, Frequency Controls (VA)
EVAL-ADP5588
Manufacturer Part No.
ADP5588ACPZ-RL
GRM188R71E104KA01
GRM188R61C105K
SSW-110-03-G-D
PEC36SAAN
Manufacturer Part No.
CRCW040210K0FKE
GRM21BR61C106K
GRM188R61C104KA01B
GRM1885C1H6R2DZ01D
GRM188R61C225K
GRM32ER61C476K
LTW-170TK
APDS-9005
UX60-MB-5ST
PEC36DAAN
PEC36DAAN
PEC36SAAN
PEC36DAAN
PEC36SAAN
CRCW0603681RFKE
CRCW0402100KFKE
CRCW0603100KFKE
CRCW040224K3FKE
CRCW040231K6FKE
CRCW08052K21FKE
SW MAG-SPDT
SW PUSHBUTTON
ADG712BRUZ
ADG802BRTZ-REEL7
CY7C68013A
ADP1715ARMZ-R7
M24C64-R
CTX651CT
